BX80648I75960X - Intel CORE I7-5960X FC-LGA12A 3GHZ

Intel Core i7-5960X. Processor family: Intel® Core™ i7 X-series Extreme Edition, Processor socket: LGA 2011-v3, Processor lithography: 22 nm. Memory channels: Quad-channel, Maximum internal memory supported by processor: 64 GB, Memory types supported by processor: DDR4-SDRAM. Market segment: Desktop, Supported instruction sets: SSE4.2, AVX 2.0, Scalability: 1S. Intel® Turbo Boost Technology 2.0 frequency: 3.5 GHz. Package type: Retail box



Specification:



Processor
Processor generation	5th gen Intel® Core™ i7
Processor base frequency	3.3 GHz
Processor manufacturer	Intel
Cooler included	Yes
Processor codename	Broadwell
Configurable TDP-down	37 W
Memory bandwidth supported by processor (max)	25.6 GB/s
Thermal Design Power (TDP)	65 W
Processor cache	6 MB
Processor ARK ID	88040
Processor model	i7-5775C
Processor threads	8
System bus rate	5 GT/s
Processor operating modes	64-bit
Processor boost frequency	3.7 GHz
Stepping	G0
Bus type	DMI2
Component for	PC
Processor lithography	14 nm
Processor family	Intel Core i7
Processor cores	4
Box	Yes
Processor socket	LGA 1150 (Socket H3)
Processor series	Intel Core i7-5700 Desktop Series
Configurable TDP-down frequency	2.2 GHz
Processor cache type	L3
Generation	5th Generation
Memory
Maximum internal memory supported by processor	32 GB
Memory types supported by processor	DDR3L-SDRAM
Memory clock speeds supported by processor	1333,1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Supported memory types	DDR3L-SDRAM
Memory channels	Dual-channel
ECC	No
Graphics
On-board graphics adapter outputs supported	Embedded DisplayPort (eDP),DisplayPort,HDMI,DVI,VGA (D-Sub)
On-board graphics adapter maximum resolution (DisplayPort)	3840 x 2160 pixels
Number of execution units	48
On-board graphics adapter ID	1622
On-board graphics adapter maximum resolution (eDP - Integrated Flat Panel)	3840 x 2160 pixels
On-board graphics adapter refresh rate at maximum resolution (HDMI)	24 Hz
On-board graphics adapter refresh rate at maximum resolution (DisplayPort)	60 Hz
On-board graphics adapter refresh rate at maximum resolution (eDP - Integrated Flat Panel)	60 Hz
On-board graphics adapter refresh rate at maximum resolution (VGA)	60 Hz
Maximum graphics adapter memory	1740 MB
Maximum on-board graphics adapter memory	32 GB
Number of displays supported (on-board graphics)	3
On-board graphics adapter maximum resolution (HDMI)	4096 x 2304 pixels
On-board graphics adapter maximum resolution (VGA)	1920 x 1200 pixels
On-board graphics adapter DirectX version	11.2
On-board graphics adapter OpenGL version	4.3
On-board graphics adapter model	Intel® Iris™ Pro Graphics 6200
On-board graphics adapter	Yes
On-board graphics adapter dynamic frequency (max)	1150 MHz
On-board graphics adapter base frequency	300 MHz
Embedded DRAM (eDRAM) memory	128 MB
Maximum graphics adapter memory	32 GB
Power
Configurable TDP-down	37 W
Thermal Design Power (TDP)	65 W
Configurable TDP-down frequency	2.2 GHz
Technical details
Intel Stable Image Platform Program (SIPP)	No
Cache memory	6 MB
Thermal solution specification	PCA 2013D
Intel TSX-NI	Yes
Intel® Secure Key	Yes
Thermal Monitoring Technologies	Yes
Intel® Wireless Display (Intel® WiDi)	Yes
Intel® Turbo Boost Technology	2.0
Intel Trusted Execution Technology	No
Intel® Quick Sync Video Technology	Yes
Intel® InTru™ 3D Technology	Yes
Intel® Insider™	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel FDI Technology	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® Anti-Theft Technology (Intel® AT)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Idle States	Yes
Execute Disable Bit	Yes
Enhanced Intel SpeedStep Technology	Yes
Intel® Virtualization Technology (Intel® VT)	VT-d,VT-x
PCI Express slots version	3.0
PCI Express configurations	1x16,2x8,1x8+2x4
Supported instruction sets	SSE4.1,SSE4.2,AVX 2.0
Scalability	1S
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Enhanced Halt State	Yes
Graphics & IMC lithography	14 nm
Embedded options available	No
CPU configuration (max)	1
Graphics output	eDP/DP/HDMI/DVI/VGA
Video compression formats	Yes
Product type	Processor
Processor cache	6144 KB
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel 64	Yes
Video decoding	Yes
Maximum graphics adapter memory	1740 MB
Thermal Design Power (TDP)	65 W
Supported memory types	DDR3L-SDRAM
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	Yes
Status	Discontinued
Product name	Intel Core i7-5775C (6M Cache, up to 3.70 GHz)
Processor series	Intel Core i7-5700 Desktop Series
OpenGL support	Yes
Number of graphics cores	3
Maximum resolution & refresh rate (VGA)	1920x1200@60Hz
Maximum resolution & refresh rate (Integrated Flat Panel)	3840x2160@60Hz
Maximum resolution & refresh rate (HDMI)	4096x2304@24Hz
Maximum resolution & refresh rate (DisplayPort)	3840x2160@60Hz
Market segment	Desktop
Launch date	Q2'15
Intel Virtualization Technology (VT-x)	Yes
Intel Stable Image Platform Program (SIPP) version	0.00
Intel Small Business Advantage (SBA) version	0.00
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	1.00
Graphics max dynamic frequency	1.15 GHz
Configurable TDP-down frequency	2.2 GHz
Processor cache type	L3
Bus type units	GT/s
Bus bandwidth	5
Born on date	Q2'15
Maximum memory	32 GB
Intel TSX-NI version	1.00
Processor brand name	Intel Core i7 Intel Core i7 Processor
Last change	63903513
Embedded DRAM (eDRAM) memory	128 MB
Product family	5th Generation Intel Core i7 Processors
Maximum graphics adapter memory	32 GB
Processor ID	0x1622
Bus speed	5 GT/s
Features
On-board graphics adapter ID	1622
Maximum number of PCI Express lanes	16
Thermal Design Power (TDP)	65 W
Processor package size	37.5 x 37.5 mm
Integrated 4G WiMAX	No
Processor ARK ID	88040
Thermal solution specification	PCA 2013D
Thermal Monitoring Technologies	Yes
Idle States	Yes
Execute Disable Bit	Yes
PCI Express slots version	3.0
PCI Express configurations	1x16,2x8,1x8+2x4
Supported instruction sets	SSE4.1,SSE4.2,AVX 2.0
Scalability	1S
Graphics & IMC lithography	14 nm
Embedded options available	No
CPU configuration (max)	1
Market segment	Desktop
Harmonized System (HS) code	8542310001
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	G077159
PCI Express CEM revision	3.0
Processor special features
Intel Clear Video Technology	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel 64	Yes
Conflict-Free processor	Yes
Intel® Small Business Advantage (Intel® SBA)	No
Intel® OS Guard	Yes
Intel Stable Image Platform Program (SIPP)	No
Intel TSX-NI	Yes
Intel® Secure Key	Yes
Intel® Wireless Display (Intel® WiDi)	Yes
Intel® Turbo Boost Technology	2.0
Intel Trusted Execution Technology	No
Intel® Quick Sync Video Technology	Yes
Intel® InTru™ 3D Technology	Yes
Intel® Insider™	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel FDI Technology	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® Anti-Theft Technology (Intel® AT)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Enhanced Intel SpeedStep Technology	Yes
Intel® Virtualization Technology (Intel® VT)	VT-d,VT-x
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Enhanced Halt State	Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Stable Image Platform Program (SIPP) version	0.00
Intel Small Business Advantage (SBA) version	0.00
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	1.00
Intel TSX-NI version	1.00
Intel® vPro™ Platform Eligibility	No
Intel Virtualization Technology for Itanium (VT-i)	No
Intel® Turbo Boost Technology 2.0 frequency	3.7 GHz
Intel® Transactional Synchronization Extensions	Yes
Packaging data
Package width	1.48" (37.5 mm)
Package depth	1.48" (37.5 mm)
Package type	Retail box
Weight & dimensions
Processor package size	37.5 x 37.5 mm
Package width	1.48" (37.5 mm)
Package depth	1.48" (37.5 mm)
Other features
Video decoding	Yes
Cache memory	6 MB
Intel® Virtualization Technology (Intel® VT)	VT-d,VT-x
Maximum internal memory	32 GB
Maximum internal memory	32768 MB
CPU configuration (max)	1
Graphics output	eDP/DP/HDMI/DVI/VGA
