Lenovo
40A40090US - Lenovo THINKPAD ONELINK+ DOCK
40A40090US - Lenovo THINKPAD ONELINK+ DOCK
SKU:40A40090US
Regular price
$140.60 USD
Regular price
Sale price
$140.60 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
The ThinkPad OneLink+ Dock, powered by Lenovo€™s revolutionary OneLink+ technology transforms your new ThinkPad into a full featured machine in the office or at home. Not only does the new convenient OneLink+ connector deliver super-fast data transfers with USB 3.0 and up to Ultra High Definition (UHD) video but it also charges your notebook, cell phone and tablet while you work or play!
Unlike USB docks the OneLink+ Dock delivers video with no compression, no drivers and no impact on image quality and notebook performance. Simply connect your notebook with the ThinkPad OneLink+ Dock and get connected to power, Internet and workplace accessories through a convenient single connector. Expect nothing short of outstanding value with connections for two external displays, a keyboard, a mouse, and a printer. It also comes with a ThinkPad 90w slim tip AC Adapter.
The docking station comes equipped with a stereo/microphone combination audio port and 2x USB 3.0 ports on the front panel with one of those as an €œalways (power) on€� port for mobile device charging. Meanwhile, the rear panel has 2x USB 2.0 ports and 2x USB 3.0 ports, allowing for maximum device connectivity. The OneLink+ dock also comes with a 10/1000 Gigabit Ethernet port, one VGA port, and two DisplayPort 1.2 ports for up to 3 video outputs* with a maximum 4k2k resolution**. For security, the dock can be secured via a cable lock.
With all of these great features, the ThinkPad OneLink+ Dock actually takes up less desk space than other typical docking stations!
Features and Benefits:
- A single OneLink+ cable enables all docking functions while delivering continuous power, allowing you to boost your productivity in no time
- Up to 4k video output allows you to enjoy a vivid video experience with your brand new ThinkPad Ultrabook
- Power button on dock mirrors system power button
- Gigabit Ethernet (10/100/1000) with Boot over LAN support*** on all ThinkPad OneLink+ systems
Unlike USB docks the OneLink+ Dock delivers video with no compression, no drivers and no impact on image quality and notebook performance. Simply connect your notebook with the ThinkPad OneLink+ Dock and get connected to power, Internet and workplace accessories through a convenient single connector. Expect nothing short of outstanding value with connections for two external displays, a keyboard, a mouse, and a printer. It also comes with a ThinkPad 90w slim tip AC Adapter.
The docking station comes equipped with a stereo/microphone combination audio port and 2x USB 3.0 ports on the front panel with one of those as an €œalways (power) on€� port for mobile device charging. Meanwhile, the rear panel has 2x USB 2.0 ports and 2x USB 3.0 ports, allowing for maximum device connectivity. The OneLink+ dock also comes with a 10/1000 Gigabit Ethernet port, one VGA port, and two DisplayPort 1.2 ports for up to 3 video outputs* with a maximum 4k2k resolution**. For security, the dock can be secured via a cable lock.
With all of these great features, the ThinkPad OneLink+ Dock actually takes up less desk space than other typical docking stations!
Features and Benefits:
- A single OneLink+ cable enables all docking functions while delivering continuous power, allowing you to boost your productivity in no time
- Up to 4k video output allows you to enjoy a vivid video experience with your brand new ThinkPad Ultrabook
- Power button on dock mirrors system power button
- Gigabit Ethernet (10/100/1000) with Boot over LAN support*** on all ThinkPad OneLink+ systems
Specification:
| Ports & interfaces | |
|---|---|
| Combo headphone/mic port | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 6 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| VGA (D-Sub) ports quantity | 1 |
| DisplayPorts quantity | 2 |
| DVI-D ports quantity | 1 |
| Microphone in | No |
| Connectivity technology | Docking |
| Networking | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports | 1 |
| Performance | |
| Product colour | Black |
| Card reader integrated | No |
| Brand compatibility | Lenovo |
| Cable lock slot | Yes |
| Certification | AS / NZS S-DOC, VCCI, BSMI, KCC, NOM, GOST, CB, CE, UkrSEPRO, EC-DoC, UL, FCC |
| Technical details | |
| Product colour | Black |
| Brand compatibility | Lenovo |
| Cable lock slot | Yes |
| Storage | |
| Card reader integrated | No |
| Weight & dimensions | |
| Weight | 34.6 oz (980 g) |
| Width | 15.8" (402.2 mm) |
| Depth | 6.51" (165.4 mm) |
| Height | 2.19" (55.6 mm) |
| Design | |
| Product colour | Black |
| Cable lock slot | Yes |
| Certification | AS / NZS S-DOC, VCCI, BSMI, KCC, NOM, GOST, CB, CE, UkrSEPRO, EC-DoC, UL, FCC |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 43 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Certificates | |
| Certification | AS / NZS S-DOC, VCCI, BSMI, KCC, NOM, GOST, CB, CE, UkrSEPRO, EC-DoC, UL, FCC |
