BX80708W1350P - Intel XEON W-1350P WKSTN PROC 6CORE

Intel Xeon W-1350P. Processor family: Intel Xeon W, Processor socket: LGA 1200 (Socket H5), Processor lithography: 14 nm. Memory channels: Dual-channel, Memory types supported by processor: DDR4-SDRAM, Memory bandwidth (max): 50 GB/s. On-board graphics card model: Intel UHD Graphics P750, Maximum on-board graphics card memory: 64 GB, On-board graphics card base frequency: 350 MHz. Market segment: Workstation, PCI Express configurations: 1x16+1x4, 2x8+1x4, 1x8+3x4, Supported instruction sets: SSE4.1, SSE4.2, AVX 2.0, AVX-512. Intel® Turbo Boost Technology 2.0 frequency: 5.1 GHz



Specification:



Processor
Processor base frequency	2.9 GHz
Processor manufacturer	Intel
Cooler included	No
Memory bandwidth supported by processor (max)	50 GB/s
Thermal Design Power (TDP)	80 W
Processor cache	16 MB
Processor ARK ID	212265
Processor model	W-1370
Processor threads	16
System bus rate	8 GT/s
Processor operating modes	64-bit
Processor boost frequency	5.1 GHz
Component for	Server/workstation
Processor lithography	14 nm
Processor family	Intel Xeon W
Processor cores	8
Box	No
Processor socket	LGA 1200 (Socket H5)
Processor cache type	Smart Cache
Memory
Maximum internal memory supported by processor	128 GB
Memory types supported by processor	DDR4-SDRAM
Memory bandwidth supported by processor (max)	50 GB/s
Supported memory types	DDR4-SDRAM
Memory channels	Dual-channel
Memory bandwidth (max)	50 GB/s
ECC	Yes
Graphics
Discrete graphics card	No
On-board graphics card maximum resolution (DisplayPort)	5120 x 3200 pixels
Number of execution units	32
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)	5120 x 3200 pixels
On-board graphics card 4K support	Yes
On-board graphics card refresh rate at maximum resolution (HDMI)	60 Hz
On-board graphics card refresh rate at maximum resolution (DisplayPort)	60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)	60 Hz
Maximum on-board graphics card memory	64 GB
On-board graphics card maximum resolution (HDMI)	4096 x 2160 pixels
On-board graphics card OpenGL version	4.5
On-board graphics card model	Intel UHD Graphics P750
On-board graphics card	Yes
On-board graphics card dynamic frequency (max)	1300 MHz
On-board graphics card base frequency	350 MHz
Discrete graphics card model	Not available
Power
Thermal Design Power (TDP)	80 W
Technical details
Intel® Secure Key	Yes
Thermal Monitoring Technologies	Yes
Intel® Turbo Boost Technology	2.0
Intel Trusted Execution Technology	Yes
Intel® Quick Sync Video Technology	Yes
Intel® InTru™ 3D Technology	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Idle States	Yes
Execute Disable Bit	Yes
Enhanced Intel SpeedStep Technology	Yes
PCI Express slots version	4.0
PCI Express configurations	1x16+1x4, 2x8+1x4, 1x8+3x4
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0, AVX-512
Scalability	1S
Intel VT-x with Extended Page Tables (EPT)	Yes
CPU configuration (max)	1
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel 64	Yes
Thermal Design Power (TDP)	80 W
Supported memory types	DDR4-SDRAM
Status	Launched
Market segment	Workstation
Launch date	Q2'21
Intel Virtualization Technology (VT-x)	Yes
Processor cache type	Smart Cache
Features
Maximum number of PCI Express lanes	20
Thermal Design Power (TDP)	80 W
Processor package size	37.5 x 37.5 mm
Processor ARK ID	212265
Thermal Monitoring Technologies	Yes
Idle States	Yes
Execute Disable Bit	Yes
PCI Express slots version	4.0
PCI Express configurations	1x16+1x4, 2x8+1x4, 1x8+3x4
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0, AVX-512
Scalability	1S
CPU configuration (max)	1
Market segment	Workstation
Harmonized System (HS) code	85423119
Export Control Classification Number (ECCN)	5A992CN3
Commodity Classification Automated Tracking System (CCATS)	G167599
Processor special features
Intel Clear Video Technology	Yes
Intel Software Guard Extensions (Intel SGX)	No
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel 64	Yes
Intel Turbo Boost Max Technology 3.0	Yes
Intel® Optane™ Memory Ready	Yes
Intel® OS Guard	Yes
Intel® Secure Key	Yes
Intel® Turbo Boost Technology	2.0
Intel Trusted Execution Technology	Yes
Intel® Quick Sync Video Technology	Yes
Intel® InTru™ 3D Technology	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Enhanced Intel SpeedStep Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel® Boot Guard	Yes
Intel® Thermal Velocity Boost	No
Intel® Deep Learning Boost (Intel® DL Boost)	Yes
Intel® vPro™ Platform Eligibility	Yes
Intel® Gaussian & Neural Accelerator (Intel® GNA) 2.0	Yes
Intel® Turbo Boost Technology 2.0 frequency	5 GHz
Intel® Turbo Boost Max Technology 3.0 frequency	5.1 GHz
Operational conditions
Tjunction	100 °C
Packaging data
Package type	Retail box
Logistics data
Harmonized System (HS) code	85423119
Weight & dimensions
Processor package size	37.5 x 37.5 mm
Other features
Maximum internal memory	128 GB
CPU configuration (max)	1
