Description
Universal Hybrid Dock | USB Type-C & USB Type-A | Dual 4K 60Hz HDMI & DisplayPortTransition from the legacy USB-A (USB 3.1/3.0) to newer USB-C laptops with this universal laptop docking station for USB-C and USB-A laptops. The USB 3.1 Gen 1 (5 Gbps) Type-C dock features dual HDMI and/or DisplayPort monitors, six USB Type-A downstream peripheral ports, and headset audio.Flexible Monitor ConnectionsThis is a dual 4K60Hz video docking station with support for both Ultra HD DisplayPort and/or HDMI monitors that lets you configure your video connections to best suit your needs.•Dual 4K DisplayPort | Up to 4096 x 2160p @ 60Hz•Dual 4K HDMI | Up to 4096 x 2160p @ 60Hz•Single 4K DisplayPort + Single 4K HDMI | Up to 4096 x 2160p @ 60Hz•Single 5K DisplayPort * | Up to 5120 × 2880*Requires monitor support for 5K using two DP portsCertified for Maximum Compatibility & PerformanceThis docking station is fully certified to meet top industry standards for DisplayLink (video connections) certification to guarantee the highest quality, performance, and compatibility.Flexible Setup OptionsFor fast setup right out of the box, the two included host cables (USB-C and USB-A) connect to any laptop. The included dock stand lets you position the dock vertically to save space or lay flat on the desk.The Connections You NeedConnect your devices with six downstream USB Type-A (USB 3.0 5 Gbps) ports, two positioned on the front, and four on the back. The dock provides a GbE port and a 3.5 mm 4-position headset audio jack.Enhance Productivity and Device Management with the StarTech.com Connectivity Tools ApplicationDeveloped to improve performance and security, StarTech.com Connectivity Tools is the only software suite on the market that works with a wide range of IT connectivity accessories. The software suite includes:•Advanced Windows Layout Utility : To setup and save custom windows layouts.•Mac Address Pass-Through Utility : To improve network security.•USB Event Monitoring Utility : To track and log connected USB devices•Wi-Fi Auto Switch Utility : Enabling users to quickly access faster network speeds via wired LAN.For more information and to download the StarTech.com Connectivity Tools application, please visit: www.StarTech.com/Connectivity-ToolsThe IT Pro's Choice Since 1985StarTech.com conducts thorough compatibility and performance testing on all our products to ensure we are meeting or exceeding industry standards and providing high-quality products to IT Professionals. Our local StarTech.com Technical Advisors have broad product expertise and work directly with our StarTech.com Engineers to provide support for our customers both pre and post-sales.DK30A2DHU is backed by a StarTech.com 3-year warranty and free lifetime technical support.The StarTech.com Advantage
Specification:
Ports & interfaces | |
---|---|
Combo headphone/mic port | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 6 |
Headphone connectivity | 3.5 mm |
Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-B |
Ethernet LAN (RJ-45) ports | 1 |
HDMI ports quantity | 1 |
DVI-I ports quantity | 1 |
Headphone outputs | 1 |
DC-in jack | Yes |
Connectivity technology | Wired |
Network | |
Full duplex | Yes |
Auto MDI/MDI-X | Yes |
Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
Wake-on-LAN ready | Yes |
Ethernet LAN | Yes |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Ethernet LAN (RJ-45) ports | 1 |
Performance | |
UASP support | Yes |
Maximum digital resolution | 2048 x 1152 pixels |
Full duplex | Yes |
Auto MDI/MDI-X | Yes |
Number of displays supported | 2 |
On/off switch | Yes |
Product colour | Black, Silver |
Card reader integrated | No |
Brand compatibility | Any brand |
LED indicators | Power |
Data transfer rate | 5 Gbit/s |
Certification | CE, FCC, DisplayLink, REACH |
Housing material | Plastic |
Technical details | |
Product colour | Black, Silver |
Brand compatibility | Any brand |
Data transfer rate | 5 Gbit/s |
Cable length | 39.4" (1 m) |
Sustainability certificates | RoHS |
Harmonized System (HS) code | 84733020 |
Products per master (outer) case | 10 pc(s) |
Master (outer) case width | 12.4" (315 mm) |
Master (outer) case length | 12.8" (325 mm) |
Master (outer) case height | 11.6" (295 mm) |
Storage | |
Card reader integrated | No |
Power | |
Power source type | AC |
Input current | 1 A |
Power plug type | Type N |
Compatible power plug types | AU, EU, JP, UK, US |
AC input voltage | 100 - 240 V |
Power consumption (typical) | 40 W |
Output voltage | 20 V |
Output current | 2 A |
Software | |
Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 |
Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 13.0 Ventura |
Indication | |
LED indicators | Power |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -10 - 70 °C |
Operating relative humidity (H-H) | 10 - 90% |
Sustainability | |
Sustainability certificates | RoHS |
Weight & dimensions | |
Weight | 10.3 oz (291 g) |
Width | 3.39" (86.2 mm) |
Depth | 8.5" (216 mm) |
Height | 1.22" (31 mm) |
Package weight | 28.2 oz (800 g) |
Package width | 5.51" (140 mm) |
Package depth | 12.1" (307 mm) |
Package height | 2.36" (60 mm) |
Design | |
Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 |
Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 13.0 Ventura |
Product colour | Black, Silver |
LED indicators | Power |
Certification | CE, FCC, DisplayLink, REACH |
Packaging data | |
Package weight | 28.2 oz (800 g) |
Package width | 5.51" (140 mm) |
Package depth | 12.1" (307 mm) |
Package height | 2.36" (60 mm) |
Packaging content | |
Quick start guide | Yes |
Cables included | USB |
AC adapter included | Yes |
Certificates | |
Certification | CE, FCC, DisplayLink, REACH |
Logistics data | |
Products per master (outer) case | 10 pc(s) |
Master (outer) case width | 12.4" (315 mm) |
Master (outer) case length | 12.8" (325 mm) |
Master (outer) case height | 11.6" (295 mm) |
Other features | |
Chipset | DisplayLink - DL-3900, VIA/VLI - VL813 |
Cable length | 39.4" (1 m) |
