StarTech.com
NOTECONS01 - StarTech.com TURN ANY LAPTOP INTO A CONSOLE FOR HEADLESS SERVERS, PCS, ATMS, KIOSKS AND MORE
NOTECONS01 - StarTech.com TURN ANY LAPTOP INTO A CONSOLE FOR HEADLESS SERVERS, PCS, ATMS, KIOSKS AND MORE
SKU:NOTECONS01
Regular price
$494.00 USD
Regular price
Sale price
$494.00 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
Turn any laptop into a console for headless servers, PCs, ATMs, kiosks and more
The NOTECONS01 KVM Console to USB 2.0 Portable Laptop Crash Cart Adapter turns your notebook or netbook into a portable server crashcart, eliminating the need to lug around a large, heavy and awkward video screen, keyboard, and mouse. This adapter delivers the VGA stream from any host computer to a laptop and emulates the laptop mouse and keyboard outputs for simple access and control of connected servers, PCs or other "headless" devices.
"StarTech.com's USB KVM may be your new best friend for trips to the datacenter... you can use this from the back of the rack. So if you are handling issues that require moving cables or network connections... this can be a major timesaver."
€” everythingUSB.com
"The CRN Test Center recommends StarTech's Crash Cart Adapter for any company with a data center or with technicians servicing computers in the field"
€” CRN
With portability for the mobile administrator or repair technician in mind, this USB-powered adapter features a small-footprint design that requires no additional accessories to connect to most servers, and requires no server-side software installation. Plus, the pocket-sized adapter draws its power from the server-side USB connections, allowing the laptop/netbook to last longer without consuming battery power.
Ensuring full control of the connected units, the Laptop KVM Server Console Adapter provides immediate access to the POST screen and BIOS, plus the ability to handle full configuration of the attached PC or machine; administrators can connect to a headless server/device without the need of an expensive LCD rackmount console or bulky monitor, keyboard and mouse solution.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
How it works:
The StarTech.com Advantage
- Ultra high resolution support up to 1920 x 1200 @ 60Hz €“ The highest resolution portable console available
- No power adapter needed - Draws power from the server side USB connection saving your laptop€™s battery life, and avoiding the hassle of finding 110V outlets in the server room or remote locations
- Small, ruggedized casing (similar to the size of a cellphone) is easily stored and transported; with no server-side software requirement, you will be up and running in seconds
The NOTECONS01 KVM Console to USB 2.0 Portable Laptop Crash Cart Adapter turns your notebook or netbook into a portable server crashcart, eliminating the need to lug around a large, heavy and awkward video screen, keyboard, and mouse. This adapter delivers the VGA stream from any host computer to a laptop and emulates the laptop mouse and keyboard outputs for simple access and control of connected servers, PCs or other "headless" devices.
"StarTech.com's USB KVM may be your new best friend for trips to the datacenter... you can use this from the back of the rack. So if you are handling issues that require moving cables or network connections... this can be a major timesaver."
€” everythingUSB.com
"The CRN Test Center recommends StarTech's Crash Cart Adapter for any company with a data center or with technicians servicing computers in the field"
€” CRN
With portability for the mobile administrator or repair technician in mind, this USB-powered adapter features a small-footprint design that requires no additional accessories to connect to most servers, and requires no server-side software installation. Plus, the pocket-sized adapter draws its power from the server-side USB connections, allowing the laptop/netbook to last longer without consuming battery power.
Ensuring full control of the connected units, the Laptop KVM Server Console Adapter provides immediate access to the POST screen and BIOS, plus the ability to handle full configuration of the attached PC or machine; administrators can connect to a headless server/device without the need of an expensive LCD rackmount console or bulky monitor, keyboard and mouse solution.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
How it works:
The StarTech.com Advantage
- Ultra high resolution support up to 1920 x 1200 @ 60Hz €“ The highest resolution portable console available
- No power adapter needed - Draws power from the server side USB connection saving your laptop€™s battery life, and avoiding the hassle of finding 110V outlets in the server room or remote locations
- Small, ruggedized casing (similar to the size of a cellphone) is easily stored and transported; with no server-side software requirement, you will be up and running in seconds
Specification:
| Ports & interfaces | |
|---|---|
| Cable length | 16.4" (0.416 m) |
| Console USB ports quantity | 1 |
| USB connector type | Mini-USB B |
| Number of computers controlled | 1 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | VGA |
| Audio connections | No |
| Technical details | |
| Product colour | Black |
| Rack mounting | No |
| Plug and Play | Yes |
| On Screen Display (OSD) | No |
| Number of users | 1 user(s) |
| LED indicators | Yes |
| Sustainability certificates | RoHS |
| Video | |
| HD type | Full HD |
| Video bandwidth | 60 Hz |
| Maximum resolution | 1920 x 1200 pixels |
| Performance | |
| Daisy chain | No |
| HD type | Full HD |
| Video bandwidth | 60 Hz |
| Plug and Play | Yes |
| Maximum resolution | 1920 x 1200 pixels |
| Number of users | 1 user(s) |
| Design | |
| Mean time between failures (MTBF) | 909000 h |
| Product colour | Black |
| Cable length | 16.4" (0.416 m) |
| Rack mounting | No |
| LED indicators | Yes |
| Certification | CE, FCC, TAA, UL |
| Housing material | Plastic |
| Display | |
| Built-in display | No |
| On Screen Display (OSD) | No |
| Power | |
| Power source | USB |
| System requirements | |
| Server operating systems supported | Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows Vista x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 |
| Linux operating systems supported | Yes |
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 13.0 Ventura |
| Sustainability | |
| Sustainability certificates | RoHS |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Weight & dimensions | |
| Width | 2.91" (74 mm) |
| Depth | 4.53" (115 mm) |
| Height | 0.591" (15 mm) |
| Weight | 6 oz (170 g) |
| Package width | 6.54" (166 mm) |
| Package depth | 11.9" (303 mm) |
| Package height | 1.81" (46 mm) |
| Package weight | 12.8 oz (363 g) |
| Packaging data | |
| Package width | 6.54" (166 mm) |
| Package depth | 11.9" (303 mm) |
| Package height | 1.81" (46 mm) |
| Package weight | 12.8 oz (363 g) |
| Packaging content | |
| Cables included | USB |
| Software included | Yes |
| Certificates | |
| Certification | CE, FCC, TAA, UL |
| Logistics data | |
| Master (outer) case width | 12.6" (320 mm) |
| Master (outer) case length | 20.5" (520 mm) |
| Master (outer) case height | 20.7" (525 mm) |
| Products per master (outer) case | 30 pc(s) |
| Harmonized System (HS) code | 85176200 |
