BX80701G6400 - Intel BOXED INTEL PENTIUM GOLD G6400 PROCESSOR (4M CACHE, 4.00 GHZ) FC-LGA14C

Intel Pentium Gold G6400. Processor family: Intel® Pentium® Gold, Processor socket: LGA 1200 (Socket H5), Processor lithography: 14 nm. Memory channels: Dual-channel, Maximum internal memory supported by processor: 128 GB, Memory types supported by processor: DDR4-SDRAM. On-board graphics card model: Intel® UHD Graphics 610, Maximum on-board graphics card memory: 64 GB, On-board graphics card base frequency: 350 MHz. Market segment: Desktop, PCI Express configurations: 1x16, 2x8, 1x8+2x4, Supported instruction sets: SSE4.1, SSE4.2. Package type: Retail box



Specification:



Processor
Processor base frequency	4.1 GHz
Processor manufacturer	Intel
Processor codename	Comet Lake
Memory bandwidth supported by processor (max)	41.6 GB/s
Thermal Design Power (TDP)	58 W
Processor cache	4 MB
Processor ARK ID	201901
Processor model	G6405
Processor threads	4
System bus rate	8 GT/s
Processor operating modes	64-bit
Component for	PC
Processor lithography	14 nm
Processor family	Intel® Pentium® Gold
Processor cores	2
Box	Yes
Processor socket	LGA 1200 (Socket H5)
Processor cache type	Smart Cache
Memory
Maximum internal memory supported by processor	128 GB
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2666 MHz
Memory bandwidth supported by processor (max)	41.6 GB/s
Supported memory types	DDR4-SDRAM
Memory channels	Dual-channel
Memory bandwidth (max)	41.6 GB/s
Graphics
Discrete graphics card	No
On-board graphics card maximum resolution (DisplayPort)	4096 x 2304 pixels
On-board graphics card ID	0x9BA8
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)	4096 x 2304 pixels
On-board graphics card 4K support	Yes
On-board graphics card refresh rate at maximum resolution (HDMI)	30 Hz
On-board graphics card refresh rate at maximum resolution (DisplayPort)	60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)	60 Hz
Maximum on-board graphics card memory	64 GB
Number of displays supported (on-board graphics)	3
On-board graphics card maximum resolution (HDMI)	4096 x 2160 pixels
On-board graphics card DirectX version	12.0
On-board graphics card OpenGL version	4.5
On-board graphics card model	Intel® UHD Graphics 610
On-board graphics card	Yes
On-board graphics card dynamic frequency (max)	1050 MHz
On-board graphics card base frequency	350 MHz
Discrete graphics card model	Not available
Power
Thermal Design Power (TDP)	58 W
Technical details
Intel Stable Image Platform Program (SIPP)	No
Thermal solution specification	PCG 2015C
Intel® Secure Key	Yes
Thermal Monitoring Technologies	Yes
Intel® Turbo Boost Technology	No
Intel Trusted Execution Technology	No
Intel® Quick Sync Video Technology	Yes
Intel® InTru™ 3D Technology	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Idle States	Yes
Execute Disable Bit	Yes
Enhanced Intel SpeedStep Technology	Yes
PCI Express slots version	3.0
PCI Express configurations	1x16, 2x8, 1x8+2x4
Supported instruction sets	SSE4.1, SSE4.2
Scalability	1S
Intel VT-x with Extended Page Tables (EPT)	Yes
Embedded options available	No
CPU configuration (max)	1
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel 64	Yes
Thermal Design Power (TDP)	58 W
Supported memory types	DDR4-SDRAM
Status	Launched
Market segment	Desktop
Launch date	Q1'21
Intel Virtualization Technology (VT-x)	Yes
Processor cache type	Smart Cache
Features
On-board graphics card ID	0x9BA8
Maximum number of PCI Express lanes	16
Thermal Design Power (TDP)	58 W
Processor package size	37.5 x 37.5 mm
Processor ARK ID	201901
Thermal solution specification	PCG 2015C
Thermal Monitoring Technologies	Yes
Idle States	Yes
Execute Disable Bit	Yes
PCI Express slots version	3.0
PCI Express configurations	1x16, 2x8, 1x8+2x4
Supported instruction sets	SSE4.1, SSE4.2
Scalability	1S
Embedded options available	No
CPU configuration (max)	1
Market segment	Desktop
Harmonized System (HS) code	85423119
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	G077159
Use conditions	PC/Client/Tablet
Processor special features
Intel Clear Video Technology	Yes
Intel Software Guard Extensions (Intel SGX)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel 64	Yes
Intel Turbo Boost Max Technology 3.0	No
Intel® Optane™ Memory Ready	Yes
Intel® OS Guard	Yes
Intel Stable Image Platform Program (SIPP)	No
Intel® Secure Key	Yes
Intel® Turbo Boost Technology	No
Intel Trusted Execution Technology	No
Intel® Quick Sync Video Technology	Yes
Intel® InTru™ 3D Technology	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Enhanced Intel SpeedStep Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel® Boot Guard	Yes
Intel® Thermal Velocity Boost	No
Intel® vPro™ Platform Eligibility	No
Intel® Transactional Synchronization Extensions	No
Operational conditions
Tjunction	100 °C
Packaging data
Package type	Retail box
Weight & dimensions
Processor package size	37.5 x 37.5 mm
Other features
Maximum internal memory	128 GB
CPU configuration (max)	1
