RES2SV240 - Intel INTEL RAID EXPANDER CARD RES2SV
RES2SV240 - Intel INTEL RAID EXPANDER CARD RES2SV
SKU:RES2SV240
Regular price
$117.80 USD
Regular price
Sale price
$117.80 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
As the perfect complement for Intel€™s SAS-2 generation RAID cards, this twenty-four port expander card offers ultimate flexibility for architecting a high drive count (greater than 8 drive) storage solution in any sized system. The low profile height enables simple installation into a 1U or 2U system with a low profile chassis cutout. In addition, the MD2-compliant depth (6.6€�) fits in motherboards with heat-sinks that would interfere with longer add-in cards. In cases where an add-in slot is not available, the Intel RAID Expander Card RES2SV240 can even be mounted to a chassis wall or air-duct.
Specification:
| Ports & interfaces | |
|---|---|
| Supported storage drive interfaces | SAS, Serial ATA |
| Host interface | PCI Express x4 |
| PCI Card form factor | Full-height (low-profile) |
| Internal mini-SAS ports | 20 |
| External mini-SAS ports | 8 |
| Performance | |
| RAID ARK ID | 81277 |
| RAID levels | JBOD |
| Internal memory | 8 MB |
| Sustained data transfer rate (native) | 12288 MB/s |
| Form factor | Low Profile MD2 Card |
| Data transfer rate | 12 Gbit/s |
| Compatible products | Intel Server System R1208WT2GS Intel Server System R1208WTTGS Intel Server System R1304WT2GS Intel Server System R1304WTTGS Intel Server System R2208WT2YS Intel Server System R2208WTTYC1 Intel Server System R2208WTTYS Intel Server System R2224WTTYS Intel Server System R2308WTTYS Intel Server System R2312WTTYS |
| Harmonized System (HS) code | 84733080 |
| Export Control Classification Number (ECCN) | 4A994 |
| Commodity Classification Automated Tracking System (CCATS) | NA |
| Design | |
| Form factor | Low Profile MD2 Card |
| Power | |
| Voltage | 12 V |
| Technical details | |
| Product type | RAID |
| Data transfer rate | 12288 Mbit/s |
| Status | Launched |
| Product name | Intel RAID Expander RES3FV288 |
| PCI Express host interface | PCIe x4 |
| Market segment | Server |
| Launch date | Q2'14 |
| Born on date | Q2 '14 |
| Last change | 63903513 |
| Target market | Scalable Performance |
| Last order date | 2019-08-03 05:00:37 |
| Extended warranty available for purchase (select countries) | Yes |
| Expected discontinuance date | Q2'23 |
| Packaging content | (1) Expander board and (2) short cables to connect to a RAID card or module |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 55 °C |
| Weight & dimensions | |
| Width | 2.5" (63.5 mm) |
| Depth | 6.6" (167.6 mm) |
| Packaging content | (1) Expander board and (2) short cables to connect to a RAID card or module |
| Packaging content | |
| Packaging content | (1) Expander board and (2) short cables to connect to a RAID card or module |
| Logistics data | |
| Harmonized System (HS) code | 84733080 |
| Other features | |
| RAID ARK ID | 81277 |
| PCI Card form factor | Full-height (low-profile) |
| Supported devices | SAS/SATA |
| Internal ports | 28 |
| External ports | 8 |
| Market segment | Server |
