Description
Integrated graphics allow for incredible visual quality, faster graphic performance and flexible display options without the need for a separate graphics card. The Intel® Remote Management Module (Intel® RMM) allows you to securely gain access and control servers and other devices from any machine on the network. Remote access includes remote management capability, including power control, KVM, and media redirection, with a dedicated management network interface card (NIC). Intel® Intelligent Power Node Manager is a platform resident technology that enforces power and thermal policies for the platform. It enables data center power and thermal management by exposing an external interface to management software through which platform policies can be specified. It also enables specific data center power management usage models such as power limiting.
Specification:
| Hard drive | |
|---|---|
| RAID levels | 0, 1, 10 |
| Hot-swap HDD bays | Yes |
| Software | |
| Compatible operating systems | Windows Server 2016*|Ubuntu* |
| Processor | |
| Built-in processor | No |
| Processor socket | LGA 3647 (Socket P) |
| Number of processors supported | 2 |
| Motherboard chipset | Intel® C624 |
| Design | |
| Product type | System |
| Product series | Intel® Server System R2000WF Family |
| Product codename | Wolf Pass |
| Rack-Friendly board | Yes |
| Rack rails | No |
| LED indicators | Yes |
| Heat sink included | Yes |
| Heat sink | (2) FXXCA78X108HS |
| Product colour | Black, Gray |
| Chassis type | Rack (2U) |
| Memory | |
| Supported memory types | DDR4-SDRAM |
| Number of DIMM slots | 24 |
| Maximum internal memory | 6000 GB |
| Storage | |
| Number of storage drives supported | 12 |
| Number of 2.5" bays | 10 |
| RAID levels | 0, 1, 10 |
| Hot-swap HDD bays | Yes |
| Storage drive sizes supported | 2.5,M.2 |
| SSD form factor | M.2 |
| Performance | |
| Intel Quiet System Technology (QST) | Yes |
| Intel Flex Memory Access | Yes |
| Intel Fast Memory Access | Yes |
| Intel Rapid Storage Technology enterprise | Yes |
| Internal I/O Expansion Module x8 Gen 3 | 1 |
| Intel Server Customization Technology | Yes |
| Intel Quiet Thermal Technology | Yes |
| Intel Efficient Power Technology | Yes |
| Intel Build Assurance Technology | Yes |
| Intel Advanced Management Technology | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Trusted Platform Module (TPM) | Yes |
| Intel Remote Management Module Support | Yes |
| Intel On-Demand Power Redundancy Technology | Yes |
| Intel Intelligent Power Node Manager | Yes |
| Compatible operating systems | Windows Server 2016*|Ubuntu* |
| Network | |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Ports & interfaces | |
| USB ports quantity | 5 |
| Serial ports quantity | 2 |
| Number of SATA connectors | 10 |
| Ethernet LAN (RJ-45) ports | 1 |
| Expansion slots | |
| PCI Express x8 (Gen 3.x) slots | 3 |
| PCI Express x4 (Gen 3.x) slots | 1 |
| PCI Express x16 (Gen 3.x) slots | 2 |
| PCI Express x24 Riser Super slots | 2 |
| PCI Express OCuLink connectors (NVMe support) | 4 |
| Features | |
| Trusted Platform Module (TPM) version | 2.0 |
| Trusted Platform Module (TPM) | Yes |
| Compatible operating systems | Windows Server 2016*|Ubuntu* |
| Harmonized System (HS) code | 84714100 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G157815L2 |
| Number of UPI links | 2 |
| Intel® Optane™ DC Persistent Memory technology | Yes |
| Intel Node Manager | Yes |
| Backplanes | Included |
| Intel® Optane™ DC Persistent Memory Supported | Yes |
| Product codename | Wolf Pass |
| Technical details | |
| USB ports quantity | 5 |
| Product type | System |
| PCI Express x8 (Gen 3.x) slots | 3 |
| PCI Express x4 (Gen 3.x) slots | 1 |
| PCI Express x16 (Gen 3.x) slots | 2 |
| Number of storage drives supported | 12 |
| Number of 2.5" bays | 10 |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Server Customization Technology | Yes |
| Intel Quiet Thermal Technology | Yes |
| Intel Efficient Power Technology | Yes |
| Intel Build Assurance Technology | Yes |
| Intel Advanced Management Technology | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Trusted Platform Module (TPM) | Yes |
| Rack-Friendly board | Yes |
| Rack rails | No |
| Intel Remote Management Module Support | Yes |
| Intel On-Demand Power Redundancy Technology | Yes |
| Intel Intelligent Power Node Manager | Yes |
| Heat sink included | Yes |
| Heat sink | (2) FXXCA78X108HS |
| CPU configuration (max) | 2 |
| Chassis type | Rack (2U) |
| Target market | Mainstream |
| Supported RAID configuration | SW RAID 0, 1, 10, optional 5 |
| Supported board | Intel Server Board S2600WF0R |
| Status | Launched |
| Riser slot 2 number of lanes | 24 |
| Riser slot 1 number of lanes | 24 |
| Redundant fans | Yes |
| Optical drive supported | Yes |
| Launch date | Q2'19 |
| Included riser slot 1 configuration(s) | 3x PCIe Gen3 x8 |
| Extended warranty available for purchase (select countries) | Yes |
| Expected discontinuance date | 2023 |
| Riser slot 3 number of lanes | 12 |
| Riser Slot 2 configuration | 3x PCIe Gen3 x8 |
| PCI Express x24 Riser Super slots | 2 |
| Riser slot 3 configuration | 1x PCIe Gen3 x8 + 1x PCIe Gen2 x4 |
| Harmonized System (HS) code | 84714100 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G157815L2 |
| Colour | |
| Product colour | Black, Gray |
| Indication | |
| LED indicators | Yes |
| Processor special features | |
| Intel Quiet System Technology (QST) | Yes |
| Intel Flex Memory Access | Yes |
| Intel Fast Memory Access | Yes |
| Intel Rapid Storage Technology enterprise | Yes |
| Internal I/O Expansion Module x8 Gen 3 | 1 |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Server Customization Technology | Yes |
| Intel Quiet Thermal Technology | Yes |
| Intel Efficient Power Technology | Yes |
| Intel Build Assurance Technology | Yes |
| Intel Advanced Management Technology | Yes |
| Intel Remote Management Module Support | Yes |
| Intel On-Demand Power Redundancy Technology | Yes |
| Intel Intelligent Power Node Manager | Yes |
| Intel® Optane™ Memory Ready | No |
| Power | |
| Redundant power supply (RPS) support | Yes |
| Power supply type | AC |
| Power supply | 1300 W |
| Number of power supply units | 1 |
| Thermal Design Power (TDP) | 205 W |
| Other features | |
| Product type | System |
| On-board graphics card | No |
| CPU configuration (max) | 2 |
| Product series | Intel® Server System R2000WF Family |
| Product codename | Wolf Pass |
| Target market | Mainstream |
| Supported RAID configuration | SW RAID 0, 1, 10, optional 5 |
| Supported board | Intel Server Board S2600WF0R |
| Status | Launched |
| Riser slot 2 number of lanes | 24 |
| Riser slot 1 number of lanes | 24 |
| Redundant fans | Yes |
| Optical drive supported | Yes |
| Launch date | Q2'19 |
| Included riser slot 1 configuration(s) | 3x PCIe Gen3 x8 |
| Extended warranty available for purchase (select countries) | Yes |
| Expected discontinuance date | 2023 |
| Riser slot 3 number of lanes | 12 |
| Riser Slot 2 configuration | 3x PCIe Gen3 x8 |
| Riser slot 3 configuration | 1x PCIe Gen3 x8 + 1x PCIe Gen2 x4 |
