BX8070811500 - Intel BOXED CORE I5-11500 PROC 4.6GHZ

Intel Core i5-11500. Processor family: Intel® Core™ i5, Processor socket: LGA 1200 (Socket H5), Processor lithography: 14 nm. Memory channels: Dual-channel, Maximum internal memory supported by processor: 128 GB, Memory types supported by processor: DDR4-SDRAM. On-board graphics card model: Intel UHD Graphics 750, Maximum on-board graphics card memory: 64 GB, On-board graphics card base frequency: 350 MHz. Market segment: Desktop, Use conditions: PC/Client/Tablet, PCI Express configurations: 1x16+1x4, 2x8+1x4, 1x8+3x4. Intel® Turbo Boost Technology 2.0 frequency: 4.6 GHz



Specification:



Processor
Processor generation	11th gen Intel® Core™ i5
Processor base frequency	2.8 GHz
Processor manufacturer	Intel
Memory bandwidth supported by processor (max)	50 GB/s
Thermal Design Power (TDP)	65 W
Processor cache	12 MB
Processor ARK ID	212274
Processor model	i5-11600
Processor threads	12
System bus rate	8 GT/s
Processor operating modes	64-bit
Processor boost frequency	4.8 GHz
Component for	PC
Processor lithography	14 nm
Processor family	Intel® Core™ i5
Processor cores	6
Box	Yes
Processor socket	LGA 1200 (Socket H5)
Processor cache type	Smart Cache
Memory
Maximum internal memory supported by processor	128 GB
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	3200 MHz
Memory bandwidth supported by processor (max)	50 GB/s
Supported memory types	DDR4-SDRAM
Memory channels	Dual-channel
Memory bandwidth (max)	50 GB/s
ECC	No
Graphics
Discrete graphics card	No
On-board graphics card maximum resolution (DisplayPort)	5120 x 3200 pixels
Number of execution units	32
On-board graphics card ID	0x4C8A
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)	5120 x 3200 pixels
On-board graphics card 4K support	Yes
On-board graphics card refresh rate at maximum resolution (HDMI)	60 Hz
On-board graphics card refresh rate at maximum resolution (DisplayPort)	60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)	60 Hz
Maximum on-board graphics card memory	64 GB
Number of displays supported (on-board graphics)	3
On-board graphics card maximum resolution (HDMI)	4096 x 2160 pixels
On-board graphics card OpenGL version	4.5
On-board graphics card model	Intel UHD Graphics 750
On-board graphics card	Yes
On-board graphics card dynamic frequency (max)	1300 MHz
On-board graphics card base frequency	350 MHz
Discrete graphics card model	Not available
Power
Thermal Design Power (TDP)	65 W
Technical details
Intel Stable Image Platform Program (SIPP)	Yes
Intel® Secure Key	Yes
Thermal Monitoring Technologies	Yes
Intel® Turbo Boost Technology	2.0
Intel Trusted Execution Technology	Yes
Intel® Quick Sync Video Technology	Yes
Intel® InTru™ 3D Technology	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Idle States	Yes
Execute Disable Bit	Yes
Enhanced Intel SpeedStep Technology	Yes
PCI Express slots version	4.0
PCI Express configurations	1x16+1x4, 2x8+1x4, 1x8+3x4
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0, AVX-512
Scalability	1S
Intel VT-x with Extended Page Tables (EPT)	Yes
Embedded options available	No
CPU configuration (max)	1
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel 64	Yes
Thermal Design Power (TDP)	65 W
Supported memory types	DDR4-SDRAM
Status	Launched
Market segment	Desktop
Launch date	Q1'21
Intel Virtualization Technology (VT-x)	Yes
Processor cache type	Smart Cache
Target market	Gaming
Features
On-board graphics card ID	0x4C8A
Maximum number of PCI Express lanes	20
Thermal Design Power (TDP)	65 W
Processor package size	37.5 x 37.5 mm
Processor ARK ID	212274
Thermal Monitoring Technologies	Yes
Idle States	Yes
Execute Disable Bit	Yes
PCI Express slots version	4.0
PCI Express configurations	1x16+1x4, 2x8+1x4, 1x8+3x4
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0, AVX-512
Scalability	1S
Embedded options available	No
CPU configuration (max)	1
Market segment	Desktop
Harmonized System (HS) code	85423119
Export Control Classification Number (ECCN)	5A992CN3
Commodity Classification Automated Tracking System (CCATS)	G167599
Use conditions	PC/Client/Tablet
Processor special features
Intel Clear Video Technology	Yes
Intel Software Guard Extensions (Intel SGX)	No
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel 64	Yes
Intel Turbo Boost Max Technology 3.0	No
Intel® Optane™ Memory Ready	Yes
Intel® OS Guard	Yes
Intel Stable Image Platform Program (SIPP)	Yes
Intel® Secure Key	Yes
Intel® Turbo Boost Technology	2.0
Intel Trusted Execution Technology	Yes
Intel® Quick Sync Video Technology	Yes
Intel® InTru™ 3D Technology	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Enhanced Intel SpeedStep Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel® Boot Guard	Yes
Intel® Thermal Velocity Boost	No
Intel® Deep Learning Boost (Intel® DL Boost)	Yes
Intel® vPro™ Platform Eligibility	Yes
Intel® Gaussian & Neural Accelerator (Intel® GNA) 2.0	Yes
Intel® Turbo Boost Technology 2.0 frequency	4.8 GHz
Operational conditions
Tjunction	100 °C
Packaging data
Package type	Retail box
Weight & dimensions
Processor package size	37.5 x 37.5 mm
Other features
Maximum internal memory	128 GB
CPU configuration (max)	1
