Description
| Design | |
|---|---|
| Product type | Notebook |
| Market positioning | Business |
| Form factor | Clamshell |
| Product colour | Gray |
| Introduction year | 2022 |
| Display | |
| HD type | Full HD |
| Pixel density | 157 ppi |
| Panel type | WVA |
| LED backlight | Yes |
| Display brightness | 250 cd/m² |
| Display response rise/fall | 25 ms |
| Pixel pitch | 0.00705 x 0.00705" (0.179 x 0.179 mm) |
| Contrast ratio (typical) | 700:1 |
| Touchscreen | No |
| Display resolution | 1920 x 1080 pixels |
| Display diagonal | 14" |
| Anti-glare screen | Yes |
| Maximum refresh rate | 60 Hz |
| RGB colour space | NTSC |
| Colour gamut | 45% |
| Native aspect ratio | 16:9 |
| Processor | |
| Processor generation | 12th gen Intel® Core™ i7 |
| Configurable TDP-down | 12 W |
| Processor cache type | Smart Cache |
| Processor cache | 12 MB |
| Processor model | i7-1255U |
| Processor boost frequency | 4.7 GHz |
| Processor cores | 10 |
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i7 |
| Memory | |
| Memory form factor | SO-DIMM |
| Internal memory | 16 GB |
| Memory layout (slots x size) | 2 x 8 GB |
| Internal memory type | DDR4-SDRAM |
| Memory clock speed | 3200 MHz |
| Memory slots | 2x SO-DIMM |
| Maximum internal memory | 64 GB |
| Storage | |
| SSD form factor | M.2 |
| Storage media | SSD |
| Optical drive type | No |
| Number of SSDs installed | 1 |
| SSD capacity | 256 GB |
| SSD interface | PCI Express |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Total storage capacity | 256 GB |
| Total SSDs capacity | 256 GB |
| SSD performance class | 35 |
| NVMe | Yes |
| Graphics | |
| Discrete graphics card | No |
| On-board graphics card | Yes |
| On-board graphics card model | Intel Iris Xe Graphics |
| Discrete graphics card model | Not available |
| Maximum on-board graphics card resolution | 7680 x 4320 pixels |
| Audio | |
| Audio chip | Realtek ALC3204 |
| Number of microphones | 2 |
| Audio system | MaxxAudio Pro |
| Number of built-in speakers | 2 |
| Speaker power | 2 W |
| Built-in microphone | Yes |
| Camera | |
| Front camera | Yes |
| Video capturing speed | 30 fps |
| Front camera HD type | Full HD |
| Infrared (IR) camera | Yes |
| Optical drive | |
| Optical drive type | No |
| Network | |
| Mobile network connection | No |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| Near Field Communication (NFC) | Yes |
| Wi-Fi standards | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 6E (802.11ax) |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Bluetooth | Yes |
| Bluetooth version | 5.2 |
| WWAN | Installed |
| Wi-Fi data rate (max) | 2400 Mbit/s |
| Antenna type | 2x2 |
| WLAN controller manufacturer | Intel |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| HDMI ports quantity | 1 |
| HDMI version | 2.0 |
| Ethernet LAN (RJ-45) ports | 1 |
| Combo headphone/mic port | Yes |
| USB Power Delivery | Yes |
| PowerShare | Yes |
| Number of USB ports with PowerShare support | 1 |
| Charging port type | USB Type-C |
| Thunderbolt 4 ports quantity | 2 |
| Intel® Thunderbolt 4 | Yes |
| Keyboard | |
| Pointing device | Clickpad |
| Numeric keypad | No |
| Keyboard backlit | Yes |
| Software | |
| Operating system architecture | 64-bit |
| Operating system installed | Windows 10 Pro |
| Windows 11 free upgrade | Yes |
| Technical details | |
| Market positioning | Business |
| Form factor | Clamshell |
| Product colour | Gray |
| Processor special features | |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel Flex Memory Access | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Execute Disable Bit | Yes |
| Embedded options available | No |
| CPU configuration (max) | 1 |
| Intel Virtualization Technology (VT-x) | Yes |
| Battery | |
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 4 |
| Battery capacity | 58 Wh |
| Battery recharge time | 4 h |
| Battery voltage | 7.6 V |
| Fast charging | Yes |
| Battery weight | 8.11 oz (230 g) |
| Power | |
| AC adapter power | 65 W |
| AC adapter frequency | 50/60 Hz |
| AC adapter input voltage | 100 - 240 V |
| USB charging voltage | 20,5,9,15 V |
| USB charging current | 3.25 A |
| Security | |
| Password protection | Yes |
| Trusted Platform Module (TPM) | Yes |
| Cable lock slot | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 35 °C |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | -598.4 - 120000" (-15.2 - 3048 m) |
| Non-operating altitude | -598.4 - 420000" (-15.2 - 10668 m) |
| Operating shock | 110 G |
| Non-operating shock | 160 G |
| Operating vibration | 0.66 G |
| Non-operating vibration | 1.3 G |
| Weight & dimensions | |
| Width | 12.7" (321.4 mm) |
| Depth | 8.35" (212 mm) |
| Height (front) | 0.76" (1.93 cm) |
| Height (rear) | 0.823" (2.09 cm) |
| Weight | 3 lbs (1.36 kg) |
| Packaging data | |
| Cables included | AC |
| Other features | |
| Wi-Fi data rate (max) | 2400 Mbit/s |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| On-board graphics card | Yes |
| Audio system | MaxxAudio Pro |
| Anti-glare screen | Yes |
| Packaging content | |
| Cables included | AC |
