| Technical details | |
|---|---|
| Form factor | 1U |
| Product colour | Black |
| Rack mounting | Yes |
| Master (outer) case GTIN (EAN/UPC) | 10037332194869 |
| Management features | |
| Switch type | Managed |
| Web-based management | Yes |
| Switch layer | L2 |
| Ports & interfaces | |
| SFP module slots quantity | 2 |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Network | |
| MAC address auto-learning supported | Yes |
| MAC address auto-aging supported | Yes |
| Networking standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
| Auto MDI/MDI-X | Yes |
| Data transmission | |
| Jumbo frames | 9000 |
| Switching capacity | 52 Gbit/s |
| Jumbo frames support | Yes |
| Certificates | |
| Certification | Compliant standards: IEEE 802.3ab (1000BASE-T GIGABIT ETHERNET), IEEE 802.3i (10BASE-T ETHERNET), IEEE 802.3u (100BASE-T ETHERNET), IEEE 802.3x (FULL DUPLEX/FLOW CONTROL), IEEE 802.3 (NWAY AUTO-NEGOTIATION), 802.1q (TAGGED VLAN), 802.1p (QUALITY OF SERVICE), 802.af (POE), 802.at (POE+), Tested to: UL 60950-1:2007 (2nd Ed); CAN/CSA C22.2 NO. 60950-1-07 2nd Edition, 2014-10; FCC Class A (Emissions) |
| Design | |
| Country of origin | China |
| Form factor | 1U |
| Product colour | Black |
| LED indicators | Yes |
| Certification | Compliant standards: IEEE 802.3ab (1000BASE-T GIGABIT ETHERNET), IEEE 802.3i (10BASE-T ETHERNET), IEEE 802.3u (100BASE-T ETHERNET), IEEE 802.3x (FULL DUPLEX/FLOW CONTROL), IEEE 802.3 (NWAY AUTO-NEGOTIATION), 802.1q (TAGGED VLAN), 802.1p (QUALITY OF SERVICE), 802.af (POE), 802.at (POE+), Tested to: UL 60950-1:2007 (2nd Ed); CAN/CSA C22.2 NO. 60950-1-07 2nd Edition, 2014-10; FCC Class A (Emissions) |
| Rack mounting | Yes |
| Performance | |
| Harmonized System (HS) code | 8517.62.0020 |
| Indication | |
| LED indicators | Yes |
| Power | |
| Power consumption (max) | 450 W |
| AC input voltage | 100 - 240 V |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Yes |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating altitude | 0 - 118110.2" (0 - 3000 m) |
| Weight & dimensions | |
| Width | 17.3" (439.9 mm) |
| Depth | 8.19" (208 mm) |
| Height | 1.73" (43.9 mm) |
| Weight | 6.83 lbs (3.1 kg) |
| Packaging data | |
| Rack mount kit | Yes |
| Package width | 21.9" (555 mm) |
| Package depth | 11.6" (294.9 mm) |
| Package height | 3.46" (87.9 mm) |
| Package weight | 8.71 lbs (3.95 kg) |
| Manual | Yes |
| Cables included | AC |
| Logistics data | |
| Master (outer) case width | 15" (380 mm) |
| Master (outer) case length | 22.8" (579.9 mm) |
| Master (outer) case height | 12.4" (315 mm) |
| Master (outer) case gross weight | 37 lbs (16.8 kg) |
| Products per master (outer) case | 4 pc(s) |
| Harmonized System (HS) code | 8517.62.0020 |
| Packaging content | |
| Rack mount kit | Yes |
| Manual | Yes |
| Cables included | AC |
| Other features | |
| Country of origin | China |
