Lenovo

7ZT7A00496 - Lenovo THINKSYSTEM BROADCOM NX-E PCIE 10GB 2-PORT BASE-T ETHERNET ADAPTER

7ZT7A00496 - Lenovo THINKSYSTEM BROADCOM NX-E PCIE 10GB 2-PORT BASE-T ETHERNET ADAPTER

SKU:7ZT7A00496

Regular price $206.91 USD
Regular price Sale price $206.91 USD
Sale Sold out
Shipping calculated at checkout.
The Broadcom NX-E 10Gb Base-T Ethernet Adapters are dual-port 10GBASE-T adapters that are fully compliant with the IEEE 802.3an standard and provide a low-cost solution for 10 Gb Ethernet using copper wiring. This product guide provides essential presales information to understand the Broadcom adapters and their key features, specifications, and compatibility. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the adapters and consider their use in IT solutions. The Broadcom NX-E 10Gb Base-T Ethernet Adapters are dual-port 10GBASE-T adapters that are fully compliant with the IEEE 802.3an standard and provide a low-cost solution for 10 Gb Ethernet using copper wiring. The adapters are available in either ML2 form factor or PCIe low-profile form factor for use in Lenovo ThinkSystem servers. The following figure shows the ThinkSystem Broadcom NX-E ML2 10Gb 2-Port Base-T Ethernet Adapter.



Specification:



Ports & interfaces
Internal Yes
Ethernet LAN (RJ-45) ports 2
Interface Ethernet
Connectivity technology Wired
Bandwidth
Maximum data transfer rate 10000 Mbit/s
Technical details
Product colour Black,Blue
Networking
iSCSI support Yes
Cabling technology 10GBase-T
Networking standards IEEE 802.3ab,IEEE 802.3an
Maximum operating distance 3937" (100 m)
Jumbo frames support Yes
Ethernet LAN data rates 10,100,1000,10000 Mbit/s
Maximum data transfer rate 10000 Mbit/s
Design
Product colour Black,Blue
Certification CE/European Union EN60950-1
UL/USA UL60950-1
CTUVus UL
Canada: CSA 22.2 No. 950
Taiwan: CNS14336 Class A
EN55022:2010 + *AC:2011 Class A
EN55024 Class A
FCC CFR47, Part 15 Class A
Canada: ICES-003 Class A
Australia, New Zealand: EN 5022:2010 + *AC:2011
Taiwan: BSMI CNS13438 Class A
South Korea: MIC RRL KN22 Class A
South Korea: KN24 (ESD)
Japan: VCCI V-3 04/2014
EN55024:2010 Air/Direct discharge
Internal Yes
Operational conditions
Storage temperature (T-T) -40 - 65 °C
Operating relative humidity (H-H) 5 - 95%
Storage relative humidity (H-H) 5 - 95%
Weight & dimensions
Width 0.669" (17 mm)
Depth 6.61" (168 mm)
Height 2.72" (69 mm)
Certificates
Certification CE/European Union EN60950-1
UL/USA UL60950-1
CTUVus UL
Canada: CSA 22.2 No. 950
Taiwan: CNS14336 Class A
EN55022:2010 + *AC:2011 Class A
EN55024 Class A
FCC CFR47, Part 15 Class A
Canada: ICES-003 Class A
Australia, New Zealand: EN 5022:2010 + *AC:2011
Taiwan: BSMI CNS13438 Class A
South Korea: MIC RRL KN22 Class A
South Korea: KN24 (ESD)
Japan: VCCI V-3 04/2014
EN55024:2010 Air/Direct discharge
