AT-DMC1000/LC-90 - Allied Telesis 1000T TO 1000X/LC, DESKTOP MINI CONVERTER, US POWER, TAA

Gigabit Desktop USB-Powered Media Converter This desktop media converter features 1000T to 1000SX conversion with LC multi-mode fiber connector supporting a distances from 220m to 550m. At just 1.25 inches wide — 3.6 inches deep — 0.85 inches high, this media converter can easily fit into the palm of a hand.



Specification:



Networking
Fiber optic connector	SC
Data transfer rate	1000 Mbit/s
Packet forwarding rate (100 Mbps)	148800 pps
Packet forwarding rate (10 Mbps)	14880 pps
Packet forwarding rate (1 Gbps)	1488000 pps
VLAN support	Yes
Converter input interface	1000Base-T
Networking standards	IEEE 802.1Q
Ethernet interface type	Gigabit Ethernet
Duplex system	Full,Half
Converter output interface	1000Base-SX
Auto MDI/MDI-X	Yes
Maximum data transfer rate	1000 Mbit/s
Technical details
Wavelength	850 nm
Maximum transfer distance	21653.5" (550 m)
Fiber mode structure	Multi-mode
Fiber cable diameters supported (core/cladding)	50/125,62.5/125 µm
Tx power (min)	-9.5 dBmW
Tx power (max)	-4 dBmW
Rx power (min)	-17 dBmW
Internal	No
Data transfer rate	1000 Mbit/s
Ports & interfaces
Connectivity technology	Wired
Fiber optic connector	SC
Indication
LED indicators	Yes
Performance
Wavelength	850 nm
Maximum transfer distance	21653.5" (550 m)
Fiber mode structure	Multi-mode
Fiber cable diameters supported (core/cladding)	50/125,62.5/125 µm
Tx power (min)	-9.5 dBmW
Tx power (max)	-4 dBmW
Rx power (min)	-17 dBmW
Design
LED indicators	Yes
Product colour	Grey
Internal	No
Power
Power consumption (typical)	1.5 W
Colour
Product colour	Grey
Weight & dimensions
Width	1.25" (31.8 mm)
Depth	3.6" (91.4 mm)
Weight	3.99 oz (113 g)
Height	0.85" (21.6 mm)
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 65 °C
Operating relative humidity (H-H)	5 - 95%
Storage relative humidity (H-H)	5 - 95%
Operating altitude	0 - 120000" (0 - 3048 m)
