| Design | |
|---|---|
| Product type | Mobile workstation |
| Form factor | Clamshell |
| Product colour | Black |
| Display | |
| HD type | WQUXGA |
| Panel type | IPS |
| LED backlight | Yes |
| Display brightness | 600 cd/m² |
| Contrast ratio (typical) | 1500:1 |
| Touchscreen | No |
| Display resolution | 3840 x 2400 pixels |
| Display diagonal | 16" |
| Anti-glare screen | Yes |
| RGB colour space | Adobe RGB |
| High Dynamic Range (HDR) technology | DisplayHDR 400, Dolby Vision |
| Colour gamut | 100% |
| Native aspect ratio | 16:10 |
| Processor | |
| Processor generation | 12th gen Intel® Core™ i7 |
| Configurable TDP-down | 35 W |
| Processor cache type | Smart Cache |
| Processor cache | 24 MB |
| Processor model | i7-12800H |
| Processor boost frequency | 4.8 GHz |
| Processor cores | 14 |
| Motherboard chipset | Intel SoC |
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i7 |
| Memory | |
| ECC | No |
| Memory form factor | SO-DIMM |
| Internal memory | 32 GB |
| Memory layout (slots x size) | 2 x 16 GB |
| Internal memory type | DDR5-SDRAM |
| Memory clock speed | 4800 MHz |
| Memory slots | 2x SO-DIMM |
| Maximum internal memory | 64 GB |
| Memory channels | Dual-channel |
| Storage | |
| SSD form factor | M.2 |
| Storage media | SSD |
| Optical drive type | No |
| Number of SSDs installed | 1 |
| SSD capacity | 1000 GB |
| SSD interface | PCI Express 4.0 |
| Card reader integrated | Yes |
| Compatible memory cards | SD |
| Total storage capacity | 1000 GB |
| Total SSDs capacity | 1000 GB |
| NVMe | Yes |
| Graphics | |
| Discrete graphics card | Yes |
| Discrete graphics card memory | 8 GB |
| On-board graphics card | Yes |
| On-board graphics card model | Intel Iris Xe Graphics |
| Discrete graphics card model | NVIDIA GeForce RTX 3070 Ti |
| Discrete graphics memory type | GDDR6 |
| Discrete GPU manufacturer | NVIDIA |
| Audio | |
| Audio chip | Realtek ALC3306 |
| Number of microphones | 2 |
| Audio system | Dolby Atmos |
| Number of built-in speakers | 2 |
| Speaker power | 2 W |
| Built-in microphone | Yes |
| Camera | |
| Front camera | Yes |
| Front camera resolution | 1920 x 1080 pixels |
| Privacy camera | Yes |
| Privacy type | Privacy shutter |
| Front camera HD type | Full HD |
| Infrared (IR) camera | Yes |
| Optical drive | |
| Optical drive type | No |
| Network | |
| Mobile network connection | No |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| Ethernet LAN | No |
| Bluetooth | Yes |
| Bluetooth version | 5.1 |
| WWAN | Not installed |
| Antenna type | 2x2 |
| WLAN controller manufacturer | Intel |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| USB Sleep-and-Charge ports | 1 |
| USB Sleep-and-Charge | Yes |
| HDMI ports quantity | 1 |
| Combo headphone/mic port | Yes |
| USB Power Delivery | Yes |
| Thunderbolt 4 ports quantity | 2 |
| Intel® Thunderbolt 4 | Yes |
| Keyboard | |
| Pointing device | ThinkPad UltraNav |
| Keyboard layout | QWERTY |
| Numeric keypad | No |
| Spill-resistant keyboard | Yes |
| Keyboard backlit | Yes |
| Keyboard language | English |
| Software | |
| Operating system language | English |
| Operating system architecture | 64-bit |
| Recovery operating system | Windows 10 Pro |
| Operating system installed | Windows 11 Pro |
| Technical details | |
| Form factor | Clamshell |
| Product colour | Black |
| Discrete graphics card memory | 8 GB |
| Processor special features | |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel Stable Image Platform Program (SIPP) | Yes |
| Intel Flex Memory Access | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Execute Disable Bit | Yes |
| Embedded options available | No |
| CPU configuration (max) | 1 |
| Intel Virtualization Technology (VT-x) | Yes |
| Battery | |
| Battery technology | Lithium Polymer (LiPo) |
| Battery capacity | 90 Wh |
| Fast charging | Yes |
| Power | |
| AC adapter power | 230 W |
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| Security | |
| Password protection | Yes |
| Cable lock slot type | Kensington |
| Trusted Platform Module (TPM) | Yes |
| Password protection type | BIOS, Power on, Supervisor, SSD |
| Fingerprint reader | Yes |
| Cable lock slot | Yes |
| Smart card reader | No |
| Trusted Platform Module (TPM) version | 2.0 |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 35 °C |
| Storage temperature (T-T) | 5 - 43 °C |
| Operating relative humidity (H-H) | 8 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
| Maximum shipping altitude | 120000" (3048 m) |
| Certificates | |
| Certification | EPEAT Gold ENERGY STAR 8.0 RoHS compliant MIL-STD-810H TÃœV |
| Weight & dimensions | |
| Width | 14.2" (359.5 mm) |
| Depth | 9.99" (253.8 mm) |
| Height | 0.697" (17.7 mm) |
| Weight | 3.99 lbs (1.81 kg) |
| Other features | |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| On-board graphics card | Yes |
| Audio system | Dolby Atmos |
| Maximum shipping altitude | 120000" (3048 m) |
| Anti-glare screen | Yes |
