| Management features | |
|---|---|
| Multicast support | Yes |
| Switch type | Managed |
| Web-based management | Yes |
| Quality of Service (QoS) support | Yes |
| MIB support | Yes |
| Switch layer | L2/L3 |
| Network | |
| IGMP snooping | Yes |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x |
| Full duplex | Yes |
| VLAN support | Yes |
| Port mirroring | Yes |
| Number of VLANs | 64 |
| Link aggregation | Yes |
| Flow control support | Yes |
| Ethernet LAN data rates | 100 Mbit/s |
| Broadcast storm control | Yes |
| 10G support | No |
| Virtual LAN features | |
| VLAN support | Yes |
| Number of VLANs | 64 |
| Data transmission | |
| Number of VLANs | 64 |
| Jumbo frames | 9216 |
| Packet buffer memory | 0.192 MB |
| MAC address table | 4000 entries |
| Switching capacity | 10 Gbit/s |
| Store-and-forward | Yes |
| Jumbo frames support | Yes |
| Performance | |
| Packet buffer memory | 0.192 MB |
| Mean time between failures (MTBF) | 1164104 h |
| Fanless | Yes |
| Technical details | |
| Product colour | Black |
| Mean time between failures (MTBF) | 1164104 h |
| Housing material | Metal |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Security | |
| Loop protection | Yes |
| IGMP snooping | Yes |
| Queue scheduling algorithms | Weighted Round Robin (WRR) |
| Password protection | Yes |
| DHCP features | DHCP client |
| Multicast features | |
| Multicast support | Yes |
| Certificates | |
| Certification | CE mark, commercial, FCC Part 15 class B, CE/EN55032/24, VCCI, ACMA, CSA safety, KC, BSMI |
| Memory | |
| Packet buffer memory | 0.192 MB |
| Design | |
| Wall mountable | Yes |
| Product colour | Black |
| LED indicators | Activity, Link, PoE, Power, Speed, System |
| Housing material | Metal |
| Certification | CE mark, commercial, FCC Part 15 class B, CE/EN55032/24, VCCI, ACMA, CSA safety, KC, BSMI |
| Indication | |
| LED indicators | Activity, Link, PoE, Power, Speed, System |
| Power over Ethernet (PoE) | |
| Power over Ethernet plus (PoE+) ports quantity | 4 |
| Power over Ethernet (PoE) ports quantity | 4 |
| Power over Ethernet (PoE) | Yes |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 70 °C |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Operating altitude | 0 - 118110.2" (0 - 3000 m) |
| Weight & dimensions | |
| Width | 6.22" (158 mm) |
| Depth | 3.98" (101 mm) |
| Height | 1.06" (27 mm) |
| Weight | 13.8 oz (390 g) |
| Packaging data | |
| Quick start guide | Yes |
| User guide | Yes |
| Manual | Yes |
| Other features | |
| Ethernet LAN data rates | 100 Mbit/s |
| Packaging content | |
| Quick start guide | Yes |
| User guide | Yes |
| Manual | Yes |
