BXC80662I76700T - Intel I7-6700T 8M 3.60GHZ

Intel Core i7-6700T. Processor family: Intel® Core™ i7, Processor socket: LGA 1151 (Socket H4), Processor lithography: 14 nm. Memory channels: Dual-channel, Maximum internal memory supported by processor: 64 GB, Memory types supported by processor: DDR4-SDRAM, DDR3L-SDRAM. On-board graphics card model: Intel® HD Graphics 530, Maximum on-board graphics card memory: 64 GB, On-board graphics card outputs supported: Embedded DisplayPort (eDP), DisplayPort, HDMI, DVI. Market segment: Desktop, PCI Express configurations: 1x16, 2x8, 1x8+2x4, Supported instruction sets: SSE4.1, SSE4.2, AVX 2.0. Intel® Turbo Boost Technology 2.0 frequency: 3.6 GHz



Specification:



Processor
Processor generation	6th gen Intel® Core™ i7
Processor base frequency	3.4 GHz
Processor manufacturer	Intel
Cooler included	No
Processor codename	Broadwell E
Thermal Design Power (TDP)	140 W
Processor cache	15 MB
Processor ARK ID	94189
Processor model	i7-6800K
Processor threads	12
Processor operating modes	64-bit
Processor boost frequency	3.6 GHz
Component for	PC
Processor lithography	14 nm
Processor family	Intel® Core™ i7 X-series
Processor cores	6
Box	Yes
Processor socket	LGA 2011-v3
Processor cache type	Smart Cache
Generation	6th Generation
Memory
Maximum internal memory supported by processor	128 GB
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2133,2400 MHz
Supported memory types	DDR4-SDRAM
Memory channels	Quad-channel
ECC	No
Graphics
On-board graphics adapter	No
Power
Thermal Design Power (TDP)	140 W
Technical details
Intel® Turbo Boost Technology	2.0
Intel Trusted Execution Technology	No
Intel® Smart Response Technology	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Idle States	Yes
Execute Disable Bit	Yes
Enhanced Intel SpeedStep Technology	Yes
PCI Express slots version	3.0
Scalability	1S
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Enhanced Halt State	Yes
Embedded options available	No
CPU configuration (max)	1
Product type	Processor
Processor cache	15360 KB
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel 64	Yes
Thermal Design Power (TDP)	140 W
Supported memory types	DDR4-SDRAM
Status	Discontinued
Market segment	Desktop
Launch date	Q2'16
Intel Virtualization Technology (VT-x)	Yes
Intel Smart Response Technology version	1.00
Processor cache type	Smart Cache
Maximum memory	128 GB
Processor brand name	Intel Core i7 X-series Intel Core i7 X-series processor
Last change	63903513
Product family	Intel Core Processors
Intel Turbo Boost Max Technology frequency	3800 MHz
Features
Maximum number of PCI Express lanes	28
Thermal Design Power (TDP)	140 W
Processor ARK ID	94189
Idle States	Yes
Execute Disable Bit	Yes
PCI Express slots version	3.0
Scalability	1S
Embedded options available	No
CPU configuration (max)	1
Market segment	Desktop
Harmonized System (HS) code	8542310001
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	G077159
PCI Express CEM revision	3.0
Processor special features
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel 64	Yes
Conflict-Free processor	Yes
Intel Turbo Boost Max Technology 3.0	Yes
Intel® Turbo Boost Technology	2.0
Intel Trusted Execution Technology	No
Intel® Smart Response Technology	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Enhanced Intel SpeedStep Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Enhanced Halt State	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Smart Response Technology version	1.00
Intel® vPro™ Platform Eligibility	No
Intel® Turbo Boost Max Technology 3.0 frequency	3.8 GHz
Packaging data
Package type	Retail box
Other features
Maximum internal memory	128 GB
Maximum internal memory	131072 MB
CPU configuration (max)	1
