Intel COMPUTE MODULE HNS2600TP24STR, SINGLE

Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption. Intel® Quiet Thermal Technology is a series of thermal and acoustic management innovations that reduce unnecessary acoustic noise and provide cooling flexibility while maximizing efficiency . The technology includes capabilities such as advanced thermal sensory arrays, advanced cooling algorithms, and built in fail-safe shutdown protection. Internal IO expansion module indicates a mezzanine connector on Intel® Server Boards that supports a variety of Intel(r) I/O Expansion Modules using a x8 PCI Express* interface. These modules are either RoC (RAID-on-Chip) or SAS (Serial Attached SCSI) modules that are not used for external connectivity through the rear I/O panel.



Specification:



Technical details
Discrete graphics adapter model	support
Motherboard chipset	Intel® C612
PCI Express slots quantity	2
On-board graphics adapter	Yes
Number of processors supported	2
Number of DIMM slots	16
Intel Trusted Execution Technology	No
Intel I/O Acceleration Technology	Yes
Intel Flex Memory Access	Yes
Intel Fast Memory Access	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Embedded options available	No
CPU configuration (max)	2
Component for	Server
Graphics output	VGA
USB version	2.0
USB ports quantity	4
Thermal Design Power (TDP)	145 W
Product type	Server/Workstation Board
Maximum number of PCI Express lanes	80
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Memory bandwidth supported by processor (max)	115 GB/s
ECC supported by processor	Yes
Total number of SATA connectors	10
Maximum internal memory supported by processor	1024 GB
Memory bandwidth (max)	115 GB/s
Status	Launched
Market segment	Server
Launch date	Q1'16
Supported RAID configuration	up to SW Raid 5 (LSI or RSTE)
Last change	63903513
Expected discontinuance date	Q3'20
Form factor	Custom 6.8" x 18.9"
Last receipt attributes date	Monday, October 5, 2020
Last order date	Sunday, July 5, 2020
End of life date announce	Friday, July 19, 2019
Additional information URL	http://www.intel.com/content/www/us/en/motherboards/server-motherboards/server-board-s2600tp.html
Riser slot 1 number of lanes	16
Riser slot 2 number of lanes	24
Riser slot 3 number of lanes	24
Riser slot 4 number of lanes	16
Performance
Motherboard ARK ID	88297
Motherboard chipset	Intel® C612
Intel Trusted Execution Technology	No
Intel I/O Acceleration Technology	Yes
Intel Flex Memory Access	Yes
Intel Fast Memory Access	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Component for	Server
Processor
Processor manufacturer	Intel
Thermal Design Power (TDP)	145 W
Maximum number of PCI Express lanes	80
Memory bandwidth supported by processor (max)	115 GB/s
ECC supported by processor	Yes
Maximum internal memory supported by processor	1024 GB
Processor thermal power (max)	160 W
Intel Xeon series	E5-2600
Processor socket	LGA 2011-v3
Product family	Intel compute module
Product series	Intel HNS2600TP
Product codename	Taylor Pass
Processor number of cores supported	4,8,10,12,14,16
Number of QPI links	2
Lithography	22 nm
Memory
Memory bandwidth (max)	115 GB/s
Supported memory types	DDR4-SDRAM
Memory channels	Octa-channel
ECC	Yes
Supported memory clock speeds	1600,1866 MHz
Maximum internal memory	1024 GB
Storage controllers
Supported storage drive interfaces	SATA
RAID support	Yes
Graphics
On-board graphics adapter	Yes
Discrete graphics support	Yes
Internal I/O
Total number of SATA connectors	10
Supported storage drive interfaces	SATA
Number of SATA connectors	10
Rear panel I/O ports
USB 2.0 ports quantity	4
VGA (D-Sub) ports quantity	1
Serial ports quantity	1
Ethernet LAN (RJ-45) ports	2
Network
Ethernet LAN	Yes
Wi-Fi	No
Wake-on-LAN ready	Yes
Ethernet interface type	Gigabit Ethernet
Features
Motherboard ARK ID	88297
Motherboard chipset	Intel® C612
Component for	Server
Market segment	Server
Harmonized System (HS) code	8473301180
Rack-Friendly board	Yes
Physical Address Extension (PAE)	Yes
Physical Address Extension (PAE)	46 bit
Expansion slots
PCI Express x16 (Gen 3.x) slots	1
PCI Express slots version	3.0
PCI Express CEM revision	3.0
Processor special features
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel Trusted Execution Technology	No
Intel I/O Acceleration Technology	Yes
Intel Flex Memory Access	Yes
Intel Fast Memory Access	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel Server Management Software	Yes
Intel Server Customization Technology	Yes
Intel Remote Management Module Support	Yes
Intel Quiet Thermal Technology	Yes
Intel Intelligent Power Node Manager	Yes
Intel Efficient Power Technology	Yes
Intel Build Assurance Technology	Yes
Intel Advanced Management Technology	Yes
Connector for Intel I/O Expansion Module x8 Gen 3	1
Integrated systems available	No
Video
Discrete graphics support	Yes
Design
Product family	Intel compute module
Product series	Intel HNS2600TP
Product codename	Taylor Pass
Weight & dimensions
Width	6.8" (172.7 mm)
Depth	16.1" (408.1 mm)
Other features
Thermal Design Power (TDP)	145 W
Motherboard ARK ID	88297
Discrete graphics adapter model	support
PCI Express slots quantity	2
Number of processors supported	2
Number of DIMM slots	16
Intel Xeon series	E5-2600
Embedded options available	No
CPU configuration (max)	2
Graphics output	VGA
PCI Express CEM revision	3.0
Packaging content	Integrated compute module includes: (1) Intel Server Board S2600TPR w/two 1Gb ports (Intel Ethernet Controller I350); (1) 6Gb/s bridge board (FHWKPTPBGB); (1) node power board (FH2000NPB2); (1) one slot PCIe x16 riser card (FHW1U16RISER2); (1) front 1U passive heat sinks (FXXEA84X106HS); (1) rear 1U passive heat sink (FXXCA91X91HS); (3) 4056 dual rotor fan (FXX4056DRFAN2); (1) airduct; (1) 1U node tray
Chassis type	Rack
Intel Node Manager	Yes
