SRWF10UMOD - Tripp Lite SMARTRACK 5U LOW-PROFILE VERTICAL-MOUNT SWITCH-DEPTH WALL-MOUNT STRUCTURED WIRIN

Rugged 5U Enclosure Ideal for Housing Regular Rack and Non-Rack Network Equipment This heavy-duty steel enclosure secures and houses both regular rack equipment and other equipment not typically mounted in an EIA-standard 19-inch rack. It is recommended for wiring closets, retail locations, classrooms, back offices and other areas with limited floor space where you need audio/video, voice and data infrastructure to be secure, organized and out of the way. Constructed with a durable black powder-coated finish, the vertical equipment rack has a maximum load capacity of 68 kgs.
Connect a Modem, Router and Other Non-Rack Equipment Inside the Enclosure Two pre-installed, but removable, 1U shelves with adjustable metal equipment brackets attach to the cabinet’s square mounting holes. Just place your modem, router, firewall, switch, power block or other non-rack equipment on the brackets, and use the included thumbscrew to secure them to the rack. Four RJ45 jacks are built into the rack cabinet for connecting your devices to a network.
Low-Profile Design Accommodates Switches, Panels and Other Standard Rack Equipment Remove the two shelves to reveal two 5U areas for rack-mount equipment, one above the other, forming a total mounting space of 10U. The enclosure extends less than seven inches from the wall, while housing equipment up to 16.5 inches deep, including network switches and patch panels.
Keeps Important Equipment Secure and Easy to Access The reversible front door locks securely with a built-in combination lock to help prevent damage, tampering or theft. The vented cabinet allows air to flow freely and keep equipment cool. Brush-strip cable plates on both sides allow easy cable routing while preventing dust from entering.
Easy Enclosure Deployment and Equipment Installation The structured wiring cabinet comes fully assembled and ready to mount to the wall. The equipment brackets adjust easily and allow for flexibility in storing routers and other devices.
Meets Payment Card Industry Standards The SRWF10UMOD provides physical equipment and media security required for PCI DSS (Payment Card Industry Data Security Standard) compliance. This is essential for companies that process, store and/or transmit credit card information.
Typical Application ● Simplify the installation and maintenance of multiple network connections by storing equipment together ● Organize various A/V, voice and data network cable runs to cut down on cord clutter ● Protect valuable components from damage, tampering or theft to prevent costly downtime and equipment replacement Introduction Bullets ● 2 removable 1U shelves with adjustable metal brackets secure non-rack equipment ● Houses 2 areas of 5U of rack equipment up to 16.5 in. deep (when 1U shelves are removed) ● Structured wiring cabinet extends less than 7 in. from wall with max capacity of 68 kgs. ● 4 built-in RJ45 jacks connect installed modem, router and other equipment to network ● Ships fully assembled for immediate installation in back office area or network closet Package Includes ● SRWF10UMOD 5U Structured Wiring Enclosure ● (2) Pre-installed 1U shelves ● Adjustable equipment brackets ● Combination lock instructions



Specification:



Weight & dimensions
Package depth	42.9" (1089.9 mm)
Package width	22.4" (570 mm)
Package height	18.9" (479.8 mm)
Package weight	82.9 lbs (37.6 kg)
Mounting depth (max)	35" (88.9 cm)
Width	19.7" (500 mm)
Depth	16.2" (410.4 mm)
Height	38" (965.2 mm)
Weight	66.8 lbs (30.3 kg)
Maximum weight capacity	400000.1 lbs (181437 kg)
Packaging content
Manual	Yes
Features
Key lock	Yes
Rack capacity	12U
Type	Freestanding rack
Maximum weight capacity	400000.1 lbs (181437 kg)
Product colour	Black
Packaging data
Manual	Yes
Package depth	42.9" (1089.9 mm)
Package width	22.4" (570 mm)
Package height	18.9" (479.8 mm)
Package weight	82.9 lbs (37.6 kg)
Technical details
Package width	22.4" (570 mm)
Package height	18.9" (479.8 mm)
Type	Freestanding rack
Harmonized System (HS) code	8517.79.0000
Rack capacity	12U
Colour
Product colour	Black
Logistics data
Master (outer) case width	22.4" (570 mm)
Master (outer) case length	42.9" (1089.9 mm)
Master (outer) case height	18.9" (479.8 mm)
Master (outer) case gross weight	82.9 lbs (37.6 kg)
Products per master (outer) case	1 pc(s)
Country of origin	China
