CD8069504248501 - Intel XEON W-3245M PROCESSOR 22M CACHE, 3.20 GHZ

Intel Xeon W-3245M. Processor family: Intel Xeon W, Processor socket: FCLGA3647, Processor lithography: 14 nm. Memory channels: Hexa-channel, Maximum internal memory supported by processor: 2048 GB, Memory types supported by processor: DDR4-SDRAM. Market segment: Server, Supported instruction sets: AVX-512, Scalability: 1S. Intel® Turbo Boost Max Technology 3.0 frequency: 4.6 GHz. Processor package size: 76mm x 56.5mm



Specification:



Processor
Processor base frequency	2.7 GHz
Processor manufacturer	Intel
Cooler included	No
Processor codename	Cascade Lake
Thermal Design Power (TDP)	205 W
Processor cache	33 MB
Processor ARK ID	193750
Processor model	W-3265M
Processor threads	48
System bus rate	8 GT/s
Processor boost frequency	4.4 GHz
Component for	Server/workstation
Processor lithography	14 nm
Processor family	Intel Xeon W
Processor cores	24
Box	No
Processor socket	FCLGA3647
Memory
Maximum internal memory supported by processor	2048 GB
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2933 MHz
Supported memory types	DDR4-SDRAM
Memory channels	Hexa-channel
ECC	Yes
Graphics
Discrete graphics card	No
On-board graphics card model	Not available
On-board graphics card	No
Discrete graphics card model	Not available
Power
Thermal Design Power (TDP)	205 W
Technical details
Intel TSX-NI	Yes
Intel® Turbo Boost Technology	2.0
Intel Trusted Execution Technology	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Execute Disable Bit	Yes
Enhanced Intel SpeedStep Technology	Yes
PCI Express slots version	3.0
Supported instruction sets	AVX-512
Scalability	1S
Intel VT-x with Extended Page Tables (EPT)	Yes
Embedded options available	No
Product type	Processor
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel 64	Yes
Thermal Design Power (TDP)	205 W
Supported memory types	DDR4-SDRAM
Status	Launched
Market segment	Server
Launch date	Q2'19
Intel Virtualization Technology (VT-x)	Yes
Memory speed (max)	2933 MHz
AVX-512 Fused Multiply-Add (FMA) units	2
Bus speed	8 GT/s
Features
Maximum number of PCI Express lanes	64
Thermal Design Power (TDP)	205 W
Processor package size	76mm x 56.5mm
Processor ARK ID	193750
Execute Disable Bit	Yes
PCI Express slots version	3.0
Supported instruction sets	AVX-512
Scalability	1S
Embedded options available	No
Market segment	Server
Harmonized System (HS) code	85423119
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	G077159
PCI Express CEM revision	3.0
Processor special features
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel 64	Yes
Intel Turbo Boost Max Technology 3.0	Yes
Intel® Speed Shift Technology	Yes
Intel TSX-NI	Yes
Intel® Turbo Boost Technology	2.0
Intel Trusted Execution Technology	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Enhanced Intel SpeedStep Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
AVX-512 Fused Multiply-Add (FMA) units	2
Intel® Boot Guard	Yes
Intel® Volume Management Device (VMD)	Yes
Intel® Speed Select technology - Performance Profile (Intel® SST-PP)	No
Intel® Optane™ DC Persistent Memory Supported	No
Intel® Deep Learning Boost (Intel® DL Boost)	Yes
Mode-based Execute Control (MBE)	Yes
Intel® Run Sure Technology	Yes
Intel® Resource Director Technology (Intel® RDT)	No
Intel® vPro™ Platform Eligibility	Yes
Intel® Speed Select Technology - Base Frequency (Intel® SST-BF)	No
Intel® Optane™ DC Persistent Memory technology	No
Intel Speed Select Technology (SST)	No
Intel® Turbo Boost Max Technology 3.0 frequency	4.6 GHz
Intel® Transactional Synchronization Extensions	Yes
Operational conditions
Tcase	78 °C
Logistics data
Harmonized System (HS) code	85423119
Weight & dimensions
Processor package size	76mm x 56.5mm
Other features
Maximum internal memory	2000 GB
