Tripp Lite

B042-004 - Tripp Lite 4-PORT RACKMOUNT USB / PS2 KVM SWITCH W/ ON-SCREEN DISPLAY 1U

B042-004 - Tripp Lite 4-PORT RACKMOUNT USB / PS2 KVM SWITCH W/ ON-SCREEN DISPLAY 1U

SKU:B042-004

Regular price $460.75 USD
Regular price Sale price $460.75 USD
Sale Sold out
Shipping calculated at checkout.
Batteries not Required to Operate Tripp Lite's NetController 4-Port, 1U rackmount KVM Switch is an affordable, highly-flexible enterprise class KVM Switch, which allows the user to connect either USB or PS/2 keyboards and mice. In addition, P780-Series USB/PS2 combo KVM cable kits allow you to connect either USB or PS/2 computers, without the need to purchase separate cables or adapters. Control up to 4 directly connected computers, or expand the number of connected computers to up to 244 by daisychaining up to 15 additional B042-Series KVM switches. Switch between connected computers via the On-Screen Display (OSD), pushbuttons, or keyboard hotkey commands. Other features include: password protection, auto-scanning, auto-logout, firmware upgrade and video support up to 2048 x 1536 (QXGA). Mounts easily in a standard 19" rack/cabinet and includes all necessary mounting hardware. Compatible with all major operating systems. Constructed of heavy-duty steel housing. - NetController 4-Port, 1U rackmount KVM switch - Control 4 computers via a single VGA monitor and USB or PS/2 keyboard/mouse - Control up to 244 computers by daisychaining up to 15 additional B042-Series KVM switches - P780-Series USB/PS2 combo KVM cables kits allow you to connect either USB or PS/2 computers, without the need to purchase separate cables or adapters - Compatible with all major operating systems - B042-004 NetController 4-Port, 1U rackmount KVM switch - External Power Supply with NEMA 1-15P Plug (Input: 100-240V, 50/60Hz, 0.3A / Output: 9V, 1A) - Rackmount hardware - 20.32 cm (8-in.) Daisychain cable ( for longer daisy-chain cables, see Tripp Lite P781 series cables) - Daisychain terminator - 1.22 m (4-ft.) HD15 to DB9 firmware upgrade cable - CD with owner's manual and quick start guide - Quick start guide - NetController 4-Port, 1U rackmount KVM switch - Control 4 computers via a single VGA monitor and USB or PS/2 keyboard/mouse - P780-Series USB/PS2 combo KVM cable kits allow you to connect either USB or PS/2 computers, without the need to purchase separate cables or adapters - Control up to 244 computers by daisychaining up to 15 additional B042-Series KVM switches - Allows for easy customization of ports by daisy-chaing any combination of B042-Series KVM's (4-, 8- or 16-port) - Standard 19" Rackmount size - hardware included - On-Screen Display (OSD) menu for intuitive operation and easy control - Switch between connected computers via the On-Screen Display (OSD), pushbuttons, or keyboard hotkey commands - Supports video resolution up to 2048 x 1536 - Password protection and auto-logout features - Firmware upgradeable - Robust metal case design ensures best EMI/RFI shielding and video quality - Hot-swappable: disconnect and reconnect USB computers without rebooting - Supports standard 5-button Microsoft, Logitech, or comparable mice - Supports standard Microsoft, Logitech, or comparable keyboards - Compatible with all major operating systems - Constructed of heavy-duty steel housing



Specification:



Technical details
Product colour Black
Rack mounting Yes
Ports & interfaces
Number of computers controlled 8
Keyboard port type USB, PS/2
Mouse port type USB, PS/2
Video port type VGA
Design
Country of origin China
Product colour Black
Rack mounting Yes
Rack capacity 1U
Display
Built-in display No
Power
AC input voltage 100-250 V
Features
Country of origin China
Weight & dimensions
Width 19" (482.6 mm)
Depth 6.5" (165.1 mm)
Height 1.75" (44.4 mm)
Weight 4.3 lbs (1.95 kg)
Package width 11.1" (281.9 mm)
Package depth 17.1" (434.3 mm)
Package height 2.8" (71.1 mm)
Package weight 6.11 lbs (2.77 kg)
Packaging data
Package width 11.1" (281.9 mm)
Package depth 17.1" (434.3 mm)
Package height 2.8" (71.1 mm)
Package weight 6.11 lbs (2.77 kg)
Logistics data
Country of origin China
Master (outer) case width 18.3" (464.8 mm)
Master (outer) case length 15.4" (391.2 mm)
Master (outer) case height 12.6" (320 mm)
Master (outer) case gross weight 32.6 lbs (14.8 kg)
Products per master (outer) case 5 pc(s)
Master (outer) case GTIN (EAN/UPC) 20037332141396
Harmonized System (HS) code 8517.62.0020
