CM8071504820606 - Intel CORE I9-13900F 36M CACHE, UP TO 5.60GHZ, TRAY

Intel Core i9-13900F. Processor family: Intel® Core™ i9, Processor socket: LGA 1700, Processor manufacturer: Intel. Memory channels: Dual-channel, Maximum internal memory supported by processor: 128 GB, Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM. Market segment: Desktop, Use conditions: PC/Client/Tablet, PCI Express slots version: 5.0, 4.0. Intel® Turbo Boost Max Technology 3.0 frequency: 5.5 GHz, Intel® Thermal Velocity Boost Frequency: 5.6 GHz. Package type: Retail box



Specification:



Processor
Processor generation	13th gen Intel® Core™ i7
Processor manufacturer	Intel
Processor codename	Raptor Lake
Memory bandwidth supported by processor (max)	89.6 GB/s
Processor cache	30 MB
Processor ARK ID	230500
Processor model	i7-13700K
Processor threads	24
Processor operating modes	64-bit
Processor boost frequency	5.4 GHz
Stepping	B0
Bus type	DMI4
Processor family	Intel® Core™ i7
Processor cores	16
Box	No
Processor socket	LGA 1700
Processor cache type	Smart Cache
Performance cores	8
Efficient cores	8
Performance-core boost frequency	5.3 GHz
Performance-core base frequency	3.4 GHz
Efficient-core boost frequency	4.2 GHz
Efficient-core base frequency	2.5 GHz
Processor base power	125 W
Maximum turbo power	253 W
Maximum number of DMI lanes	8
Memory
Maximum internal memory supported by processor	128 GB
Memory types supported by processor	DDR4-SDRAM, DDR5-SDRAM
Memory bandwidth supported by processor (max)	89.6 GB/s
Memory channels	Dual-channel
Memory bandwidth (max)	89.6 GB/s
ECC	Yes
Graphics
Discrete graphics card	No
On-board graphics card outputs supported	Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
On-board graphics card maximum resolution (DisplayPort)	7680 x 4320 pixels
Number of execution units	32
On-board graphics card ID	0xA780
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)	5120 x 3200 pixels
On-board graphics card refresh rate at maximum resolution (HDMI)	60 Hz
On-board graphics card refresh rate at maximum resolution (DisplayPort)	60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)	120 Hz
Number of displays supported (on-board graphics)	4
On-board graphics card maximum resolution (HDMI)	4096 x 2160 pixels
On-board graphics card DirectX version	12.0
On-board graphics card OpenGL version	4.5
On-board graphics card model	Intel UHD Graphics 770
On-board graphics card	Yes
On-board graphics card dynamic frequency (max)	1600 MHz
On-board graphics card base frequency	300 MHz
Discrete graphics card model	Not available
Multi-Format Codec Engines	2
Technical details
Intel® Secure Key	Yes
Thermal Monitoring Technologies	Yes
Intel® Turbo Boost Technology	2.0
Intel Trusted Execution Technology	Yes
Intel® Quick Sync Video Technology	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Idle States	Yes
Execute Disable Bit	Yes
Enhanced Intel SpeedStep Technology	Yes
PCI Express slots version	4.0, 5.0
PCI Express configurations	1x16+1x4, 2x8+1x4
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Scalability	1S
L2 cache	24576 KB
Intel VT-x with Extended Page Tables (EPT)	Yes
Embedded options available	No
CPU configuration (max)	1
Graphics output	eDP 1.4b, DP 1.4a, HDMI 2.1
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel 64	Yes
Status	Launched
Market segment	Desktop
Launch date	Q4'22
Intel Virtualization Technology (VT-x)	Yes
Processor cache type	Smart Cache
OpenCL version	3.0
Target market	Gaming, Content Creation
Features
On-board graphics card ID	0xA780
Maximum number of PCI Express lanes	20
Processor ARK ID	230500
Thermal Monitoring Technologies	Yes
Idle States	Yes
Execute Disable Bit	Yes
PCI Express slots version	4.0, 5.0
PCI Express configurations	1x16+1x4, 2x8+1x4
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Scalability	1S
Embedded options available	No
CPU configuration (max)	1
Market segment	Desktop
Harmonized System (HS) code	8542310001
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	740.17B1
Use conditions	PC/Client/Tablet, Workstation
Direct Media Interface (DMI) Revision	4.0
Processor special features
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel 64	Yes
Intel Turbo Boost Max Technology 3.0	Yes
Intel® Speed Shift Technology	Yes
Intel® OS Guard	Yes
Intel® Secure Key	Yes
Intel® Turbo Boost Technology	2.0
Intel Trusted Execution Technology	Yes
Intel® Quick Sync Video Technology	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Enhanced Intel SpeedStep Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel® Boot Guard	Yes
Intel® Volume Management Device (VMD)	Yes
Intel® Deep Learning Boost (Intel® DL Boost)	Yes
Mode-based Execute Control (MBE)	Yes
Intel® Turbo Boost Max Technology 3.0 frequency	5.4 GHz
Intel® Control-flow Enforcement Technology (CET)	Yes
Intel® Thread Director	Yes
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0	Yes
Intel® Standard Manageability (ISM)	Yes
Operational conditions
Tjunction	100 °C
Packaging data
Package type	Retail box
Logistics data
Harmonized System (HS) code	8542310001
Other features
Maximum internal memory	128 GB
L2 cache	24576 KB
CPU configuration (max)	1
Graphics output	eDP 1.4b, DP 1.4a, HDMI 2.1
