| Management features | |
|---|---|
| Multicast support | Yes |
| Traffic classification | Yes |
| ARP inspection | Yes |
| Switch type | Managed |
| Web-based management | Yes |
| Quality of Service (QoS) support | Yes |
| Switch layer | L3 |
| Ports & interfaces | |
| Copper ethernet cabling technology | 10BASE-T,100BASE-T,1000BASE-T |
| Switching optical modules type | 100 Gigabit Ethernet |
| Basic switching RJ-45 Ethernet ports quantity | 28 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Installed SFP modules quantity | 4 |
| Gigabit Ethernet (copper) ports quantity | 24 |
| Console port | RS-232 |
| Networking | |
| IGMP snooping | Yes |
| Copper ethernet cabling technology | 10BASE-T,100BASE-T,1000BASE-T |
| Networking standards | IEEE 802.2,IEEE 802.3,IEEE 802.3ab,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z |
| Full duplex | Yes |
| VLAN support | Yes |
| Port mirroring | Yes |
| Number of VLANs | 4094 |
| Link aggregation | Yes |
| Flow control support | Yes |
| Virtual LAN features | Private VLAN |
| Virtual LAN features | |
| VLAN support | Yes |
| Number of VLANs | 4094 |
| Virtual LAN features | Private VLAN |
| Data transmission | |
| Number of VLANs | 4094 |
| Jumbo frames | 10000 |
| Latency (1 Gbps) | 4.3 µs |
| Packet buffer memory | 1.5 MB |
| MAC address table | 16000 entries |
| Switching capacity | 56 Gbit/s |
| Jumbo frames support | Yes |
| Forwarding rate | 41.7 Mpps |
| Performance | |
| Packet buffer memory | 1.5 MB |
| Noise level | 34 dB |
| Memory type | DDR-SDRAM |
| Internal memory | 512 MB |
| Flash memory | 64 MB |
| Technical details | |
| Product colour | Grey |
| Noise level | 34 dB |
| Rack mounting | No |
| Optical fiber | |
| Switching optical modules type | 100 Gigabit Ethernet |
| Security | |
| Loop protection | Yes |
| BPDU filtering/protection | Yes |
| Authentication | Guest VLAN,MAC-based authentication,Port-based authentication |
| SSH/SSL support | Yes |
| Security algorithms | 3DES,128-bit AES,192-bit AES,256-bit AES,802.1x RADIUS,AES,DES,MD5,PEAP,RSA,SHA-1,SHA-2,SSL/TLS,TTLS |
| MAC address filtering | Yes |
| IGMP snooping | Yes |
| Access Control List (ACL) | Yes |
| Password protection | Yes |
| DHCP features | DHCP snooping,DHCP client |
| Multicast features | |
| Multicast support | Yes |
| Protocols | |
| Management protocols | SNMP |
| Certificates | |
| Safety | EN60950-1 (TUV), UL 60950-1(cULus), EN60825-1 |
| Electromagnetic compatibility | EN55024 |
| Certification | UL, cUL, UL-EU, CE |
| Memory | |
| Packet buffer memory | 1.5 MB |
| Memory type | DDR-SDRAM |
| Internal memory | 512 MB |
| Flash memory | 64 MB |
| Design | |
| Country of origin | China |
| Safety | EN60950-1 (TUV), UL 60950-1(cULus), EN60825-1 |
| Product colour | Grey |
| LED indicators | Yes |
| Electromagnetic compatibility | EN55024 |
| Certification | UL, cUL, UL-EU, CE |
| Rack mounting | No |
| Indication | |
| LED indicators | Yes |
| Power | |
| Power consumption (max) | 26 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 2.4 A |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | No |
| Operational conditions | |
| Storage temperature (T-T) | -25 - 70 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 5 - 90% |
| Operating altitude | 0 - 118110.2" (0 - 3000 m) |
| Non-operating altitude | 0 - 157480.3" (0 - 4000 m) |
| Heat dissipation | 89 BTU/h |
| Weight & dimensions | |
| Width | 13.4" (341 mm) |
| Depth | 9.09" (231 mm) |
| Height | 1.73" (44 mm) |
| Weight | 5.29 lbs (2.4 kg) |
| Packaging data | |
| Package width | 16.9" (430 mm) |
| Package depth | 14.2" (360 mm) |
| Package height | 5.91" (150 mm) |
| Package weight | 8.82 lbs (4 kg) |
| Other features | |
| Country of origin | China |
