PDUH32HV - Tripp Lite PDU BASIC 230V 32A C13 10 OUTLET IEC309 BLUE HORIZONTAL 1U

The PDUH32HV 7.7kW Single-Phase 200-240V Basic PDU is a versatile no-frills unit for data centers, server rooms and network wiring closets. Perfectly suited for high-density IT environments, the PDUH32HV features 10 total outlets€”two in front and eight in the rear. The IEC 309 32A Blue (2P+E) input plug with 3.6 m cord connects to your facility€™s compatible AC power source, generator or protected UPS to distribute power to connected equipment. The switchless design prevents an accidental shutdown, which could lead to costly downtime. Dual 20A circuit breakers protect connected equipment from dangerous overloads. The reversible all-metal housing supports a variety of mounting options, including 1U horizontal or 0U vertical mounting in EIA-standard 19-inch racks, under a counter or on a wall or workbench. Reliable Single-Phase 32A 200-240V Power Distribution Ideal no-frills PDU for data centers, server rooms and network wiring closets 10 total C13 outlets€”8 rear and 2 front IEC 309 32A Blue (2P+E) input with 3.6 m power cord Rear-panel grounding lug Dual 20A circuit breakers protect against overloads Switchless Design Prevents accidental shutdowns and costly downtime Versatile Installation Options Reversible all-metal housing faces front or rear in rack Supports 1U horizontal or 0U vertical mounting in EIA-standard 19 in. racks Also mounts on wall, workbench or under a counter



Specification:



Design
Type	Single-phase
PDU types	Basic
Mounting	Horizontal
Product colour	Black
Rack capacity	1U
Housing material	Metal
Ports & interfaces
AC outlets quantity	4 AC outlet(s)
AC outlet types	C19 coupler
Power plug	IEC309
Features
Cable length	144.1" (3.66 m)
Ergonomics
Cable length	144.1" (3.66 m)
Power
Maximum power	7700 W
Nominal input voltage	200-240 V
Nominal output voltage	200-240 V
Power protection features	Overload
Maximum current	32 A
AC input frequency	50 - 60 Hz
Weight & dimensions
Dimensions (WxDxH)	17.5 x 3.75 x 1.77" (445 x 95.3 x 45 mm)
Weight	6.33 lbs (2.87 kg)
Width	17.3" (439.4 mm)
Depth	3.75" (95.2 mm)
Height	1.7" (43.2 mm)
Package width	20.3" (514.4 mm)
Package depth	11.3" (285.8 mm)
Package height	3" (76.2 mm)
Package weight	7.08 lbs (3.21 kg)
Package dimensions (WxDxH)	20.2 x 11.3 x 2.99" (514 x 286 x 76 mm)
Packaging data
Package width	20.3" (514.4 mm)
Package depth	11.3" (285.8 mm)
Package height	3" (76.2 mm)
Package weight	7.08 lbs (3.21 kg)
Package dimensions (WxDxH)	20.2 x 11.3 x 2.99" (514 x 286 x 76 mm)
Operational conditions
Storage temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	5 - 95%
Technical details
Sustainability certificates	RoHS
Master (outer) case GTIN (EAN/UPC)	10037332183207
Logistics data
Master (outer) case width	20" (508 mm)
Master (outer) case length	21" (533.4 mm)
Master (outer) case height	12" (304.8 mm)
Master (outer) case gross weight	35.9 lbs (16.3 kg)
Products per master (outer) case	5 pc(s)
Country of origin	China
