BX80621E52680 - Intel E5-2680 2.70G 8C 130W PROC
BX80621E52680 - Intel E5-2680 2.70G 8C 130W PROC
SKU:BX80621E52680
Regular price
$95.87 USD
Regular price
Sale price
$95.87 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
Intel Xeon E5-2680. Processor family: Intel® Xeon® E5 Family, Processor socket: LGA 2011 (Socket R), Processor lithography: 32 nm. Memory channels: Quad-channel, Maximum internal memory supported by processor: 750 GB, Memory types supported by processor: DDR3-SDRAM. Market segment: Server, Supported instruction sets: AVX, Scalability: 2S. Intel® Turbo Boost Technology 2.0 frequency: 3.5 GHz. Package width: 1.73" (44 mm), Package depth: 5.51" (140 mm), Package height: 4.61" (117 mm)
Specification:
| Processor | |
|---|---|
| Processor base frequency | 3.1 GHz |
| Processor manufacturer | Intel |
| Cooler included | Yes |
| Processor codename | Sandy Bridge EP |
| Memory bandwidth supported by processor (max) | 51.2 GB/s |
| Thermal Design Power (TDP) | 150 W |
| Processor cache | 20 MB |
| Processor ARK ID | 64582 |
| Processor model | E5-2687W |
| Processor threads | 16 |
| System bus rate | 8 GT/s |
| Processor operating modes | 64-bit |
| VID Voltage Range | 0.6 - 1.35 V |
| Processor boost frequency | 3.8 GHz |
| Stepping | C2 |
| Number of QPI links | 2 |
| CPU multiplier (bus/core ratio) | 38 |
| Bus type | QPI |
| Component for | Server/workstation |
| Processor lithography | 32 nm |
| Processor family | Intel® Xeon® E5 Family |
| Processor cores | 8 |
| Box | Yes |
| Processor socket | LGA 2011 (Socket R) |
| Processor code | SR0KG |
| Processor series | Intel Xeon E5-2600 |
| Processor cache type | Smart Cache |
| Memory | |
| Maximum internal memory supported by processor | 750 GB |
| Memory types supported by processor | DDR3-SDRAM |
| Memory clock speeds supported by processor | 800,1066,1333,1600 MHz |
| Memory bandwidth supported by processor (max) | 51.2 GB/s |
| Supported memory types | DDR3-SDRAM |
| Memory channels | Quad-channel |
| ECC | Yes |
| Power | |
| Thermal Design Power (TDP) | 150 W |
| VID Voltage Range | 0.6 - 1.35 V |
| Technical details | |
| Cache memory | 20 MB |
| Thermal Monitoring Technologies | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel Trusted Execution Technology | Yes |
| Intel® Smart Cache | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel Flex Memory Access | No |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Idle States | Yes |
| Execute Disable Bit | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel® Virtualization Technology (Intel® VT) | VT-d, VT-x |
| PCI Express slots version | 3.0 |
| Supported instruction sets | AVX |
| Scalability | 2S |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Enhanced Halt State | Yes |
| Intel Demand Based Switching | Yes |
| Embedded options available | No |
| CPU configuration (max) | 2 |
| Processor code | SR0KG |
| Product type | Processor |
| Processor cache | 20480 KB |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel 64 | Yes |
| Thermal Design Power (TDP) | 150 W |
| Supported memory types | DDR3-SDRAM |
| Status | Discontinued |
| Product name | Intel Xeon E5-2687W (20M Cache, 3.10 GHz, 8.00 GT/s Intel QPI) |
| Processor series | Intel Xeon E5-2600 |
| Processor core voltage | 0.60 - 1.35 V |
| Market segment | Server |
| Launch date | Q1'12 |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Identity Protection Technology version | 0.00 |
| Processor cache type | Smart Cache |
| Bus type units | GT/s |
| Bus bandwidth | 8 |
| Born on date | Q1'12 |
| Maximum memory | 256 GB |
| Processor brand name | Intel Xeon |
| Last change | 63903513 |
| Product family | Intel Xeon Processor E5 Family |
| Bus speed | 8 GT/s |
| Features | |
| Maximum number of PCI Express lanes | 40 |
| Thermal Design Power (TDP) | 150 W |
| Processor package size | 52.5mm x 45mm |
| Processor ARK ID | 64582 |
| Thermal Monitoring Technologies | Yes |
| Idle States | Yes |
| Execute Disable Bit | Yes |
| PCI Express slots version | 3.0 |
| Supported instruction sets | AVX |
| Scalability | 2S |
| Embedded options available | No |
| CPU configuration (max) | 2 |
| Processor code | SR0KG |
| Market segment | Server |
| Images Type Map |  |
| Harmonized System (HS) code | 8542310001 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G077159 |
| PCI Express CEM revision | 3.0 |
| Processor special features | |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel 64 | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel Trusted Execution Technology | Yes |
| Intel® Smart Cache | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel Flex Memory Access | No |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel® Virtualization Technology (Intel® VT) | VT-d, VT-x |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Enhanced Halt State | Yes |
| Intel Demand Based Switching | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Identity Protection Technology version | 0.00 |
| Intel® vPro™ Platform Eligibility | Yes |
| Intel® Turbo Boost Technology 2.0 frequency | 3.8 GHz |
| Operational conditions | |
| Tcase | 67 °C |
| Packaging data | |
| Package width | 1.73" (44 mm) |
| Package depth | 5.51" (140 mm) |
| Package height | 4.61" (117 mm) |
| Package weight | 4.41 oz (125 g) |
| Package type | Retail box |
| Weight & dimensions | |
| Processor package size | 52.5mm x 45mm |
| Package width | 1.73" (44 mm) |
| Package depth | 5.51" (140 mm) |
| Package height | 4.61" (117 mm) |
| Package weight | 4.41 oz (125 g) |
| Other features | |
| Cache memory | 20 MB |
| Intel® Virtualization Technology (Intel® VT) | VT-d, VT-x |
| Maximum internal memory | 256 GB |
| Maximum internal memory | 262144 MB |
| CPU configuration (max) | 2 |
| Compatibility | Intel W2600CR2, S2600COE, S2600COEIOC, W2600CR2L, P4304CR2LFKN, P4304CR2LFJN, P4304CR2LFGN, P4304CR2LFJNL, H2312JFKR, H2216JFQKR |
| Processor code | SR0KG |
