CD8068904691401 - Intel XEON W-3375 PROC 57M CACHE UP

Intel Xeon ® ® W-3375 Processor (57M Cache, up to 4.00 GHz). Processor family: Intel Xeon W, Processor socket: FCLGA4189, Processor lithography: 10 nm. Memory channels: Octa-channel, Maximum internal memory supported by processor: 4000 GB, Memory types supported by processor: DDR4-SDRAM. Market segment: Workstation, Supported instruction sets: AVX-512, Scalability: 1S. Processor package size: 77.5 x 56.5 mm. Maximum internal memory: 4000 GB



Specification:



Processor
Processor base frequency	3.4 GHz
Processor manufacturer	Intel
Cooler included	No
Processor codename	Ice Lake
Thermal Design Power (TDP)	250 W
Processor cache	24 MB
Processor ARK ID	217244
Processor model	W-3335
Processor threads	32
System bus rate	8 GT/s
Processor operating modes	64-bit
Processor boost frequency	4 GHz
Component for	Server/workstation
Processor lithography	10 nm
Processor family	Intel Xeon W
Processor cores	16
Box	No
Processor socket	FCLGA4189
Memory
Maximum internal memory supported by processor	4000 GB
Memory types supported by processor	DDR4-SDRAM
Supported memory types	DDR4-SDRAM
Memory channels	Octa-channel
ECC	Yes
Graphics
Discrete graphics card	No
On-board graphics card model	Not available
On-board graphics card	No
Discrete graphics card model	Not available
Power
Thermal Design Power (TDP)	250 W
Technical details
Intel® Turbo Boost Technology	2.0
Intel Trusted Execution Technology	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Execute Disable Bit	Yes
Enhanced Intel SpeedStep Technology	Yes
PCI Express slots version	4.0
Supported instruction sets	AVX-512
Scalability	1S
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel 64	Yes
Thermal Design Power (TDP)	250 W
Supported memory types	DDR4-SDRAM
Status	Launched
Market segment	Workstation
Launch date	Q3'21
Intel Virtualization Technology (VT-x)	Yes
Memory speed (max)	3200 MHz
AVX-512 Fused Multiply-Add (FMA) units	2
Features
Maximum number of PCI Express lanes	64
Thermal Design Power (TDP)	250 W
Processor package size	77.5 x 56.5 mm
Processor ARK ID	217244
Execute Disable Bit	Yes
PCI Express slots version	4.0
Supported instruction sets	AVX-512
Scalability	1S
Market segment	Workstation
Harmonized System (HS) code	85423119
Export Control Classification Number (ECCN)	5A992CN3
Commodity Classification Automated Tracking System (CCATS)	G178966
Processor special features
Intel Software Guard Extensions (Intel SGX)	No
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel 64	Yes
Intel Turbo Boost Max Technology 3.0	No
Intel® Speed Shift Technology	Yes
Intel® Turbo Boost Technology	2.0
Intel Trusted Execution Technology	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Enhanced Intel SpeedStep Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
AVX-512 Fused Multiply-Add (FMA) units	2
Intel® Volume Management Device (VMD)	Yes
Intel® Speed Select technology - Performance Profile (Intel® SST-PP)	No
Intel® Optane™ DC Persistent Memory Supported	No
Intel® Deep Learning Boost (Intel® DL Boost)	Yes
Mode-based Execute Control (MBE)	Yes
Intel® Resource Director Technology (Intel® RDT)	No
Intel® vPro™ Platform Eligibility	No
Intel® Transactional Synchronization Extensions	Yes
Intel® Total Memory Encryption	No
Operational conditions
Tcase	68 °C
Logistics data
Harmonized System (HS) code	85423119
Weight & dimensions
Processor package size	77.5 x 56.5 mm
Other features
Maximum internal memory	4000 GB
