CM8070804400161 - Intel I9-11900K UP TO 5.3GHZ UNLOCKED

Intel Core i9-11900K. Processor family: Intel® Core™ i9, Processor socket: LGA 1200 (Socket H5), Processor lithography: 14 nm. Memory channels: Dual-channel, Maximum internal memory supported by processor: 128 GB, Memory types supported by processor: DDR4-SDRAM. On-board graphics card model: Intel UHD Graphics 750, Maximum on-board graphics card memory: 64 GB, On-board graphics card base frequency: 350 MHz. Market segment: Desktop, Use conditions: PC/Client/Tablet, PCI Express configurations: 1x16+1x4, 2x8+1x4, 1x8+3x4. Intel® Turbo Boost Max Technology 3.0 frequency: 5.2 GHz, Intel® Turbo Boost Technology 2.0 frequency: 5.1 GHz, Intel® Thermal Velocity Boost Temperature: 70 °C



Specification:



Processor
Processor generation	11th gen Intel® Core™ i9
Processor base frequency	3.5 GHz
Processor manufacturer	Intel
Cooler included	No
Configurable TDP-down	95 W
Memory bandwidth supported by processor (max)	50 GB/s
Thermal Design Power (TDP)	125 W
Processor cache	16 MB
Processor ARK ID	212321
Processor model	i9-11900KF
Processor threads	16
System bus rate	8 GT/s
Processor operating modes	64-bit
Processor boost frequency	5.3 GHz
Component for	PC
Processor lithography	14 nm
Processor family	Intel® Core™ i9
Processor cores	8
Box	No
Processor socket	LGA 1200 (Socket H5)
Configurable TDP-down frequency	3 GHz
Processor cache type	Smart Cache
Memory
Maximum internal memory supported by processor	128 GB
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	3200 MHz
Memory bandwidth supported by processor (max)	50 GB/s
Supported memory types	DDR4-SDRAM
Memory channels	Dual-channel
Memory bandwidth (max)	50 GB/s
ECC	No
Graphics
Discrete graphics card	No
On-board graphics card model	Not available
On-board graphics card	No
Discrete graphics card model	Not available
Power
Configurable TDP-down	95 W
Thermal Design Power (TDP)	125 W
Configurable TDP-down frequency	3 GHz
Technical details
Intel Stable Image Platform Program (SIPP)	No
Intel® Secure Key	Yes
Thermal Monitoring Technologies	Yes
Intel® Turbo Boost Technology	2.0
Intel Trusted Execution Technology	No
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Idle States	Yes
Execute Disable Bit	Yes
Enhanced Intel SpeedStep Technology	Yes
PCI Express slots version	4.0
PCI Express configurations	1x16+1x4, 2x8+1x4, 1x8+3x4
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0, AVX-512
Scalability	1S
Intel VT-x with Extended Page Tables (EPT)	Yes
Embedded options available	No
CPU configuration (max)	1
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel 64	Yes
Thermal Design Power (TDP)	125 W
Supported memory types	DDR4-SDRAM
Status	Launched
Market segment	Desktop
Launch date	Q1'21
Intel Virtualization Technology (VT-x)	Yes
Configurable TDP-down frequency	3 GHz
Processor cache type	Smart Cache
Target market	Gaming, Content Creation
Features
Maximum number of PCI Express lanes	20
Thermal Design Power (TDP)	125 W
Processor package size	37.5 x 37.5 mm
Processor ARK ID	212321
Thermal Monitoring Technologies	Yes
Idle States	Yes
Execute Disable Bit	Yes
PCI Express slots version	4.0
PCI Express configurations	1x16+1x4, 2x8+1x4, 1x8+3x4
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0, AVX-512
Scalability	1S
Embedded options available	No
CPU configuration (max)	1
Market segment	Desktop
Harmonized System (HS) code	85423119
Export Control Classification Number (ECCN)	5A992CN3
Commodity Classification Automated Tracking System (CCATS)	G167599
Use conditions	PC/Client/Tablet
Processor special features
Intel Software Guard Extensions (Intel SGX)	No
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel 64	Yes
Intel Turbo Boost Max Technology 3.0	Yes
Intel® Optane™ Memory Ready	Yes
Intel® OS Guard	Yes
Intel Stable Image Platform Program (SIPP)	No
Intel® Secure Key	Yes
Intel® Turbo Boost Technology	2.0
Intel Trusted Execution Technology	No
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Enhanced Intel SpeedStep Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel® Boot Guard	Yes
Intel® Thermal Velocity Boost	Yes
Intel® Deep Learning Boost (Intel® DL Boost)	Yes
Intel® vPro™ Platform Eligibility	No
Intel® Gaussian & Neural Accelerator (Intel® GNA) 2.0	Yes
Intel® Turbo Boost Technology 2.0 frequency	5.1 GHz
Intel® Turbo Boost Max Technology 3.0 frequency	5.2 GHz
Intel® Thermal Velocity Boost Temperature	70 °C
Intel® Thermal Velocity Boost Frequency	5.3 GHz
Operational conditions
Tjunction	100 °C
Packaging data
Package type	Retail box
Weight & dimensions
Processor package size	37.5 x 37.5 mm
Other features
Maximum internal memory	128 GB
CPU configuration (max)	1
