BR1500GI - APC POWER SAVING BACK-UPS PRO 1500, 230V
BR1500GI - APC POWER SAVING BACK-UPS PRO 1500, 230V
SKU:BR1500GI
Regular price
$273.60 USD
Regular price
Sale price
$273.60 USD
Unit price
per
Green mode Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection. Battery failure notification Provides early-warning fault analysis on batteries enabling timely preventive maintenance Power-saving outlets Automatically cuts power to idle equipment to conserve electricity. Resettable circuit breaker Easy recovery from overloads; no need to replace a fuse. Extendable Run Time Additional batteries can be added to provide power to the load for an extended period of time in the event of utility supply failure. Battery-protected and surge-only outlets Reserves power capacity and run time for connected equipment that require battery back-up while providing surge only protection for less critical equipment Cold-start capable Provides temporary battery power when the utility power is out. Serial Connectivity Use any Home Automation network to monitor and control the S20 through its RS-232 serial port. For information on how to communicate with the S20, see APC's Application Note #102. Crestron and AMX installers should visit their respective websites for information on how to integrate the S20 into those networks. Hot-swappable batteries Ensures clean, uninterrupted power to protected equipment while batteries are being replaced Disconnected battery notification Warns when a battery is not available to provide backup power. Dataline Surge Protection Provides protection of connected equipment from power surges on the data lines. Automatic self-test Periodic battery self-test ensures early detection of a battery that needs to be replaced. Adjustable voltage-transfer points Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.
Specification:
Power | |
---|---|
Output power | 900 W |
Input operation voltage (min) | 88 V |
Input operation voltage (max) | 147 V |
Output operation voltage (min) | 120 V |
Surge energy rating | 1080 J |
Maximum current | 12 A |
Output power capacity | 1.5 kVA |
Input frequency | 50/60 Hz |
Ports & interfaces | |
Cable length | 72" (1.83 m) |
Socket circuit breaker | Yes |
USB port | Yes |
Cabling technology | 10/100/1000Base-T(X) |
AC outlets quantity | 10 AC outlet(s) |
AC outlet types | NEMA 5€“15P |
Power plug | NEMA 5-15R |
Ethernet LAN (RJ-45) ports | 3 |
Number of outlets (Battery backup & protection) | 6 |
Number of outlets (Protection) | 4 |
Performance | |
Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
Waveform | Sine |
Automatic Voltage Regulation (AVR) | Yes |
LED indicators | Fault |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Surge protection features | A/V, Coax, Modem, Network |
Noise level | 45 dB |
Audible alarm(s) | Yes |
Maintenance-free | Yes |
Features | |
Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
Waveform | Sine |
Automatic Voltage Regulation (AVR) | Yes |
Output power | 900 W |
Input operation voltage (min) | 88 V |
Input operation voltage (max) | 147 V |
Output operation voltage (min) | 120 V |
Surge energy rating | 1080 J |
Maximum current | 12 A |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Surge protection features | A/V, Coax, Modem, Network |
Noise level | 45 dB |
Audible alarm(s) | Yes |
Output power capacity | 1.5 kVA |
Socket circuit breaker | Yes |
Maintenance-free | Yes |
Input frequency | 50/60 Hz |
Battery | |
Battery life (max) | 5 year(s) |
Battery technology | Sealed Lead Acid (VRLA) |
Battery recharge time | 16 h |
Hot-swap battery | Yes |
Cold start | Yes |
Automatic battery test | Yes |
Design | |
Form factor | Compact |
LED indicators | Fault |
Product colour | Black |
Certification | FCC Part 15 Class B, NOM, TUV C-US, REACH |
Cable length | 72" (1.83 m) |
Display type | LCD |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 40 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 118110.2" (0 - 3000 m) |
Non-operating altitude | 0 - 118110.2" (0 - 3000 m) |
Technical details | |
Sustainability certificates | RoHS |
Weight & dimensions | |
Package width | 9.49" (241 mm) |
Package depth | 19.7" (500 mm) |
Package height | 15" (380 mm) |
Weight | 27.6 lbs (12.5 kg) |
Width | 3.94" (100 mm) |
Package weight | 31.3 lbs (14.2 kg) |
Height | 10.2" (260 mm) |
Depth | 14.5" (368 mm) |
Packaging data | |
Manual | Yes |
Cables included | Coaxial, USB cable |
Package width | 9.49" (241 mm) |
Package depth | 19.7" (500 mm) |
Package height | 15" (380 mm) |
Package weight | 31.3 lbs (14.2 kg) |
Certificates | |
Certification | FCC Part 15 Class B, NOM, TUV C-US, REACH |
Packaging content | |
Manual | Yes |
Cables included | Coaxial, USB cable |
