DGS-108 - D-Link UNMANAGED GIGABIT SWITCH. 8-PORT GIGABIT UNMANAGED DESKTOP METAL SWITCH. LIMITED

Effortless Gigabit Networking With data transfer speeds of up to 2000 Mbps on Gigabit Ethernet, the D-Link DGS-108 8 Port Gigabit Switch is ideal for transferring files quickly. Featuring easy access front Ethernet ports with two color LED indicators per port to quickly distinguish link status. The switch supports IEEE 802.1p QoS, which organizes and prioritizes time-sensitive and important data for efficient delivery, allowing for smooth streaming media, VoIP calling, and online gaming. Additionally the switch incorporates a Kensington Security Slot on the rear panel allowing users to securely fasten the unit to a table or desk. Think Green The DGS-108 is a plug-and-play networking switch that offers D-Link€™s Green Technology to save energy and reduce heat, which in turn extends product life without sacrificing performance or functionality. The switch supports IEEE 802.3az Energy-Efficient Ethernet (EEE) which detects when a connected computer is shut down or when there is no Ethernet traffic, at which time the switch will automatically power down the idle port, saving a substantial amount of power. In addition, the switch can also save energy by detecting the length of cable connected to a port and only using as much power as is necessary. Working together these features drastically reduce power consumption and heat dissipation, resulting in extended life and substantial cost savings. Environmentally Friendly The DGS-108 Gigabit switch was designed with the environment in mind. It is compliant with Energy Star Level V, CEC, and MEPS regulations which require the use of energy efficient power adapters. Built to comply with RoHS standards to minimize use of hazardous materials and is packaged with an EnergyStar Level V qualified power adapter all in a recyclable packaging making this product truly environmental friendly.



Specification:



Ports & interfaces
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Basic switching RJ-45 Ethernet ports quantity	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Technical details
Product colour	Black
Mean time between failures (MTBF)	1402428 h
Housing material	Metal
Management features
Switch type	Unmanaged
Quality of Service (QoS) support	Yes
Network
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Networking standards	IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Flow control support	Yes
Auto MDI/MDI-X	Yes
Data transmission
Jumbo frames	9216
MAC address table	4000 entries
Switching capacity	16 Gbit/s
Store-and-forward	Yes
Number of queues	8
Jumbo frames support	Yes
Forwarding rate	11.9 Mpps
Design
Product colour	Black
LED indicators	Activity, Link, Power
Housing material	Metal
Performance
Mean time between failures (MTBF)	1402428 h
Harmonized System (HS) code	85176990
Indication
LED indicators	Activity, Link, Power
Power
Power consumption (max)	4.31 W
Input current	1 A
DC input voltage	5 V
Operational conditions
Storage temperature (T-T)	-10 - 65 °C
Storage relative humidity (H-H)	5 - 95%
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90%
Heat dissipation	14.7 BTU/h
Weight & dimensions
Width	5.51" (140 mm)
Depth	2.64" (67 mm)
Height	1.02" (26 mm)
Weight	8.47 oz (240 g)
Logistics data
Harmonized System (HS) code	85176990
