| Processor |
|---|
| Processor base frequency |
2 GHz |
| Memory bandwidth supported by processor (max) |
76.8 GB/s |
| Thermal Design Power (TDP) |
105 W |
| Processor cache |
35 MB |
| Processor model |
E5-2660V4 |
| Processor threads |
28 |
| System bus rate |
9.6 GT/s |
| Processor operating modes |
64-bit |
| Processor boost frequency |
3.2 GHz |
| Stepping |
M0 |
| Number of QPI links |
2 |
| Bus type |
QPI |
| Component for |
Server/workstation |
| Processor lithography |
14 nm |
| Processor family |
Intel® Xeon® E5 v4 |
| Processor cores |
14 |
| Processor socket |
LGA 2011-v3 |
| Processor series |
Intel Xeon E5-2600 v4 |
| Processor cache type |
L3 |
| Memory |
|---|
| Memory types supported by processor |
DDR4-SDRAM |
| Memory clock speeds supported by processor |
1600,1866,2133,2400 MHz |
| Memory bandwidth supported by processor (max) |
76.8 GB/s |
| Memory channels |
Quad-channel |
| ECC |
Yes |
| Graphics |
|---|
| On-board graphics card |
No |
| Power |
|---|
| Thermal Design Power (TDP) |
105 W |
| Technical details |
|---|
| Intel TSX-NI |
Yes |
| Intel® Secure Key |
Yes |
| Thermal Monitoring Technologies |
Yes |
| Intel® Turbo Boost Technology |
2.0 |
| Intel Trusted Execution Technology |
Yes |
| Intel® Identity Protection Technology (Intel® IPT) |
No |
| Intel® Hyper Threading Technology (Intel® HT Technology) |
Yes |
| Intel Flex Memory Access |
No |
| Intel® AES New Instructions (Intel® AES-NI) |
Yes |
| Idle States |
Yes |
| Execute Disable Bit |
Yes |
| Enhanced Intel SpeedStep Technology |
Yes |
| PCI Express slots version |
3.0 |
| Supported instruction sets |
AVX 2.0 |
| Scalability |
2S |
| Physical Address Extension (PAE) |
Yes |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Intel Demand Based Switching |
Yes |
| Embedded options available |
No |
| CPU configuration (max) |
2 |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel 64 |
Yes |
| Thermal Design Power (TDP) |
105 W |
| Processor series |
Intel Xeon E5-2600 v4 |
| Physical Address Extension (PAE) |
46 bit |
| Market segment |
Server |
| Intel Virtualization Technology (VT-x) |
Yes |
| Processor cache type |
L3 |
| Features |
|---|
| Maximum number of PCI Express lanes |
40 |
| Thermal Design Power (TDP) |
105 W |
| Thermal Monitoring Technologies |
Yes |
| Idle States |
Yes |
| Execute Disable Bit |
Yes |
| PCI Express slots version |
3.0 |
| Supported instruction sets |
AVX 2.0 |
| Scalability |
2S |
| Physical Address Extension (PAE) |
Yes |
| Embedded options available |
No |
| CPU configuration (max) |
2 |
| Physical Address Extension (PAE) |
46 bit |
| Market segment |
Server |
| Processor special features |
|---|
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel 64 |
Yes |
| Conflict-Free processor |
Yes |
| Intel® OS Guard |
Yes |
| Intel TSX-NI |
Yes |
| Intel® Secure Key |
Yes |
| Intel® Turbo Boost Technology |
2.0 |
| Intel Trusted Execution Technology |
Yes |
| Intel® Identity Protection Technology (Intel® IPT) |
No |
| Intel® Hyper Threading Technology (Intel® HT Technology) |
Yes |
| Intel Flex Memory Access |
No |
| Intel® AES New Instructions (Intel® AES-NI) |
Yes |
| Enhanced Intel SpeedStep Technology |
Yes |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Intel Demand Based Switching |
Yes |
| Intel Virtualization Technology (VT-x) |
Yes |
| Intel® vPro™ Platform Eligibility |
Yes |
| Operational conditions |
|---|
| Tcase |
79 °C |
| Other features |
|---|
| CPU configuration (max) |
2 |
