| Projector |
|---|
| Number of colours |
1.07 billion colors |
| Projector native resolution |
WXGA (1280x800) |
| Screen size compatibility |
30 - 300" |
| Projection distance |
33.9 - 417.3" (0.86 - 10.6 m) |
| Contrast ratio (typical) |
3000000:1 |
| Vertical scan range |
23 - 120 Hz |
| Horizontal scan range |
15 - 102 kHz |
| Matrix size |
0.65" |
| Keystone correction, vertical |
-40 - 40° |
| Keystone correction, horizontal |
-40 - 40° |
| Projection technology |
DMD |
| Projector brightness |
3000 ANSI lumens |
| Light source |
|---|
| Light source type |
LED |
| Service life of light source |
30000 h |
| Lens system |
|---|
| Zoom ratio |
2.0:1 |
| Zoom capability |
Yes |
| Focus |
Manual |
| Focal length range |
19.16 - 23.02 mm |
| Aperture range (F-F) |
1.6 - 1.75 |
| Throw ratio |
1.37-1.64 |
| Offset |
79% |
| Video |
|---|
| Analog signal format system |
NTSC, PAL, SECAM |
| Supported video modes |
480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
| Supported graphics resolutions |
640 x 480 (VGA), 1920 x 1080 (HD 1080) |
| Ports & interfaces |
|---|
| HDMI connector type |
Full-size |
| VGA (D-Sub) ports quantity |
1 |
| HDMI ports quantity |
2 |
| USB 2.0 ports quantity |
1 |
| Composite video in |
1 |
| Serial interface type |
RS-232 |
| PC Audio out |
Yes |
| PC Audio in |
Yes |
| HDMI version |
1.4 |
| DVI port |
No |
| Component video (YPbPr/YCbCr) in |
1 |
| AC (power) in |
Yes |
| Network |
|---|
| Smart TV |
No |
| Ethernet LAN |
Yes |
| Wi-Fi |
No |
| Ethernet LAN (RJ-45) ports |
1 |
| Storage |
|---|
| Card reader integrated |
No |
| Features |
|---|
| Interactive |
No |
| HDCP |
Yes |
| On Screen Display (OSD) |
Yes |
| On Screen Display (OSD) languages |
Arabic, Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Greek, Indonesian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese |
| Noise level |
31 dB |
| Noise level (economic mode) |
25 dB |
| Number of OSD languages |
23 |
| Multimedia |
|---|
| Built-in speaker(s) |
Yes |
| Number of built-in speakers |
1 |
| RMS rated power |
10 W |
| Design |
|---|
| Market positioning |
Presentation |
| Product type |
Standard throw projector |
| Product colour |
White |
| Placement |
Desktop, Ceiling |
| Display |
|---|
| Built-in display |
No |
| Power |
|---|
| AC input voltage |
100-240 V |
| AC input frequency |
50/60 Hz |
| Power source |
AC |
| Power consumption (typical) |
270 W |
| Power consumption (standby) |
0.5 W |
| Supplier features |
|---|
| Harmonized System (HS) code |
85286200 |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Weight & dimensions |
|---|
| Package width |
19.3" (490 mm) |
| Package depth |
14.8" (376 mm) |
| Package height |
10.6" (268 mm) |
| Weight |
11 lbs (5 kg) |
| Width |
15.2" (386 mm) |
| Depth |
10.9" (276 mm) |
| Height |
4.57" (116 mm) |
| Package weight |
15.4 lbs (7 kg) |
| Packaging content |
|---|
| Remote control included |
Yes |
| Manual |
Yes |
| Cables included |
AC, VGA |
