Superb Picture Quality with Ultra HD Resolution With the resolution of UHD, it makes the color and details of the contents vivid and realistic. In addition, the wide viewing angle applied with an IPS panel, provides clear contents.
Sophisticated Slim Design This series is thin in bezel size and thickness*, which saves space and enables easy installation. In addition, it increases the immersive experience from the screen and provides a sophisticated design, improving the décor of the space where the product is installed. * Compared to LG's UL3G series
High Performance with LG webOS 6.0 LG webOS 6.0, upgraded in SoC* and web engine, is available on UL3J series for a smooth execution of several tasks. LG webOS smart signage platform enhances user convenience with intuitive GUI.** * SoC : System On Chip ** GUI : Graphical User Interface
Various Sensor Connection LG webOS smart signage platform helps to easily provide value-added solutions* by supporting simple connections with external sensors** such as GPIO, NFC/RFID, temperature sensors, etc., via USB plug-in. * e.g. showing specific promotional information according to weather change to store visitors ** External sensors need to be purchased separately and tested for compatibility with webOS platform.
LG's Simple Advertisement Helper, Promota Using LG's Promota* application, downloadable on a mobile device, you can easily create your own display contents. With Promota, you can add text and images to create an online profile for your business as well as deliver information such as event news, seasonal menus, promotions, and even more to your customers while recommending easy-to-use templates relevant to your industry. * LG Promota is can be downloaded from the App Store and Google Play store. (Not available for Europe/CIS Region)
LG’s Wireless Screen Sharing Solution, LG One:Quick Share LG One:Quick Share is a wireless screen sharing solution available through the UL3J series, USB transmission unit, and its app. You can simply share personal PC screen to the display with it's USB dongle button and embedded Wi-Fi*, and can adjust the basic setting values (volume, picture mode, auto bright, etc.) of the connected display without a remote control. Also, the Office Meeting Mode** helps you to display the agenda, note before the meeting starts. * Users need to set up Soft AP enabled at Network Menu of the Signage. ** Users can enable Office Meeting Mode at EZ Setting Menu of the Signage. *** LG One:Quick Share needs to be purchased separately.
Remote Monitoring and Control This web-based monitoring solution is user-friendly and allows the user to be at ease. It enables the user to have full access anywhere at anytime from their mobile phone & PC under network-accessible environment while having access to both current and past data. It allows the user to monitor the unit, make adjustments and control the unit remotely in real time.
Compatible with AV Control Systems The UL3J series supports Crestron Connected* for high compatibility with professional AV controls to achieve seamless integration and automated control**, boosting business management efficiency. * Initial setting from display is required for Crestron Connected® compatibility. ** Network based control
Easy Menu Setup for Vertical Needs UL3J series increases users' convenience by organizing frequently used menus* by industry. * Pre-set Support Vertical : Corporate / Government / Retail, Meeting room
Easy Content Distribution & SW Update UL3J series features embedded Wi-Fi making it easy to distribute content wirelessly and update Firmware under the same network.
Wireless Access Point UL3J series operates as a virtual router which can be an wireless access point for mobile devices.
Built-in Speaker Contents will be enriched with sound effects from built-in speakers, without the need for purchasing or installing external speakers.
REAL-TIME LG ConnectedCare Service Maintenance is easy and fast with the optional LG ConnectedCare* service, a cloud service solution provided by LG. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, supporting the stable operation of clients' businesses. * The availability of the 'LG ConnectedCare' service differs by region, and it needs to be purchased separately. So please contact the LG sales representative in your region for more details.
Specification:
| Display |
|---|
| Touchscreen |
No |
| Display technology |
LED |
| Display diagonal |
86" |
| Display resolution |
3840 x 2160 pixels |
| Display brightness |
330 cd/m² |
| HD type |
4K Ultra HD |
| Response time |
5 ms |
| Panel life |
30000 h |
| High Dynamic Range (HDR) technology |
High Dynamic Range 10 Pro (HDR10 Pro) |
| High Dynamic Range (HDR) supported |
Yes |
| Native refresh rate |
120 Hz |
| Ports & interfaces |
|---|
| USB port |
Yes |
| HDMI version |
2.0 |
| RS-232C |
Yes |
| Infrared data port |
Yes |
| Ethernet LAN |
Yes |
| HDMI ports quantity |
3 |
| Ethernet LAN (RJ-45) ports |
1 |
| RS-232 interface |
Yes |
| USB version |
2.0 |
| USB ports quantity |
1 |
| HDMI input ports quantity |
3 |
| Audio |
|---|
| Number of built-in speakers |
2 |
| RMS rated power |
20 W |
| Built-in speaker(s) |
Yes |
| Speaker impedance |
8 Ω |
| Design |
|---|
| Product design |
Digital signage flat panel |
| Bezel width (top) |
62.6" (159 cm) |
| Bezel width (side) |
62.6" (159 cm) |
| Bezel width (bottom) |
78.3" (199 cm) |
| Product colour |
Blue, Navy |
| Panel mounting interface |
600 x 400 mm |
| VESA mounting |
Yes |
| Performance |
|---|
| Analog signal format system |
NTSC |
| Digital signal format system |
ATSC |
| Browsing |
Yes |
| Hybrid Log-Gamma (HLG) |
Yes |
| High Dynamic Range 10 (HDR10) |
Yes |
| Panel life |
30000 h |
| Power |
|---|
| Power consumption (typical) |
313 W |
| Power consumption (standby) |
0.5 W |
| AC input voltage |
120 V |
| AC input frequency |
50 - 60 Hz |
| Input voltage |
120 V |
| Computer system |
|---|
| Operating system installed |
Web OS |
| Weight & dimensions |
|---|
| Width (with stand) |
75.9" (1927 mm) |
| Height (with stand) |
45.9" (1167 mm) |
| Depth (with stand) |
14.3" (362 mm) |
| Width |
75.9" (1927 mm) |
| Depth |
23.6" (599 mm) |
| Height |
43.5" (1104 mm) |
| Weight |
99.6 lbs (45.2 kg) |
| Weight (with stand) |
101.2 lbs (45.9 kg) |
| Packaging data |
|---|
| Package width |
83.3" (2115 mm) |
| Package depth |
8.98" (228 mm) |
| Package height |
47.8" (1215 mm) |
| Package weight |
128.7 lbs (58.4 kg) |
| Remote control included |
Yes |
| Remote control type |
L-Con |
| Cables included |
AC, RS-232 |
| Packaging content |
|---|
| Remote control included |
Yes |
| Remote control type |
L-Con |
| Cables included |
AC, RS-232 |
| Technical details |
|---|
| VESA mounting |
Yes |
| Weight (with stand) |
101.2 lbs (45.9 kg) |
| Real Time Clock (RTC) |
Yes |
| Thin Client |
|---|
| Operating system installed |
Web OS |
| Other features |
|---|
| Width (with stand) |
75.9" (1927 mm) |
| Height (with stand) |
45.9" (1167 mm) |
| Display technology |
LED |
| Depth (with stand) |
14.3" (362 mm) |
| Bezel width (top) |
62.6" (159 cm) |
| Bezel width (side) |
62.6" (159 cm) |
| Bezel width (bottom) |
78.3" (199 cm) |
| Weight (with stand) |
101.2 lbs (45.9 kg) |
| Input voltage |
120 V |
