40A40090US - Lenovo THINKPAD ONELINK+ DOCK

The ThinkPad OneLink+ Dock, powered by Lenovo€™s revolutionary OneLink+ technology transforms your new ThinkPad into a full featured machine in the office or at home. Not only does the new convenient OneLink+ connector deliver super-fast data transfers with USB 3.0 and up to Ultra High Definition (UHD) video but it also charges your notebook, cell phone and tablet while you work or play!

Unlike USB docks the OneLink+ Dock delivers video with no compression, no drivers and no impact on image quality and notebook performance. Simply connect your notebook with the ThinkPad OneLink+ Dock and get connected to power, Internet and workplace accessories through a convenient single connector. Expect nothing short of outstanding value with connections for two external displays, a keyboard, a mouse, and a printer. It also comes with a ThinkPad 90w slim tip AC Adapter.

The docking station comes equipped with a stereo/microphone combination audio port and 2x USB 3.0 ports on the front panel with one of those as an €œalways (power) on€� port for mobile device charging. Meanwhile, the rear panel has 2x USB 2.0 ports and 2x USB 3.0 ports, allowing for maximum device connectivity. The OneLink+ dock also comes with a 10/1000 Gigabit Ethernet port, one VGA port, and two DisplayPort 1.2 ports for up to 3 video outputs* with a maximum 4k2k resolution**. For security, the dock can be secured via a cable lock.

With all of these great features, the ThinkPad OneLink+ Dock actually takes up less desk space than other typical docking stations!

Features and Benefits:

- A single OneLink+ cable enables all docking functions while delivering continuous power, allowing you to boost your productivity in no time
- Up to 4k video output allows you to enjoy a vivid video experience with your brand new ThinkPad Ultrabook
- Power button on dock mirrors system power button
- Gigabit Ethernet (10/100/1000) with Boot over LAN support*** on all ThinkPad OneLink+ systems



Specification:



Ports & interfaces
Combo headphone/mic port	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	1
HDMI version	1.4
VGA (D-Sub) ports quantity	1
DisplayPorts quantity	2
DVI-D ports quantity	1
Microphone in	No
Connectivity technology	Docking
Networking
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Ethernet LAN (RJ-45) ports	1
Performance
Product colour	Black
Card reader integrated	No
Brand compatibility	Lenovo
Cable lock slot	Yes
Certification	AS / NZS S-DOC, VCCI, BSMI, KCC, NOM, GOST, CB, CE, UkrSEPRO, EC-DoC, UL, FCC
Technical details
Product colour	Black
Brand compatibility	Lenovo
Cable lock slot	Yes
Storage
Card reader integrated	No
Weight & dimensions
Weight	34.6 oz (980 g)
Width	15.8" (402.2 mm)
Depth	6.51" (165.4 mm)
Height	2.19" (55.6 mm)
Design
Product colour	Black
Cable lock slot	Yes
Certification	AS / NZS S-DOC, VCCI, BSMI, KCC, NOM, GOST, CB, CE, UkrSEPRO, EC-DoC, UL, FCC
Operational conditions
Operating temperature (T-T)	0 - 43 °C
Operating relative humidity (H-H)	0 - 95%
Certificates
Certification	AS / NZS S-DOC, VCCI, BSMI, KCC, NOM, GOST, CB, CE, UkrSEPRO, EC-DoC, UL, FCC
