N220-01K-GY - Tripp Lite 1000FT CAT6 GIGABIT CABLE STRANDED CMR PVC 24AWG GRAY 1000

Perfect Solution for High-Speed Cat6 Premise Applications Designed for do-it-yourself custom patch cable assemblies Delivers speeds up to 250 MHz/1 Gbps No center spline and overall 0.22 in. diameter makes for easy RJ45 plug termination Reduces impedance and structural return loss compared to standard 100 MHz wire Ideal for 10/100/1000 Base-T Ethernet, 100 Mbps TPDDI, 155 Mbps ATM, ISDN, voice, EIA/TIA and Token Ring Type 3 applications Premium Construction for Superior Performance Made from 24 AWG copper wire (7 x 32 AWG per conductor) 4-pair stranded UTP Minimum near-end crosstalk CMR-rated PVC jacket Meets most current industry standards, including IEEE 802.3ab, IEEE 802.5, ANSI/EIA/TIA 568, ISO/IEC 11801 and ETL (category 6, draft 11) TAA-Compliant Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases



Specification:



Technical details
Product colour	White
Cable standard	Cat6
Connector 1	No
Connector 2	No
Cabling technology	10/100/1000Base-T(X)
Data transfer rate	1000 Mbit/s
Networking standards	IEEE 802.3ab
Jacket material	Polyvinyl chloride (PVC)
Conductor type	Stranded
Cable length	12000" (304.8 m)
Country of origin	China
Sustainability certificates	RoHS
Certificates
Certification	TAA
Features
Product colour	White
Country of origin	China
Frequency	550 MHz
AWG wire size	23
Cable standard	Cat6
Connector 1	No
Connector 2	No
Cabling technology	10/100/1000Base-T(X)
Data transfer rate	1000 Mbit/s
Networking standards	IEEE 802.3ab
Jacket material	Polyvinyl chloride (PVC)
Conductor type	Stranded
Certification	TAA
Cable length	12000" (304.8 m)
Harmonized System (HS) code	8544.49.1000
Connector 2 gender	No
Connector 1 gender	No
Packaging data
Package width	13.4" (340.4 mm)
Package depth	13" (330.2 mm)
Package height	11.2" (284.5 mm)
Package weight	22.9 lbs (10.4 kg)
Quantity per pack	1 pc(s)
Logistics data
Products per master (outer) case	1 pc(s)
Master (outer) case GTIN (EAN/UPC)	10037332196597
Other features
Master (outer) case GTIN (EAN/UPC)	10037332196597
