BX8071512900KF - Intel I9-12900KF UP TO 5.20 GHZ, RTL

Intel Core ® ™ i9-12900KF Processor (30M Cache, up to 5.20 GHz). Processor family: Intel® Core™ i9, Processor socket: LGA 1700, Processor manufacturer: Intel. Memory channels: Dual-channel, Maximum internal memory supported by processor: 128 GB, Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM. Market segment: Desktop, Use conditions: PC/Client/Tablet, PCI Express slots version: 5.0, 4.0. Intel® Turbo Boost Max Technology 3.0 frequency: 5.2 GHz. Package type: Retail box



Specification:



Processor
Processor generation	12th gen Intel® Core™ i9
Processor manufacturer	Intel
Processor codename	Alder Lake
Memory bandwidth supported by processor (max)	76.8 GB/s
Processor cache	30 MB
Processor ARK ID	225916
Processor model	i9-12900KS
Processor threads	24
Processor operating modes	64-bit
Processor boost frequency	5.5 GHz
Bus type	DMI4
Processor family	Intel® Core™ i9
Processor cores	16
Box	Yes
Processor socket	LGA 1700
Processor cache type	Smart Cache
Performance cores	8
Efficient cores	8
Performance-core boost frequency	5.2 GHz
Performance-core base frequency	3.4 GHz
Efficient-core boost frequency	4 GHz
Efficient-core base frequency	2.5 GHz
Processor base power	150 W
Maximum turbo power	241 W
Maximum number of DMI lanes	8
Memory
Maximum internal memory supported by processor	128 GB
Memory types supported by processor	DDR4-SDRAM, DDR5-SDRAM
Memory bandwidth supported by processor (max)	76.8 GB/s
Memory channels	Dual-channel
Memory bandwidth (max)	76.8 GB/s
ECC	Yes
Graphics
Discrete graphics card	No
On-board graphics card outputs supported	Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
On-board graphics card maximum resolution (DisplayPort)	7680 x 4320 pixels
Number of execution units	32
On-board graphics card ID	0x4680
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)	5120 x 3200 pixels
On-board graphics card refresh rate at maximum resolution (HDMI)	60 Hz
On-board graphics card refresh rate at maximum resolution (DisplayPort)	60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)	120 Hz
Number of displays supported (on-board graphics)	4
On-board graphics card maximum resolution (HDMI)	4096 x 2160 pixels
On-board graphics card DirectX version	12.0
On-board graphics card OpenGL version	4.5
On-board graphics card model	Intel UHD Graphics 770
On-board graphics card	Yes
On-board graphics card dynamic frequency (max)	1550 MHz
On-board graphics card base frequency	300 MHz
Discrete graphics card model	Not available
Multi-Format Codec Engines	2
Technical details
Intel® Active Management Technology (Intel® AMT)	Yes
Intel® Secure Key	Yes
Thermal Monitoring Technologies	Yes
Intel® Turbo Boost Technology	2.0
Intel Trusted Execution Technology	Yes
Intel® Quick Sync Video Technology	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Idle States	Yes
Execute Disable Bit	Yes
Enhanced Intel SpeedStep Technology	Yes
PCI Express slots version	4.0, 5.0
PCI Express configurations	1x16+1x4, 2x8+1x4
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Scalability	1S
Intel VT-x with Extended Page Tables (EPT)	Yes
Embedded options available	No
CPU configuration (max)	1
Graphics output	eDP 1.4b, DP 1.4a, HDMI 2.1
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel 64	Yes
Status	Launched
Market segment	Desktop
Launch date	Q1'22
Intel Virtualization Technology (VT-x)	Yes
Processor cache type	Smart Cache
OpenCL version	2.1
Target market	Gaming, Content Creation
Features
On-board graphics card ID	0x4680
Maximum number of PCI Express lanes	20
Processor package size	45 x 37.5 mm
Processor ARK ID	225916
Thermal Monitoring Technologies	Yes
Idle States	Yes
Execute Disable Bit	Yes
PCI Express slots version	4.0, 5.0
PCI Express configurations	1x16+1x4, 2x8+1x4
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Scalability	1S
Embedded options available	No
CPU configuration (max)	1
Market segment	Desktop
Harmonized System (HS) code	85423119
Export Control Classification Number (ECCN)	5A992CN3
Commodity Classification Automated Tracking System (CCATS)	G167599
Use conditions	PC/Client/Tablet
Direct Media Interface (DMI) Revision	4.0
Processor special features
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel 64	Yes
Intel Turbo Boost Max Technology 3.0	Yes
Intel® Speed Shift Technology	Yes
Intel® Optane™ Memory Ready	Yes
Intel® OS Guard	Yes
Intel® Active Management Technology (Intel® AMT)	Yes
Intel® Secure Key	Yes
Intel® Turbo Boost Technology	2.0
Intel Trusted Execution Technology	Yes
Intel® Quick Sync Video Technology	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Enhanced Intel SpeedStep Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel® Boot Guard	Yes
Intel® Thermal Velocity Boost	Yes
Intel® Volume Management Device (VMD)	Yes
Intel® Deep Learning Boost (Intel® DL Boost)	Yes
Mode-based Execute Control (MBE)	Yes
Intel® vPro™ Platform Eligibility	Yes
Intel® Turbo Boost Max Technology 3.0 frequency	5.3 GHz
Intel® Total Memory Encryption	Yes
Intel® Thermal Velocity Boost Temperature	50 °C
Intel® Control-flow Enforcement Technology (CET)	Yes
Intel® Thermal Velocity Boost Frequency	5.5 GHz
Intel® Thread Director	Yes
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0	Yes
Intel® Total Memory Encryption - Multi Key	Yes
Intel® Threat Detection Technology (TDT)	Yes
Intel® Hardware Shield Eligibility	Yes
Intel vPro® Enterprise Platform Eligibility	Yes
Intel® Standard Manageability (ISM)	Yes
Intel® One-Click Recovery	Yes
Intel® Virtualization Technology with Redirect Protection (VT-rp)	Yes
Intel® Adaptive Boost Technology	Yes
Operational conditions
Tjunction	90 °C
Packaging data
Package type	Retail box
Logistics data
Harmonized System (HS) code	85423119
Weight & dimensions
Processor package size	45 x 37.5 mm
Other features
Maximum internal memory	128 GB
CPU configuration (max)	1
Graphics output	eDP 1.4b, DP 1.4a, HDMI 2.1
