| Hard drive |
|---|
| Hot-swap HDD bays |
Yes |
| Optical drive |
|---|
| Optical drive type |
No |
| Software |
|---|
| Compatible operating systems |
Windows Server 2016*|Ubuntu* |
| Processor |
|---|
| Built-in processor |
No |
| Processor socket |
LGA 3647 (Socket P) |
| Number of processors supported |
2 |
| Motherboard chipset |
Intel® C624 |
| Design |
|---|
| Product type |
System |
| Product series |
Intel® Server System R1000WF Family |
| Product codename |
Wolf Pass |
| Rack-Friendly board |
Yes |
| Rack rails |
No |
| LED indicators |
Yes |
| Heat sink included |
Yes |
| Heat sink |
(2) 1U Standard Heat Sink FXXCA78X108HS |
| Product colour |
Black, Gray |
| Chassis type |
Rack (1U) |
| Memory |
|---|
| Supported memory types |
DDR4-SDRAM |
| Number of DIMM slots |
24 |
| Maximum internal memory |
7500 GB |
| Storage |
|---|
| Number of storage drives supported |
10 |
| Hot-swap HDD bays |
Yes |
| Storage drive sizes supported |
2.5" |
| Supported storage drive types |
SSD |
| SSD form factor |
M.2 |
| Performance |
|---|
| Intel Quiet System Technology (QST) |
Yes |
| Intel Flex Memory Access |
Yes |
| Intel Fast Memory Access |
Yes |
| Intel Rapid Storage Technology enterprise |
Yes |
| Internal I/O Expansion Module x8 Gen 3 |
1 |
| Intel Server Customization Technology |
Yes |
| Intel Quiet Thermal Technology |
Yes |
| Intel Efficient Power Technology |
Yes |
| Intel Build Assurance Technology |
Yes |
| Intel Advanced Management Technology |
Yes |
| Trusted Platform Module (TPM) version |
2.0 |
| Trusted Platform Module (TPM) |
Yes |
| Optical drive type |
No |
| Intel Remote Management Module Support |
Yes |
| Intel On-Demand Power Redundancy Technology |
Yes |
| Intel Intelligent Power Node Manager |
Yes |
| Compatible operating systems |
Windows Server 2016*|Ubuntu* |
| Network |
|---|
| Ethernet LAN data rates |
1000,10000 Mbit/s |
| Ethernet LAN |
Yes |
| Ports & interfaces |
|---|
| USB ports quantity |
5 |
| Serial ports quantity |
2 |
| Number of SATA connectors |
10 |
| Ethernet LAN (RJ-45) ports |
3 |
| Expansion slots |
|---|
| PCI Express x16 (Gen 3.x) slots |
2 |
| PCI Express slots version |
3.0 |
| PCI Express x24 Riser Super slots |
1 |
| PCI Express OCuLink connectors (NVMe support) |
4 |
| Features |
|---|
| Trusted Platform Module (TPM) version |
2.0 |
| Trusted Platform Module (TPM) |
Yes |
| Optical drive type |
No |
| Compatible operating systems |
Windows Server 2016*|Ubuntu* |
| Harmonized System (HS) code |
84714100 |
| Export Control Classification Number (ECCN) |
5A992C |
| Commodity Classification Automated Tracking System (CCATS) |
G157815L2 |
| Number of UPI links |
2 |
| Intel® Optane™ DC Persistent Memory technology |
Yes |
| Intel Node Manager |
Yes |
| Backplanes |
Included |
| Intel® Optane™ DC Persistent Memory Supported |
Yes |
| Product codename |
Wolf Pass |
| Technical details |
|---|
| USB ports quantity |
5 |
| Product type |
System |
| PCI Express x16 (Gen 3.x) slots |
2 |
| Number of storage drives supported |
10 |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Connector for Intel I/O Expansion Module x8 Gen 3 |
1 |
| Intel Server Customization Technology |
Yes |
| Intel Quiet Thermal Technology |
Yes |
| Intel Efficient Power Technology |
Yes |
| Intel Build Assurance Technology |
Yes |
| Intel Advanced Management Technology |
Yes |
| Trusted Platform Module (TPM) version |
2.0 |
| Trusted Platform Module (TPM) |
Yes |
| Rack-Friendly board |
Yes |
| Rack rails |
No |
| Intel Remote Management Module Support |
Yes |
| Intel On-Demand Power Redundancy Technology |
Yes |
| Intel Intelligent Power Node Manager |
Yes |
| Heat sink included |
Yes |
| Heat sink |
(2) 1U Standard Heat Sink FXXCA78X108HS |
| CPU configuration (max) |
2 |
| Chassis type |
Rack (1U) |
| Target market |
Mainstream |
| Supported RAID configuration |
SW RAID 0/1/10 (5 optional) |
| Supported board |
Intel Server Board S2600WFTR |
| Status |
Launched |
| Riser slot 2 number of lanes |
24 |
| Riser slot 1 number of lanes |
24 |
| Redundant fans |
No |
| Optical drive supported |
Yes |
| Launch date |
Q2'19 |
| Included riser slot 1 configuration(s) |
1x PCIe Gen3 x16 |
| Extended warranty available for purchase (select countries) |
Yes |
| Expected discontinuance date |
2023 |
| Riser Slot 2 configuration |
1x PCIe Gen3 x16 |
| PCI Express x24 Riser Super slots |
1 |
| Harmonized System (HS) code |
84714100 |
| Export Control Classification Number (ECCN) |
5A992C |
| Commodity Classification Automated Tracking System (CCATS) |
G157815L2 |
| Colour |
|---|
| Product colour |
Black, Gray |
| Indication |
|---|
| LED indicators |
Yes |
| Processor special features |
|---|
| Intel Quiet System Technology (QST) |
Yes |
| Intel Flex Memory Access |
Yes |
| Intel Fast Memory Access |
Yes |
| Intel Rapid Storage Technology enterprise |
Yes |
| Internal I/O Expansion Module x8 Gen 3 |
1 |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Connector for Intel I/O Expansion Module x8 Gen 3 |
1 |
| Intel Server Customization Technology |
Yes |
| Intel Quiet Thermal Technology |
Yes |
| Intel Efficient Power Technology |
Yes |
| Intel Build Assurance Technology |
Yes |
| Intel Advanced Management Technology |
Yes |
| Intel Remote Management Module Support |
Yes |
| Intel On-Demand Power Redundancy Technology |
Yes |
| Intel Intelligent Power Node Manager |
Yes |
| Intel® Optane™ Memory Ready |
No |
| Power |
|---|
| Redundant power supply (RPS) support |
Yes |
| Power supply type |
AC |
| Power supply |
1100 W |
| Number of power supply units |
1 |
| Thermal Design Power (TDP) |
165 W |
| Weight & dimensions |
|---|
| Width |
16.9" (430 mm) |
| Height |
1.72" (43.7 mm) |
| Depth |
28" (710 mm) |
| Other features |
|---|
| Product type |
System |
| On-board graphics card |
No |
| CPU configuration (max) |
2 |
| Product series |
Intel® Server System R1000WF Family |
| Product codename |
Wolf Pass |
| Target market |
Mainstream |
| Supported RAID configuration |
SW RAID 0/1/10 (5 optional) |
| Supported board |
Intel Server Board S2600WFTR |
| Status |
Launched |
| Riser slot 2 number of lanes |
24 |
| Riser slot 1 number of lanes |
24 |
| Redundant fans |
No |
| Optical drive supported |
Yes |
| Launch date |
Q2'19 |
| Included riser slot 1 configuration(s) |
1x PCIe Gen3 x16 |
| Extended warranty available for purchase (select countries) |
Yes |
| Expected discontinuance date |
2023 |
| Riser Slot 2 configuration |
1x PCIe Gen3 x16 |
