UNIRAILS1U - StarTech.com MOUNT 19 SERVERS OR NETWORKING HARDWARE IN ANY STANDARD RACK - SERVER RACK RAILS

Mount 19" Servers or Networking Hardware in any Standard RackThese 1U server-rack rails let you mount non-rackmount equipment such as desktop servers, networking equipment or KVM switches, into your 19€� server rack without sacrificing 1U of rack space, like you would with a traditional shelf. The rack rails are also a great solution for mounting equipment with damaged rails or discontinued OEM equipment such as Dell , IBM, HP or Apple servers that no longer have rack rails available.This TAA compliant product adheres to the requirements of the US Federal Trade Agreements Act (TAA), allowing government GSA Schedule purchases.Turn non-rackmount equipment into 1U rackmount hardwareThese rack rails add rackmount functionality to your non-rackmount gear, by cradling your equipment in an open frame supported by three sturdy crossbars. You can mount your non-rackmount equipment by mounting the rails to your server rack and placing your equipment on the undercarriage. For equipment that already features mounting holes, the rails also feature multiple mounting patterns to secure your equipment, for an added level of security.Universal design mounts to almost any 19" server rackAdhering to the EIA-310 standard for 19€� rackmount equipment, these mounting rails are universally compatible with 19€� server racks. The depth is adjustable for a variety of rack sizes and configurations. Plus, there is a rear cable management panel that€™s removable for additional customization.Maximum durabilityTo ensure your equipment is secure, these mounting rails feature cold-rolled steel construction. The durable design can support a weight load of up to 55 lb (25 kg).The UNIRAILS1U is backed by a lifetime StarTech.com warranty with free technical support.The StarTech.com Advantage



Specification:



Features
Type	Rack rail
Maximum weight capacity	200 lbs (90.7 kg)
Product colour	Black
Compliance industry standards	EIA-310-D
Harmonized System (HS) code	85389099
Weight & dimensions
Package width	8.66" (220 mm)
Package height	3.54" (90 mm)
Package depth	25.2" (640 mm)
Package weight	8.82 lbs (4 kg)
Mounting depth (min)	24" (61 cm)
Mounting depth (max)	36" (91.4 cm)
Width	3.15" (80 mm)
Weight	7.72 lbs (3.5 kg)
Height	1.77" (45 mm)
Depth	24.7" (628 mm)
Maximum weight capacity	200 lbs (90.7 kg)
Packaging data
Package width	8.66" (220 mm)
Package height	3.54" (90 mm)
Package depth	25.2" (640 mm)
Package weight	8.82 lbs (4 kg)
Quantity per pack	2 pc(s)
Packaging content
Screws included	Yes
Nuts included	Yes
Number of screws	8
Number of nuts	8
Quick installation guide	Yes
Washers included	Yes
Number of washers included	8
Technical details
Type	Rack rail
Sustainability certificates	CE, RoHS
Colour
Product colour	Black
Logistics data
Master (outer) case width	18.1" (460 mm)
Master (outer) case length	26" (660 mm)
Master (outer) case height	19.3" (490 mm)
Products per master (outer) case	10 pc(s)
Harmonized System (HS) code	85389099
