CD8067303406600 - Intel XEON PLATINUM 8160F

Intel Xeon 8160M. Processor family: Intel® Xeon® Platinum, Processor socket: FCLGA3647, Processor lithography: 14 nm. Memory channels: Hexa-channel, Maximum internal memory supported by processor: 1500 GB, Memory types supported by processor: DDR4-SDRAM. Market segment: Server, Supported instruction sets: SSE4.2, AVX, AVX 2.0, AVX-512, Scalability: S8S. Processor package size: 76mm x 56.5mm. Maximum internal memory: 1500 GB, Maximum internal memory: 1536000 MB



Specification:



Processor
Processor generation	1st Generation Intel® Xeon® Scalable
Processor base frequency	2 GHz
Processor manufacturer	Intel
Cooler included	No
Processor codename	Skylake
Thermal Design Power (TDP)	150 W
Processor cache	35.75 MB
Processor ARK ID	120503
Processor model	8164
Processor threads	52
Processor operating modes	64-bit
Processor boost frequency	3.7 GHz
Stepping	H0
Bus type	UPI
Component for	Server/workstation
Processor lithography	14 nm
Processor family	Intel® Xeon® Platinum
Processor cores	26
Box	No
Processor socket	FCLGA3647
Processor code	SR3BB
Processor cache type	L3
Memory
Maximum internal memory supported by processor	768 GB
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2666 MHz
Supported memory types	DDR4-SDRAM
Memory channels	Hexa-channel
ECC	Yes
Graphics
On-board graphics card	No
Power
Thermal Design Power (TDP)	150 W
Technical details
Intel TSX-NI	Yes
Intel® Turbo Boost Technology	2.0
Intel Trusted Execution Technology	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Execute Disable Bit	Yes
Enhanced Intel SpeedStep Technology	Yes
PCI Express slots version	3.0
Supported instruction sets	SSE4.2, AVX, AVX 2.0, AVX-512
Scalability	S8S
Intel VT-x with Extended Page Tables (EPT)	Yes
Embedded options available	No
Processor code	SR3BB
Product type	Processor
Processor cache	36608 KB
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel 64	Yes
Thermal Design Power (TDP)	150 W
Supported memory types	DDR4-SDRAM
Status	Launched
Market segment	Server
Launch date	Q3'17
Intel Virtualization Technology (VT-x)	Yes
Processor cache type	L3
Maximum memory	768 GB
Intel TSX-NI version	1.00
Processor brand name	Intel Xeon Platinum Intel Xeon Platinum Processor
Last change	63903513
Product family	Intel Xeon Processors
Intel® Speed Shift Technology version	1.00
Number of UPI links	3
Mode-based Execute Control (MBE) version	1.00
Memory speed (max)	2666 MHz
Intel® Volume Management Device (VMD) version	1.00
Intel® Run Sure Technology version	1.00
AVX-512 Fused Multiply-Add (FMA) units	2
Features
Maximum number of PCI Express lanes	48
Thermal Design Power (TDP)	150 W
Processor package size	76mm x 56.5mm
Processor ARK ID	120503
Execute Disable Bit	Yes
PCI Express slots version	3.0
Supported instruction sets	SSE4.2, AVX, AVX 2.0, AVX-512
Scalability	S8S
Embedded options available	No
Processor code	SR3BB
Market segment	Server
Harmonized System (HS) code	8542310001
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	G077159
PCI Express CEM revision	3.0
Processor special features
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel 64	Yes
Conflict-Free processor	Yes
Intel Turbo Boost Max Technology 3.0	No
Intel® Speed Shift Technology	Yes
Intel® Optane™ Memory Ready	No
Intel TSX-NI	Yes
Intel® Turbo Boost Technology	2.0
Intel Trusted Execution Technology	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Enhanced Intel SpeedStep Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel TSX-NI version	1.00
AVX-512 Fused Multiply-Add (FMA) units	2
Intel® Volume Management Device (VMD)	Yes
Mode-based Execute Control (MBE)	Yes
Intel® Run Sure Technology	Yes
Intel® vPro™ Platform Eligibility	Yes
Intel® Transactional Synchronization Extensions	Yes
Operational conditions
Tcase	85 °C
Packaging data
Package width	1.69" (43 mm)
Package depth	5.39" (137 mm)
Package height	4.41" (112 mm)
Package weight	7.09 oz (201 g)
Package type	Retail box
Weight & dimensions
Processor package size	76mm x 56.5mm
Package width	1.69" (43 mm)
Package depth	5.39" (137 mm)
Package height	4.41" (112 mm)
Package weight	7.09 oz (201 g)
Other features
Maximum internal memory	768 GB
Maximum internal memory	786432 MB
Processor code	SR3BB
