Description
Intel® Remote Management Module Support The Intel® Remote Management Module (Intel® RMM) allows you to securely gain access and control servers and other devices from any machine on the network. Remote access includes remote management capability, including power control, KVM, and media redirection, with a dedicated management network interface card (NIC). Integrated BMC with IPMI IPMI (Intelligent Platform Management Interface) is a standardized interface used for out-of-band management of computer systems. The integrated BMC (Baseboard Management Controller) is a specialized microcontroller that enables IPMI. Intel® Node Manager Intel® Intelligent Power Node Manager is a platform resident technology that enforces power and thermal policies for the platform. It enables data center power and thermal management by exposing an external interface to management software through which platform policies can be specified. It also enables specific data center power management usage models such as power limiting. Intel® Rapid Storage Technology enterprise Intel ® Rapid Storage Technology enterprise (Intel ® RSTe) provides performance and reliability for supported systems equipped with Serial ATA (SATA) devices, Serial Attached SCSI (SAS) devices, and/or solid state drives (SSDs) to enable an optimal enterprise storage solution.
Specification:
| Hard drive | |
|---|---|
| RAID levels | 0, 1 |
| Hot-swap HDD bays | Yes |
| Software | |
| Compatible operating systems | VMware*|Ubuntu* |
| Processor | |
| Built-in processor | No |
| Processor socket | LGA 3647 (Socket P) |
| Number of processors supported | 2 |
| Motherboard chipset | Intel® C628 |
| Compatible processor series | Intel® Xeon® |
| Processor manufacturer | Intel |
| Design | |
| Product codename | Wolf Pass |
| Rack-Friendly board | Yes |
| LED indicators | Yes |
| Heat sink included | Yes |
| Heat sink | (2) 1U Standard Heat Sink FXXCA78X108HS |
| Product colour | Black, Gray |
| Chassis type | Rack (1U) |
| Memory | |
| Supported memory types | DDR4-SDRAM |
| Number of DIMM slots | 24 |
| Maximum internal memory | 6000 GB |
| Storage | |
| Number of storage drives supported | 10 |
| Number of 2.5" bays | 8 |
| RAID levels | 0, 1 |
| Hot-swap HDD bays | Yes |
| Storage drive sizes supported | M.2 |
| SSD form factor | M.2 |
| Performance | |
| Intel Rapid Storage Technology | Yes |
| Internal I/O Expansion Module x8 Gen 3 | 1 |
| Trusted Platform Module (TPM) version | 2.0 |
| Trusted Platform Module (TPM) | Yes |
| Intel Remote Management Module Support | Yes |
| Intel Intelligent Power Node Manager | Yes |
| Integrated BMC with IPMI | Yes |
| Compatible operating systems | VMware*|Ubuntu* |
| Network | |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Ports & interfaces | |
| USB ports quantity | 5 |
| Serial ports quantity | 2 |
| Number of SATA connectors | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| Expansion slots | |
| PCI Express x16 (Gen 3.x) slots | 2 |
| PCI Express slots version | 3.0 |
| PCI Express x24 Riser Super slots | 1 |
| PCI Express OCuLink connectors (NVMe support) | 2 |
| Features | |
| Trusted Platform Module (TPM) version | 2.0 |
| Trusted Platform Module (TPM) | Yes |
| Integrated BMC with IPMI | Yes |
| Compatible operating systems | VMware*|Ubuntu* |
| Harmonized System (HS) code | 8473301180 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G157815L2 |
| Number of UPI links | 3 |
| Intel® Optane™ DC Persistent Memory Supported | Yes |
| Product codename | Wolf Pass |
| Technical details | |
| USB ports quantity | 5 |
| PCI Express x16 (Gen 3.x) slots | 2 |
| Number of storage drives supported | 10 |
| Number of 2.5" bays | 8 |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Trusted Platform Module (TPM) | Yes |
| Rack-Friendly board | Yes |
| Intel Remote Management Module Support | Yes |
| Intel Intelligent Power Node Manager | Yes |
| Integrated BMC with IPMI | Yes |
| Heat sink included | Yes |
| Heat sink | (2) 1U Standard Heat Sink FXXCA78X108HS |
| CPU configuration (max) | 2 |
| Chassis type | Rack (1U) |
| Target market | Mainstream |
| Supported board | Intel Server Board S2600WFQR |
| Status | Launched |
| Riser slot 2 number of lanes | 24 |
| Riser slot 1 number of lanes | 24 |
| Launch date | Q1'22 |
| Extended warranty available for purchase (select countries) | Yes |
| PCI Express x24 Riser Super slots | 1 |
| Harmonized System (HS) code | 8473301180 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G157815L2 |
| Colour | |
| Product colour | Black, Gray |
| Indication | |
| LED indicators | Yes |
| Logistics data | |
| Harmonized System (HS) code | 8473301180 |
| Processor special features | |
| Intel Rapid Storage Technology | Yes |
| Internal I/O Expansion Module x8 Gen 3 | 1 |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Remote Management Module Support | Yes |
| Intel Intelligent Power Node Manager | Yes |
| Processor ARK ID | 132543 |
| Power | |
| Redundant power supply (RPS) support | Yes |
| Power supply type | AC |
| Power supply | 1300 W |
| Number of power supply units | 1 |
| Thermal Design Power (TDP) | 165 W |
| Weight & dimensions | |
| Width | 16.9" (430 mm) |
| Height | 1.73" (44 mm) |
| Depth | 28" (710 mm) |
| Other features | |
| On-board graphics card | No |
| CPU configuration (max) | 2 |
| Product codename | Wolf Pass |
| Target market | Mainstream |
| Supported board | Intel Server Board S2600WFQR |
| Status | Launched |
| Riser slot 2 number of lanes | 24 |
| Riser slot 1 number of lanes | 24 |
| Launch date | Q1'22 |
| Extended warranty available for purchase (select countries) | Yes |
