BR1200GI - APC INTL BACK-UPS PRO 1200VA 230V

The Back-UPS RS offers high performance protection for your business and office computer systems. It provides abundant battery backup power, allowing you to work through medium and extended length power outages. It also safeguards your equipment from damaging surges and spikes that travel along utility, phone and network lines. A distinguishing feature of the Back-UPS RS is automatic voltage regulation (AVR). AVR instantly adjusts both low and high voltages to safe levels, so you can work indefinitely during brownouts and overvoltage situations, saving the battery for power outages when you need it most. Award-winning shutdown software automatically powers down your computer system in the event of an extended power outage. Additional features like audible alarms, LED status indicators, user replaceable battery, push-button circuit breakers and plentiful outlets (including transformer-block spaced outlets) make the Back-UPS RS the perfect unit to protect your business' productivity from the constant threat of power problems and lost data. Green mode: Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection. Audible alarms: Provide notification of changing flywheel conditions Battery failure notification: Provides early-warning fault analysis on batteries enabling timely preventive maintenance Power-saving outlets: Automatically cuts power to idle equipment to conserve electricity. LCD display: Alpha-Numeric Display which displays system parameters and alarms. Battery-protected and surge-only outlets: Reserves power capacity and run time for connected equipment that require battery back-up while providing surge only protection for less critical equipment Cold-start capable: Provides temporary battery power when the utility power is out. Hot-swappable batteries: Ensures clean, uninterrupted power to protected equipment while batteries are being replaced Automatic self-test: Periodic battery self-test ensures early detection of a battery that needs to be replaced. Adjustable voltage sensitivity: Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications. Audible alarms: Provides notification of changing utility power and UPS conditions. User-replaceable batteries: Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR) USB connectivity: Provides management of the UPS via a USB port (not available on all models). Transformer-block spaced outlets: Protect equipment with input transformer blocks without blocking access to other receptacles. Boost and Trim Automatic Voltage Regulation (AVR): Gives higher application availability by correcting low and high voltage conditions without using the battery Automatic Voltage Regulation (AVR): Gives higher application availability by correcting low and high voltage conditions without using the battery. Intelligent battery management: Maximizes battery performance, life, and reliability through intelligent, precision charging. Building Wiring Fault Indicator: This LED informs users of potentially dangerous wiring problems in the wall circuit. Adjustable voltage sensitivity: Provides the ability to adapt the Power Conditioner for optimal performance in specific power environments or generator applications. Automatic Voltage Regulation (AVR): Automatically steps up low voltage and steps down high voltage to levels that are suitable for your equipment. Battery fault detection: Monitors room and individual battery temperature changes for early detection of thermal runaway, shorted cells, open circuit, and bad battery. Battery-protected and surge-only outlets: Reserves power capacity and run time for connected equipment that require battery back-up while providing surge only protection for less critical equipment. Safety-agency approved: Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment. Power conditioning: Protects connected loads from surges, spikes, lightning, and other power disturbances. Audible alarms: Provides notification of changing utility power and UPS conditions. Automatic restart of loads after UPS shutdown: Automatically starts up the connected equipment upon the return of utility power. Automatic self-test: Periodic battery self-test ensures early detection of a battery that needs to be replaced. Battery replacement without tools: Allows quick, easy battery replacement. LED status indicators: Quickly understand unit and power status with visual indicators. Cold-start capable: Provides temporary battery power when the utility power is out. Hot-swappable batteries: Ensures clean, uninterrupted power to protected equipment while batteries are being replaced Resettable circuit breakers: Enables a quick recovery from overload events. Transformer-block spaced outlets: Protect equipment with input transformer blocks without blocking access to other receptacles. User-replaceable batteries: Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR) Adjustable voltage sensitivity: Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications. Adjustable voltage-transfer points: Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation. Intelligent battery management: Micro-processor controlled battery charging and diagnostic testing ensures maximum battery life.



Specification:



Power
Output frequency	60 Hz
Output power	810 W
Input operation voltage (min)	88 V
Input operation voltage (max)	147 V
Surge energy rating	1080 J
Maximum current	12 A
Output power capacity	1.35 kVA
Input frequency	60 Hz
Ports & interfaces
Cable length	72" (1.83 m)
USB port	Yes
AC outlets quantity	10 AC outlet(s)
AC outlet types	NEMA 5-15R
Power plug	NEMA 5-15P
Performance
Hold time (min)	8 ms
Hold time (max)	10 ms
Audible alarm modes	Low battery alarm, Overload alarm
UPS topology	Line-Interactive
Waveform	Sine
Automatic Voltage Regulation (AVR)	Yes
EMI/RFI noise filtering	Yes
Surge protection	Yes
Surge protection features	Coax, Network
Noise level	45 dB
Audible alarm(s)	Yes
Features
Output frequency	60 Hz
Hold time (min)	8 ms
Hold time (max)	10 ms
Audible alarm modes	Low battery alarm, Overload alarm
UPS topology	Line-Interactive
Waveform	Sine
Automatic Voltage Regulation (AVR)	Yes
Output power	810 W
Input operation voltage (min)	88 V
Input operation voltage (max)	147 V
Surge energy rating	1080 J
Maximum current	12 A
EMI/RFI noise filtering	Yes
Surge protection	Yes
Surge protection features	Coax, Network
Noise level	45 dB
Audible alarm(s)	Yes
Output power capacity	1.35 kVA
Input frequency	60 Hz
Battery
Battery life (max)	5 year(s)
Battery technology	Sealed Lead Acid (VRLA)
Battery recharge time	16 h
Hot-swap battery	Yes
Cold start	Yes
Automatic battery test	Yes
Design
Form factor	Tower
Product colour	Black
Certification	FCC 15 B, NOM, TUV C-US
Cable length	72" (1.83 m)
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 45 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	0 - 118110.2" (0 - 3000 m)
Non-operating altitude	0 - 118110.2" (0 - 3000 m)
Technical details
Output voltage	120 V
Output frequency	60 Hz
Sustainability certificates	ENERGY STAR
Weight & dimensions
Weight	25.8 lbs (11.7 kg)
Width	3.94" (100 mm)
Height	10.2" (260 mm)
Depth	14.5" (368 mm)
Package width	8.78" (223 mm)
Package depth	19" (482 mm)
Package height	14.1" (358 mm)
Package weight	29.3 lbs (13.3 kg)
Packaging data
Manual	Yes
Cables included	USB cable
Package width	8.78" (223 mm)
Package depth	19" (482 mm)
Package height	14.1" (358 mm)
Package weight	29.3 lbs (13.3 kg)
Logistics data
Products per master (outer) case	1 pc(s)
Master (outer) case gross weight	29.3 lbs (13.3 kg)
Products per pallet	16 pc(s)
Certificates
Certification	FCC 15 B, NOM, TUV C-US
Other features
Output voltage	120 V
Packaging content
Manual	Yes
Cables included	USB cable
