CM8070804495913 - Intel INTEL XEON E-2334 PROCESSOR

Intel Xeon ® ® E-2334 Processor (8M Cache, 3.40 GHz). Processor family: Intel Xeon E, Processor socket: LGA 1200 (Socket H5), Processor lithography: 14 nm. Memory channels: Dual-channel, Maximum internal memory supported by processor: 128 GB, Memory types supported by processor: DDR4-SDRAM. Market segment: Server, PCI Express configurations: 1x16+1x4, 2x8+1x4, 1x8+3x4, Supported instruction sets: SSE4.1, SSE4.2, AVX 2.0, AVX-512. Intel® Turbo Boost Technology 2.0 frequency: 4.8 GHz, Maximum Enclave Size Support for Intel® SGX: 0.5 GB. Package type: Retail box



Specification:



Processor
Processor base frequency	2.8 GHz
Processor manufacturer	Intel
Cooler included	No
Thermal Design Power (TDP)	65 W
Processor cache	8 MB
Processor ARK ID	212259
Processor model	E-2314
Processor threads	4
System bus rate	8 GT/s
Processor operating modes	64-bit
Processor boost frequency	4.5 GHz
Component for	Server/workstation
Processor lithography	14 nm
Processor family	Intel Xeon E
Processor cores	4
Box	No
Processor socket	LGA 1200 (Socket H5)
Processor cache type	Smart Cache
Memory
Maximum internal memory supported by processor	128 GB
Memory types supported by processor	DDR4-SDRAM
Supported memory types	DDR4-SDRAM
Memory channels	Dual-channel
ECC	Yes
Graphics
Discrete graphics card	No
On-board graphics card model	Not available
On-board graphics card	No
Discrete graphics card model	Not available
Power
Thermal Design Power (TDP)	65 W
Technical details
Intel® Secure Key	Yes
Thermal Monitoring Technologies	Yes
Intel® Turbo Boost Technology	2.0
Intel Trusted Execution Technology	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® AES New Instructions (Intel® AES-NI)	Yes
Idle States	Yes
Execute Disable Bit	Yes
Enhanced Intel SpeedStep Technology	Yes
PCI Express slots version	4.0
PCI Express configurations	1x16+1x4, 2x8+1x4, 1x8+3x4
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0, AVX-512
Scalability	1S
Intel VT-x with Extended Page Tables (EPT)	Yes
CPU configuration (max)	1
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel 64	Yes
Thermal Design Power (TDP)	65 W
Supported memory types	DDR4-SDRAM
Status	Launched
Market segment	Server
Launch date	Q3'21
Intel Virtualization Technology (VT-x)	Yes
Processor cache type	Smart Cache
Features
Maximum number of PCI Express lanes	20
Thermal Design Power (TDP)	65 W
Processor package size	37.5 x 37.5 mm
Processor ARK ID	212259
Thermal Monitoring Technologies	Yes
Idle States	Yes
Execute Disable Bit	Yes
PCI Express slots version	4.0
PCI Express configurations	1x16+1x4, 2x8+1x4, 1x8+3x4
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0, AVX-512
Scalability	1S
CPU configuration (max)	1
Market segment	Server
Harmonized System (HS) code	85423119
Export Control Classification Number (ECCN)	5A992CN3
Commodity Classification Automated Tracking System (CCATS)	G167599
Processor special features
Intel Software Guard Extensions (Intel SGX)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel 64	Yes
Intel® Memory Protection Extensions (Intel® MPX)	Yes
Intel® OS Guard	Yes
Intel® Secure Key	Yes
Intel® Turbo Boost Technology	2.0
Intel Trusted Execution Technology	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® AES New Instructions (Intel® AES-NI)	Yes
Enhanced Intel SpeedStep Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel® Boot Guard	Yes
Intel® Optane™ DC Persistent Memory Supported	No
Intel® vPro™ Platform Eligibility	Yes
Intel® Turbo Boost Technology 2.0 frequency	4.5 GHz
Intel® Transactional Synchronization Extensions	No
Maximum Enclave Size Support for Intel® SGX	0.5 GB
Operational conditions
Tjunction	100 °C
Logistics data
Harmonized System (HS) code	85423119
Weight & dimensions
Processor package size	37.5 x 37.5 mm
Other features
Maximum internal memory	128 GB
CPU configuration (max)	1
