Specification:
| Display | |
|---|---|
| Display number of colours | 1.07 billion colors |
| Panel type | ADS |
| Number of simultaneous touchpoints | 20 |
| Touchscreen | No |
| Display technology | ADS |
| Display diagonal | 65" |
| Display resolution | 3840 x 2160 pixels |
| Display brightness | 350 cd/m² |
| HD type | 4K Ultra HD |
| Response time | 8 ms |
| Contrast ratio (typical) | 1200:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Pixel pitch | 0.0146 x 0.0146" (0.372 x 0.372 mm) |
| Display diagonal (metric) | 64.5" (163.9 cm) |
| Native aspect ratio | 16:9 |
| Anti-glare screen | Yes |
| Native refresh rate | 60 Hz |
| Multi-touch | Yes |
| Ports & interfaces | |
| USB connector type | USB Type-A, USB Type-B, USB Type-C |
| USB port | Yes |
| HDMI version | 2.0 |
| RS-232C | Yes |
| Wi-Fi | No |
| Compatible memory cards | MicroSD (TransFlash) |
| Card reader integrated | Yes |
| Ethernet LAN | Yes |
| HDMI ports quantity | 3 |
| DVI port | Yes |
| DVI-D ports quantity | 1 |
| VGA (D-Sub) input ports | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB version | 2.0 |
| USB ports quantity | 8 |
| HDMI input ports quantity | 3 |
| Audio | |
| Number of built-in speakers | 2 |
| RMS rated power | 30 W |
| Built-in speaker(s) | Yes |
| Design | |
| Product design | Digital signage flat panel |
| Placement supported | Indoor |
| Orientation | Horizontal/Vertical |
| Product colour | Black |
| Panel mounting interface | 100 x 100,400 x 400 mm |
| Certification | FCC, Class A CB EAC EMF ETL |
| VESA mounting | Yes |
| Anti-glare screen | Yes |
| Wall mountable | Yes |
| Performance | |
| Purpose | Universal |
| Mean time between failures (MTBF) | 50000 h |
| On Screen Display (OSD) languages | Arabic, Simplified Chinese, Traditional Chinese, Danish, German, Dutch, English, Spanish, French, Italian, Japanese, Norwegian, Polish, Portuguese, Russian, Swedish, Turkish |
| On Screen Display (OSD) | Yes |
| Number of OSD languages | 18 |
| Open Pluggable Specification (OPS) | Yes |
| Wi-Fi | No |
| Power | |
| Power consumption (max) | 376 W |
| Power consumption (typical) | 155 W |
| Power consumption (standby) | 0.5 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Computer system | |
| Computer system | No |
| Operating system installed | Android 8.0 |
| Internal memory | 3 GB |
| Internal storage capacity | 16 GB |
| Video formats supported | H.263, H.264, H.265, MPEG1, MPEG2, MPEG4, VP9 |
| Audio formats supported | AAC, AAC HE |
| Image formats supported | BMP, JPEG, PNG |
| Processor manufacturer | ARM |
| Built-in processor | Yes |
| On-board graphics card model | ARM Mali-G51 |
| Processor architecture | ARM Cortex-A53+Cortex-A73 |
| Weight & dimensions | |
| Width | 58.8" (1494.3 mm) |
| Depth | 3.92" (99.5 mm) |
| Height | 34.8" (883.2 mm) |
| Weight | 95 lbs (43.1 kg) |
| Packaging data | |
| Package weight | 116.2 lbs (52.7 kg) |
| Quick start guide | Yes |
| Batteries included | Yes |
| Remote control included | Yes |
| Cables included | AC, DVI, HDMI, IR sensor, RS-232, USB Type-A to USB Type-B |
| Packaging content | |
| Quick start guide | Yes |
| Batteries included | Yes |
| Remote control included | Yes |
| Cables included | AC, DVI, HDMI, IR sensor, RS-232, USB Type-A to USB Type-B |
| Operational conditions | |
| Operating altitude | 0 - 118110.2" (0 - 3000 m) |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -20 - 60 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Certificates | |
| Certification | FCC, Class A CB EAC EMF ETL |
| Technical details | |
| VESA mounting | Yes |
| USB connector type | USB Type-A, USB Type-B, USB Type-C |
| Panel type | ADS |
| Remote control battery type | AAA |
| Glass protection | Yes |
| Number of simultaneous touchpoints | 20 |
| Network controllable | RS232/RJ-45 |
| Signal loop through | RS232, IR Loop through |
| Keyboard control | Lockable |
| Set width (inch) | 58.83" |
| Set height (inch) | 34.77" |
| Set depth (inch) | 3.92" |
| Product weight | 95.13 lbs |
| Bezel width (L/T, R/B) | 17.8 mm(T/R/L)/31.7 mm(B) |
| Sustainability compliance | Yes |
| Sustainability certificates | CE, RoHS |
| Warranty period | 5 year(s) |
| Thin Client | |
| Operating system installed | Android 8.0 |
| Internal memory | 3 GB |
| Internal storage capacity | 16 GB |
| Video formats supported | H.263, H.264, H.265, MPEG1, MPEG2, MPEG4, VP9 |
| Audio formats supported | AAC, AAC HE |
| Image formats supported | BMP, JPEG, PNG |
| Features | |
| Wall mountable | Yes |
| Other features | |
| USB connector type | USB Type-A, USB Type-B, USB Type-C |
| Panel type | ADS |
| Remote control battery type | AAA |
| Glass protection | Yes |
| Number of simultaneous touchpoints | 20 |
| Network controllable | RS232/RJ-45 |
| Wi-Fi | No |
| Quick start guide | Yes |
| Power consumption (max) | 376 W |
| Operating altitude | 0 - 118110.2" (0 - 3000 m) |
| Mean time between failures (MTBF) | 50000 h |
| Display technology | ADS |
| Compatible memory cards | MicroSD (TransFlash) |
| Card reader integrated | Yes |
