| Processor | |
|---|---|
| Processor generation | 1st Generation Intel® Xeon® Scalable |
| Stepping | U0 |
| Processor operating modes | 64-bit |
| Processor lithography | 14 nm |
| Processor codename | Skylake |
| Number of QPI links | 2 |
| Bus type | UPI |
| Maximum internal memory supported by processor | 768 GB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2400 MHz |
| Thermal Design Power (TDP) | 85 W |
| Tcase | 78 °C |
| Maximum number of PCI Express lanes | 48 |
| ECC supported by processor | Yes |
| Processor cache type | L3 |
| Conflict-Free processor | Yes |
| Processor cache | 13.75 MB |
| Processor frequency | 2.2 GHz |
| Processor model | 4114 |
| Number of processors installed | 1 |
| Processor manufacturer | Intel |
| Processor boost frequency | 3 GHz |
| Processor socket | LGA 3647 (Socket P) |
| Processor threads | 20 |
| Processor cores | 10 |
| PCI Express slots version | 3.0 |
| Processor family | Intel® Xeon® |
| Memory | |
| Non-ECC | No |
| ECC | Yes |
| Internal memory | 16 GB |
| Memory layout (slots x size) | 2 x 8 GB |
| Maximum internal memory | 384 GB |
| Memory slots | 12x DIMM |
| Internal memory type | DDR4-SDRAM |
| Memory clock speed | 2666 MHz |
| Memory channels | Hexa-channel |
| Storage | |
| Intel® Optane™ Memory module installed | No |
| Storage media | SSD |
| Number of storage drives installed | 1 |
| RAID support | Yes |
| Optical drive type | DVD±RW |
| SSD interface | M.2 |
| SSD capacity | 512 GB |
| RAID levels | 0,1,5,6,10 |
| Number of SSDs installed | 1 |
| Card reader integrated | Yes |
| Total storage capacity | 512 GB |
| Optical drive | |
| Optical drive type | DVD±RW |
| Optical drives quantity | 1 |
| Network | |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Bluetooth | No |
| Wake-on-LAN ready | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Ports & interfaces | |
| Combo headphone/mic port | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 8 |
| Number of speaker outputs | 3 |
| USB 2.0 ports quantity | 2 |
| PS/2 ports quantity | 2 |
| Microphone in | Yes |
| Line-out | Yes |
| Line-in | Yes |
| Headphone outputs | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| DVI port | No |
| On/off button | Yes |
| Expansion slots | |
| PCI Express x16 (Gen 3.x) slots | 3 |
| PCI slots | 1 |
| PCI Express x8 slots | 1 |
| PCI Express x4 slots | 1 |
| PCI Express slots version | 3.0 |
| Technical details | |
| Intel 64 | Yes |
| Cable lock slot type | Kensington |
| Product type | Workstation |
| Trusted Platform Module (TPM) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Product colour | Black |
| Chassis type | Tower |
| Audio system | High Definition Audio |
| Placement supported | Vertical |
| Number of 5.25" bays | 2 |
| Cable lock slot | Yes |
| Audio output channels | 5.1 channels |
| Motherboard chipset | Intel® C621 |
| Sustainability certificates | RoHS, EPEAT Gold, ENERGY STAR |
| Design | |
| Volume | 36 L |
| Cable lock slot type | Kensington |
| Product colour | Black |
| Chassis type | Tower |
| Placement supported | Vertical |
| Number of 5.25" bays | 2 |
| Cable lock slot | Yes |
| Viewing window | No |
| Performance | |
| Embedded options available | No |
| BIOS type | UEFI |
| Audio chip | Realtek ALC662 |
| Password protection | Yes |
| Password protection type | Supervisor |
| Product type | Workstation |
| Trusted Platform Module (TPM) | Yes |
| Audio system | High Definition Audio |
| Audio output channels | 5.1 channels |
| Motherboard chipset | Intel® C621 |
| Software | |
| Operating system architecture | 64-bit |
| Operating system installed | Windows 10 Pro |
| Processor special features | |
| Embedded options available | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel TSX-NI | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Execute Disable Bit | Yes |
| Supported instruction sets | AVX,AVX 2.0,AVX-512,SSE4.2 |
| Scalability | 2S |
| Processor package size | 76.0 x 56.5 mm |
| Processor code | SR3GK |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel TSX-NI version | 1.00 |
| Conflict-Free processor | Yes |
| Processor ARK ID | 123550 |
| Intel 64 | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Power | |
| 80 PLUS certification | 80 PLUS Platinum |
| Power supply input frequency | 50 - 60 Hz |
| Power supply input voltage | 100 - 240 V |
| Power supply | 900 W |
| Operational conditions | |
| Operating altitude | 0 - 120000" (0 - 3048 m) |
| Storage temperature (T-T) | -10 - 60 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 10 - 35 °C |
| Sustainability | |
| Sustainability certificates | RoHS, EPEAT Gold, ENERGY STAR |
| Weight & dimensions | |
| Volume | 36 L |
| Width | 6.89" (175 mm) |
| Depth | 19.1" (485 mm) |
| Height | 17.6" (446 mm) |
| Packaging content | |
| Manual | Yes |
| Display included | No |
| Other features | |
| Trusted Platform Module (TPM) | Yes |
| Optical drives quantity | 1 |
| Processor manufacturer | Intel |
