ACS8016MDAC-400 - Vertiv 16-PORT ACS DUAL AC W/ ANALOG MODEM

The Avocent ACS 8000 advanced console server offers upgraded and advanced features, that deliver scalable and high-performance solutions for IT administrators. The console server features a dual ARM core processor platform with dual Gigabit Ethernet ports and dual Gigabit fiber ports for redundancy. In addition, there is a sensor port, to connect a variety of sensors for monitoring and logging on the appliance. The serial ports are auto sensing for pin-out and the Avocent ACS 8000 advanced console server also offers robust features to meet the requirements of the demanding data center management applications. Features combine automated discovery tools to ease identification of servers, routers, switches and power devices, connected to any serial port, saving time at initial configuration and installation. To comply with existing data center network access policy, the Avocent ACS 8000 advanced console server provides customizable, multiple access levels for secure management. The console servers provide a complete solution for secure, remote control with advanced console server features, such as enhanced security, data logging and event monitoring. In addition, the Avocent ACS 8000 advanced console server supports network standards, such as Internet Protocol version 6 (IPv6).



Specification:



Technical details
Rack mounting	Yes
Internal modem	No
Event logging	Yes
Security
Security algorithms	SNMP,SSH,SSH-2,WPA2-RADIUS
IP address filtering	Yes
Ports & interfaces
USB 2.0 ports quantity	8
Serial ports quantity	16
Ethernet LAN (RJ-45) ports	2
Console port	RS-232
AC outlet types	C13 coupler
Software
Operating system installed	Embedded Linux
Memory
Internal memory	1000 MB
Flash memory	16000 MB
Weight & dimensions
Weight	7.05 lbs (3.2 kg)
Dimensions (WxDxH)	17.2 x 9.49 x 1.75" (438 x 241 x 44.5 mm)
Power
Power source type	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	11 W
Operational conditions
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 95%
Operating temperature (T-T)	-10 - 60 °C
Operating relative humidity (H-H)	20 - 80%
Certificates
Certification	FCC Class A UL (USA) CE Class A (EU) cUL (Canada) ICES-003 (Canada) EN-60950 (EU) VCCI (Japan) CB RCM (Australia) Customs Union (CU) KCC (Korea)
