11AV0000US - Lenovo TC M75S-1,W10P,RYZEN5,8GB,1TB,3YR

Raising the bar, & then some The ThinkCentre M75s is equipped with up to AMD Ryzen™ 5 PRO processing, plus seamless AMD Radeon™ Vega graphics and lightning-fast DDR4 memory. That means it can breeze through any task—quickly, smoothly, and efficiently. SSD or HDD? It's your call With the ThinkCentre M75s comes choice: The latest PCIe solid state drive storage, backed by state-of-the-art 3D NAND technology, for apps that load faster and files that open at super-fast speeds. Your data, your business That’s why there’s a TPM 2.0 chip to encrypt critical data and enable hardware authentication. Smart USB Protection restricts port access and ensures nothing malicious gets in, and AMD GuardMI technology counters cyber-attacks and other threats. Built-in connectivity & convenience With the ThinkCentre M75s, you’re more than ready. Smart Power-On allows you to use a keyboard or mouse to turn on your PC wherever it is stored. And there are various other ports, including USB 3.1, VGA, and DisplayPort™, for easy connectivity and multitasking. Easier on the planet & your pocket With its energy efficiency and green certifications, such as Energy® Star 7.0 and EPEAT™ Silver, the ThinkCentre M75s will generate cost savings with lower utility bills. It's also MIL-SPEC tested for durability and reliability. Because IT managers need a hand, too With the DASH Manageability tool, remote device management is a breeze, along with virus patching and updating drivers. Asset inventory management, BIOS updates, and diagnostics are also easier.



Specification:



Processor
Processor cache	32 MB
Processor frequency	3.6 GHz
Processor model	3600
Number of processors installed	1
Processor manufacturer	AMD
Processor boost frequency	4.2 GHz
Processor cores	6
Processor family	AMD Ryzen 5 PRO
Memory
Non-ECC	Yes
ECC	No
Internal memory	8 GB
Memory layout (slots x size)	1 x 8 GB
Maximum internal memory	64 GB
Memory slots	4x DIMM
Internal memory type	DDR4-SDRAM
Memory channels	Dual-channel
Storage
Storage media	SSD
Number of storage drives installed	1
Optical drive type	DVD±RW
SSD interface	PCI Express
Number of SSDs installed	1
Card reader integrated	No
Total storage capacity	256 GB
SSD form factor	M.2
Graphics
Discrete graphics adapter	Yes
Discrete graphics adapter memory	2 GB
On-board graphics adapter	No
Discrete graphics adapter model	AMD Radeon 520
Discrete graphics memory type	GDDR5
On-board graphics adapter model	Not available
Number of discrete graphics adapters	1
Optical drive
Optical drive type	DVD±RW
Network
Ethernet LAN	Yes
Wi-Fi	Yes
Bluetooth	Yes
Bluetooth version	5.0
Wi-Fi standards	802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac)
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Antenna type	2x2
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
VGA (D-Sub) ports quantity	1
USB 2.0 ports quantity	2
Serial ports quantity	1
PS/2 ports quantity	2
Microphone in	Yes
Line-out	Yes
Line-in	Yes
Headphone outputs	1
Ethernet LAN (RJ-45) ports	1
DVI port	No
DisplayPorts quantity	2
Technical details
Product type	PC
Trusted Platform Module (TPM)	Yes
Product colour	Black
Chassis type	SFF
Audio system	High Definition Audio
Placement supported	Horizontal/Vertical
Sustainability certificates	RoHS, ENERGY STAR
Design
Volume	8.4 L
Product colour	Black
Chassis type	SFF
Placement supported	Horizontal/Vertical
Performance
Audio chip	Realtek ALC662
Password protection	Yes
Password protection type	Power on, Supervisor
Product type	PC
Trusted Platform Module (TPM)	Yes
Audio system	High Definition Audio
Software
Operating system architecture	64-bit
Operating system installed	Windows 10 Pro
Power
Power supply	210 W
Weight & dimensions
Volume	8.4 L
Width	3.64" (92.5 mm)
Depth	11.4" (290.5 mm)
Height	13.5" (343.5 mm)
Weight	13.2 lbs (6 kg)
Packaging content
Mouse included	Yes
Display included	No
Keyboard included	Yes
Other features
Trusted Platform Module (TPM)	Yes
On-board graphics adapter	No
Processor manufacturer	AMD
