CD8067303533303 - Intel 4GHZ 4CORE XEON PROC W-2125

Intel Xeon W-2125. Processor family: Intel® Xeon®, Processor socket: LGA 2066 (Socket R4), Processor lithography: 14 nm. Memory channels: Quad-channel, Maximum internal memory supported by processor: 512 GB, Memory types supported by processor: DDR4-SDRAM. Market segment: Server, PCI Express configurations: 1x16, 1x4, 1x8, Supported instruction sets: SSE4.2, AVX, AVX 2.0, AVX-512. Processor package size: 45mm x 52.5mm. Maximum internal memory: 512 GB, Maximum internal memory: 524288 MB



Specification:



Processor
Processor base frequency	3.7 GHz
Processor manufacturer	Intel
Cooler included	No
Processor codename	Skylake
Memory bandwidth supported by processor (max)	85.3 GB/s
Thermal Design Power (TDP)	140 W
Processor cache	8.25 MB
Processor ARK ID	126709
Processor model	W-2135
Processor threads	12
System bus rate	8 GT/s
Processor operating modes	64-bit
Processor boost frequency	4.5 GHz
Stepping	U0
Bus type	QPI
Component for	Server/workstation
Processor lithography	14 nm
Processor family	Intel® Xeon®
Processor cores	6
Box	No
Processor socket	LGA 2066 (Socket R4)
Processor code	SR3LN
Memory
Maximum internal memory supported by processor	512 GB
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	1600,1866,2133,2400,2666 MHz
Memory bandwidth supported by processor (max)	85.3 GB/s
Supported memory types	DDR4-SDRAM
Memory channels	Quad-channel
ECC	Yes
Graphics
On-board graphics card	No
Power
Thermal Design Power (TDP)	140 W
Technical details
Intel TSX-NI	Yes
Intel® Secure Key	Yes
Thermal Monitoring Technologies	Yes
Intel® Turbo Boost Technology	2.0
Intel Trusted Execution Technology	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel Flex Memory Access	No
Intel® AES New Instructions (Intel® AES-NI)	Yes
Idle States	Yes
Execute Disable Bit	Yes
Enhanced Intel SpeedStep Technology	Yes
PCI Express slots version	3.0
PCI Express configurations	1x16, 1x4, 1x8
Supported instruction sets	SSE4.2, AVX, AVX 2.0, AVX-512
Scalability	1S
Physical Address Extension (PAE)	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Enhanced Halt State	Yes
Intel Demand Based Switching	Yes
Embedded options available	No
CPU configuration (max)	1
Processor code	SR3LN
Product type	Processor
Processor cache	8448 KB
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel 64	Yes
Thermal Design Power (TDP)	140 W
Supported memory types	DDR4-SDRAM
Status	Launched
Physical Address Extension (PAE)	46 bit
Market segment	Server
Launch date	Q3'17
Intel Virtualization Technology (VT-x)	Yes
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	1.00
Bus type units	GT/s
Maximum memory	512 GB
Intel TSX-NI version	1.00
Processor brand name	Intel Xeon
Last change	63903513
Product family	Intel Xeon Processors
Intel® Speed Shift Technology version	1.00
Intel® Volume Management Device (VMD) version	1.00
AVX-512 Fused Multiply-Add (FMA) units	2
Bus speed	8 GT/s
Features
Maximum number of PCI Express lanes	48
Thermal Design Power (TDP)	140 W
Processor package size	45mm x 52.5mm
Processor ARK ID	126709
Thermal Monitoring Technologies	Yes
Idle States	Yes
Execute Disable Bit	Yes
PCI Express slots version	3.0
PCI Express configurations	1x16, 1x4, 1x8
Supported instruction sets	SSE4.2, AVX, AVX 2.0, AVX-512
Scalability	1S
Physical Address Extension (PAE)	Yes
Embedded options available	No
CPU configuration (max)	1
Processor code	SR3LN
Physical Address Extension (PAE)	46 bit
Market segment	Server
Harmonized System (HS) code	85423119
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	G077159
PCI Express CEM revision	3.0
Processor special features
Intel Software Guard Extensions (Intel SGX)	No
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel 64	Yes
Conflict-Free processor	Yes
Intel Turbo Boost Max Technology 3.0	No
Intel® Speed Shift Technology	Yes
Intel® Memory Protection Extensions (Intel® MPX)	Yes
Intel® Device Protection Technology (Intel® DPT) with Boot Guard	Yes
Intel® Optane™ Memory Ready	No
Intel® OS Guard	Yes
Intel TSX-NI	Yes
Intel® Secure Key	Yes
Intel® Turbo Boost Technology	2.0
Intel Trusted Execution Technology	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel Flex Memory Access	No
Intel® AES New Instructions (Intel® AES-NI)	Yes
Enhanced Intel SpeedStep Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Enhanced Halt State	Yes
Intel Demand Based Switching	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	1.00
Intel TSX-NI version	1.00
AVX-512 Fused Multiply-Add (FMA) units	2
Intel® Boot Guard	Yes
Intel® Volume Management Device (VMD)	Yes
Intel® vPro™ Platform Eligibility	Yes
Intel® Transactional Synchronization Extensions	Yes
Operational conditions
Tcase	64 °C
Packaging data
Package width	1.73" (44 mm)
Package depth	4.57" (116 mm)
Package height	3.98" (101 mm)
Package weight	3.49 oz (99 g)
Package type	Retail box
Weight & dimensions
Processor package size	45mm x 52.5mm
Package width	1.73" (44 mm)
Package depth	4.57" (116 mm)
Package height	3.98" (101 mm)
Package weight	3.49 oz (99 g)
Other features
Maximum internal memory	512 GB
Maximum internal memory	524288 MB
CPU configuration (max)	1
Processor code	SR3LN
