Gigabyte
GB-BLCE-4105R - Gigabyte FEATURES INTEL CELERON PROCESSOR J4105 ULTRA COMPACT PC DESIGN AT ONLY 0.67L (56
GB-BLCE-4105R - Gigabyte FEATURES INTEL CELERON PROCESSOR J4105 ULTRA COMPACT PC DESIGN AT ONLY 0.67L (56
SKU:GB-BLCE-4105R
Regular price
$220.31 USD
Regular price
Sale price
$220.31 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
The Perfect Fit for Any Space Challenging the essence of how we define a desktop PC, GIGABYTE engineers have developed an ultra compact PC with pure black stylish chassis design. Ideal for a broad range of computing applications at home or in the office, the BRIX expounds sheer simplicity and convenience. With a broad choice of processors covering the entire performance spectrum, the BRIX sets a new standard for desktop miniaturization that makes it perfect as a discreet HTPC/multimedia hub, an ultra-low power PC for the family, an office PC or as a digital signage unit. Intel® Pentium® Silver and Celeron® Processor GIGABYTE BRIX supports Intel third-generation low-power quad-core SoC processors which feature power-efficient 10W Intel Celeron models. From a simple internet access point to a high end multimedia station, the GIGABYTE BRIX a broad range of usage scenarios and the ultimate space flexibility. GIGABYTE BRIX is expected to deliver up to 23% improvement in productivity over previous generation. Connecting the Future The USB Type-C™ is a new reversible connector that is loaded with useful features such as USB 3.0 support for 5 Gb/s transfer speed. GIGABYTE BRIX™ also includes a M.2 module offering IEEE 802.11ac Wi-Fi and the latest Bluetooth 4.2, providing connectivity for low power Bluetooth users to easily connect mobile devices. Support HDMI 2.0a & HDMI 1.4b Dual Output HDMI 2.0, which is backwards compatible with HDMI 1.4, offers 18 Gb/s of bandwidth – nearly twice that of the previous generation. This unlocks the potential for users to transfer multiple video streams, as well as a native cinematic 21:9 ratio (which most movies are shot in), offering the best visual experience for viewers. With two HDMI outputs, GIGABYTE BRI can power two displays simultaneously, making it a perfect choice as a high productivity device in IoT applications. RS232 COM Port Support GIGABYTE BRIX is equipped with 1 x COM Port to support RS232, it can be easily used in a variety of commercial applications, such as Security system, Vending machine, ATM system, KIOSK, and so on. Support DDR4 Memory GIGABYTE BRIX provides a 128-bit memory controller that supports DDR4 at up to 2400MHz. DDR4 is a type of synchronous dynamic random-access memory with a double data rate and high bandwidth interface. The primary advantages of DDR4 over its predecessor, DDR3, include higher module density and lower voltage requirements, coupled with higher data rate transfer speeds. Enjoy Always Available Responsiveness With Intel® Ready Mode Technology Now there’s no waiting to resume activity on your PC. With Intel® Ready Mode Technology, your PC resumes to fully functional in an instant. It works by providing an alternative to traditional sleep-a quiet, low power state similar to the kind used by your cell phone and tablet. Access Your Digital Files From Anywhere, Anytime Get remote access to your PC through applications on your phone and tablet to download photos, video, large files and more, no matter where you are. Get Help From Your Digital Assistant Just by Asking An always available PC complements Microsoft Windows® 10 enabled experiences Cortana*. When you need Cortana*, all you have to do is say "Hey Cortana," and your digital assistant is instantly at your service. Access Your Digital Files From Anywhere, Anytime Get remote access to your PC through applications on your phone and tablet to download photos, video, large files and more, no matter where you are. VESA Support Bundled with a VESA bracket, the GIGABYTE BRIX™ can easily be mounted behind a monitor or HDTV, offering a simple and effective way to turn any VESA-compliant display or TV into a full-featured PC or digital signage unit.
Specification:
| Motherboard | |
|---|---|
| Processor socket | BGA 1440 |
| Number of processors supported | 1 |
| Motherboard chipset | HM175 |
| Compatible processor series | Intel Core i7 |
| Processor | |
| Thermal Design Power (TDP) | 45 W |
| Built-in processor | Yes |
| Processor model | i7-7700HQ |
| Processor boost frequency | 3.8 GHz |
| Processor threads | 8 |
| Processor frequency | 2.8 GHz |
| Processor socket | BGA 1440 |
| Processor lithography | 14 nm |
| Processor cores | 4 |
| Processor family | Intel Core i7 |
| Number of processors supported | 1 |
| Motherboard chipset | HM175 |
| Compatible processor series | Intel Core i7 |
| Processor manufacturer | Intel |
| Processor series | Intel Core i7-7700 Mobile Series |
| Processor codename | Kaby Lake |
| CPU configuration (max) | 1 |
| Processor generation | 7th gen Intel® Core™ i7 |
| Memory | |
| Memory slots type | SO-DIMM |
| Number of memory slots | 2 |
| Supported memory types | DDR4-SDRAM |
| Supported memory clock speeds | 2133 MHz |
| Maximum internal memory | 64 GB |
| Video | |
| On-board graphics adapter | Yes |
| Graphics adapter family | NVIDIA |
| Maximum graphics adapter memory | 6000 MB |
| Graphics adapter memory type | GDDR5 |
| Storage | |
| Supported storage drive types | HDD & SSD |
| Storage drive sizes supported | 2.5" |
| Storage drive interface | M.2 |
| Graphics | |
| Maximum resolution | 4096 x 2160 pixels |
| On-board graphics adapter | Yes |
| Graphics adapter family | NVIDIA |
| Maximum graphics adapter memory | 6000 MB |
| Graphics adapter memory type | GDDR5 |
| Discrete graphics adapter model | NVIDIA® GeForce® GTX 1060 |
| Audio | |
| Audio system | Realtek ALC255 |
| Network | |
| Wi-Fi standards | Wi-Fi 5 (802.11ac) |
| Bluetooth version | 4.2 |
| Bluetooth | Yes |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| LAN controller | Intel I219LM |
| Ports & interfaces | |
| DisplayPort version | 1.3 |
| DC-in jack | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| HDMI version | 2.0 |
| Mini DisplayPorts quantity | 2 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| HDMI ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| Expansion slots | |
| PCI Express slots version | 3.0 |
| PCI Express configurations | 1x16,1x8,2x4,2x8 |
| Design | |
| Product type | Mini PC barebone |
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| Product colour | Black |
| Chassis type | 2.6L sized PC |
| Performance | |
| Maximum resolution | 4096 x 2160 pixels |
| Processor socket | BGA 1440 |
| Number of processors supported | 1 |
| Motherboard chipset | HM175 |
| Compatible processor series | Intel Core i7 |
| Compatible operating systems | Win10 64bit |
| Audio system | Realtek ALC255 |
| Software | |
| Compatible operating systems | Win10 64bit |
| Processor special features | |
| Intel TSX-NI | No |
| Intel® Smart Response Technology | Yes |
| Intel® Smart Cache | Yes |
| Intel® Secure Key | Yes |
| Intel® OS Guard | Yes |
| Intel Stable Image Platform Program (SIPP) | No |
| Thermal Monitoring Technologies | Yes |
| Intel® Wireless Display (Intel® WiDi) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel Trusted Execution Technology | No |
| Intel® Quick Sync Video Technology | Yes |
| Intel® My WiFi Technology (Intel® MWT) | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel Flex Memory Access | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel 64 | Yes |
| Idle States | Yes |
| Execute Disable Bit | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Clear Video Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Virtualization Technology (Intel® VT) | VT-d,VT-x |
| Embedded options available | No |
| Intel Virtualization Technology (VT-x) | Yes |
| Colour | |
| Product colour | Black |
| Technical details | |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| Intel® Virtualization Technology (Intel® VT) | VT-d,VT-x |
| Embedded options available | No |
| Processor cores | 4 |
| Chassis type | 2.6L sized PC |
| Power | |
| AC input voltage | 100 - 240 V |
| AC adapter output voltage | 19.5 V |
| AC adapter output current | 9.23 A |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating temperature (T-T) | 0 - 35 °C |
| Weight & dimensions | |
| Width | 4.33" (110 mm) |
| Depth | 4.33" (110 mm) |
| Height | 8.66" (220 mm) |
| Other features | |
| Embedded options available | No |
| Chassis type | 2.6L sized PC |
