| Hard drive |
|---|
| RAID levels |
0, 1 |
| Hot-swap HDD bays |
Yes |
| Software |
|---|
| Compatible operating systems |
Windows Server 2016*|Ubuntu* |
| Processor |
|---|
| Built-in processor |
No |
| Processor socket |
LGA 3647 (Socket P) |
| Number of processors supported |
2 |
| Motherboard chipset |
Intel® C628 |
| Design |
|---|
| Product type |
System |
| Product series |
Intel® Server System R2000WF Family |
| Product codename |
Wolf Pass |
| Rack-Friendly board |
Yes |
| Rack rails |
No |
| LED indicators |
Yes |
| Heat sink included |
Yes |
| Heat sink |
(2) FXXCA78X108HS |
| Product colour |
Black, Gray |
| Chassis type |
Rack (2U) |
| Memory |
|---|
| Supported memory types |
DDR4-SDRAM |
| Number of DIMM slots |
24 |
| Maximum internal memory |
6000 GB |
| Storage |
|---|
| Number of storage drives supported |
12 |
| Number of 2.5" bays |
10 |
| RAID levels |
0, 1 |
| Hot-swap HDD bays |
Yes |
| Storage drive sizes supported |
2.5,M.2 |
| SSD form factor |
M.2 |
| Performance |
|---|
| Intel Quiet System Technology (QST) |
Yes |
| Intel Rapid Storage Technology enterprise |
Yes |
| Internal I/O Expansion Module x8 Gen 3 |
1 |
| Intel Server Customization Technology |
Yes |
| Intel Quiet Thermal Technology |
Yes |
| Intel Efficient Power Technology |
Yes |
| Intel Build Assurance Technology |
Yes |
| Intel Advanced Management Technology |
Yes |
| Trusted Platform Module (TPM) version |
2.0 |
| Trusted Platform Module (TPM) |
Yes |
| Intel Remote Management Module Support |
Yes |
| Intel On-Demand Power Redundancy Technology |
Yes |
| Intel Intelligent Power Node Manager |
Yes |
| Compatible operating systems |
Windows Server 2016*|Ubuntu* |
| Ports & interfaces |
|---|
| USB ports quantity |
5 |
| Serial ports quantity |
2 |
| Number of SATA connectors |
2 |
| Ethernet LAN (RJ-45) ports |
1 |
| Expansion slots |
|---|
| PCI Express x8 (Gen 3.x) slots |
3 |
| PCI Express x4 (Gen 3.x) slots |
1 |
| PCI Express x16 (Gen 3.x) slots |
2 |
| PCI Express x24 Riser Super slots |
2 |
| PCI Express OCuLink connectors (NVMe support) |
2 |
| Features |
|---|
| Trusted Platform Module (TPM) version |
2.0 |
| Trusted Platform Module (TPM) |
Yes |
| Compatible operating systems |
Windows Server 2016*|Ubuntu* |
| Harmonized System (HS) code |
84714100 |
| Export Control Classification Number (ECCN) |
5A992C |
| Commodity Classification Automated Tracking System (CCATS) |
G157815L2 |
| Number of UPI links |
2 |
| Intel® Optane™ DC Persistent Memory technology |
Yes |
| Intel Node Manager |
Yes |
| Backplanes |
Included |
| Intel® Optane™ DC Persistent Memory Supported |
Yes |
| Product codename |
Wolf Pass |
| Technical details |
|---|
| USB ports quantity |
5 |
| Product type |
System |
| PCI Express x8 (Gen 3.x) slots |
3 |
| PCI Express x4 (Gen 3.x) slots |
1 |
| PCI Express x16 (Gen 3.x) slots |
2 |
| Number of storage drives supported |
12 |
| Number of 2.5" bays |
10 |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel Server Customization Technology |
Yes |
| Intel Quiet Thermal Technology |
Yes |
| Intel Efficient Power Technology |
Yes |
| Intel Build Assurance Technology |
Yes |
| Intel Advanced Management Technology |
Yes |
| Trusted Platform Module (TPM) version |
2.0 |
| Trusted Platform Module (TPM) |
Yes |
| Rack-Friendly board |
Yes |
| Rack rails |
No |
| Intel Remote Management Module Support |
Yes |
| Intel On-Demand Power Redundancy Technology |
Yes |
| Intel Intelligent Power Node Manager |
Yes |
| Heat sink included |
Yes |
| Heat sink |
(2) FXXCA78X108HS |
| CPU configuration (max) |
2 |
| Chassis type |
Rack (2U) |
| Target market |
Mainstream |
| Supported RAID configuration |
SW RAID 0, 1 |
| Supported board |
Intel Server Board S2600WFQR |
| Status |
Launched |
| Riser slot 2 number of lanes |
24 |
| Riser slot 1 number of lanes |
24 |
| Redundant fans |
Yes |
| Optical drive supported |
Yes |
| Launch date |
Q2'19 |
| Included riser slot 1 configuration(s) |
3x PCIe Gen3 x8 |
| Extended warranty available for purchase (select countries) |
Yes |
| Expected discontinuance date |
2023 |
| Riser slot 3 number of lanes |
12 |
| Riser Slot 2 configuration |
3x PCIe Gen3 x8 |
| PCI Express x24 Riser Super slots |
2 |
| Riser slot 3 configuration |
1x PCIe Gen3 x8 + 1x PCIe Gen2 x4 |
| Harmonized System (HS) code |
84714100 |
| Export Control Classification Number (ECCN) |
5A992C |
| Commodity Classification Automated Tracking System (CCATS) |
G157815L2 |
| Colour |
|---|
| Product colour |
Black, Gray |
| Indication |
|---|
| LED indicators |
Yes |
| Processor special features |
|---|
| Intel Quiet System Technology (QST) |
Yes |
| Intel Rapid Storage Technology enterprise |
Yes |
| Internal I/O Expansion Module x8 Gen 3 |
1 |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel Server Customization Technology |
Yes |
| Intel Quiet Thermal Technology |
Yes |
| Intel Efficient Power Technology |
Yes |
| Intel Build Assurance Technology |
Yes |
| Intel Advanced Management Technology |
Yes |
| Intel Remote Management Module Support |
Yes |
| Intel On-Demand Power Redundancy Technology |
Yes |
| Intel Intelligent Power Node Manager |
Yes |
| Intel® Optane™ Memory Ready |
No |
| Power |
|---|
| Redundant power supply (RPS) support |
Yes |
| Power supply type |
AC |
| Power supply |
1300 W |
| Number of power supply units |
1 |
| Thermal Design Power (TDP) |
205 W |
| Other features |
|---|
| Product type |
System |
| On-board graphics card |
No |
| CPU configuration (max) |
2 |
| Product series |
Intel® Server System R2000WF Family |
| Product codename |
Wolf Pass |
| Target market |
Mainstream |
| Supported RAID configuration |
SW RAID 0, 1 |
| Supported board |
Intel Server Board S2600WFQR |
| Status |
Launched |
| Riser slot 2 number of lanes |
24 |
| Riser slot 1 number of lanes |
24 |
| Redundant fans |
Yes |
| Optical drive supported |
Yes |
| Launch date |
Q2'19 |
| Included riser slot 1 configuration(s) |
3x PCIe Gen3 x8 |
| Extended warranty available for purchase (select countries) |
Yes |
| Expected discontinuance date |
2023 |
| Riser slot 3 number of lanes |
12 |
| Riser Slot 2 configuration |
3x PCIe Gen3 x8 |
| Riser slot 3 configuration |
1x PCIe Gen3 x8 + 1x PCIe Gen2 x4 |
