SMT1500J - APC SMART-UPS 1500VA LCD 100V

APC SMT1500J. UPS topology: Line-Interactive, Output power capacity: 1.5 kVA, Output power: 980 W. AC outlet types: NEMA 5€“15P, AC outlets quantity: 8 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 17 Ah, Battery voltage: 12 V. Form factor: Mini Tower, Product color: Black, Display type: LCD. Width: 6.77" (172 mm), Depth: 17.3" (439 mm), Height: 8.86" (225 mm)



Specification:



Power
Output frequency	50/60 Hz
Output power	1000 W
Input operation voltage (min)	75 V
Input operation voltage (max)	154 V
Output operation voltage (min)	120 V
Output operation voltage (max)	120 V
Surge energy rating	459 J
Emergency Power Off (EPO)	Yes
Output voltage Total Harmonic Distortion (THD)	5%
Output power capacity	1.44 kVA
Input frequency	50/60 Hz
Ports & interfaces
Cable length	96.1" (2.44 m)
USB port	Yes
SmartSlot	Yes
AC outlets quantity	6 AC outlet(s)
AC outlet types	NEMA 5€“15R
Power plug	NEMA L5-15P
Performance
Audible alarm modes	Alarm when on battery, Low battery alarm
UPS topology	Line-Interactive
Waveform	Sine
Auto-restart	Yes
LED indicators	Status, Battery replacement
Surge protection	Yes
Audible alarm(s)	Yes
Features
Output frequency	50/60 Hz
Audible alarm modes	Alarm when on battery, Low battery alarm
UPS topology	Line-Interactive
Waveform	Sine
Auto-restart	Yes
Output power	1000 W
Input operation voltage (min)	75 V
Input operation voltage (max)	154 V
Output operation voltage (min)	120 V
Output operation voltage (max)	120 V
Surge energy rating	459 J
Surge protection	Yes
Emergency Power Off (EPO)	Yes
Output voltage Total Harmonic Distortion (THD)	5%
Audible alarm(s)	Yes
Output power capacity	1.44 kVA
Input frequency	50/60 Hz
Battery
Battery life (max)	6 year(s)
Battery capacity	432 VAh
Battery technology	Sealed Lead Acid (VRLA)
Battery recharge time	3 h
Hot-swap battery	Yes
Cold start	Yes
Automatic battery test	Yes
Design
Rack capacity	2U
Form factor	Rackmount
LED indicators	Status, Battery replacement
Product colour	Black
Certification	CSA, FCC Part 15 Class A, UL 1778, REACH, PEP, EOLI
Cable length	96.1" (2.44 m)
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 45 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	0 - 118110.2" (0 - 3000 m)
Technical details
Output frequency	50/60 Hz
Sustainability certificates	RoHS, ENERGY STAR
Weight & dimensions
Weight	63.1 lbs (28.6 kg)
Width	17" (432 mm)
Height	3.5" (89 mm)
Depth	18" (457 mm)
Package width	23.4" (594 mm)
Package depth	23.7" (603 mm)
Package height	9.88" (251 mm)
Package weight	70.3 lbs (31.9 kg)
Packaging data
Resource CD	Yes
Rack mount kit	Yes
Quick installation guide	Yes
Cables included	RS-232, USB cable
Software CD	Yes
Package width	23.4" (594 mm)
Package depth	23.7" (603 mm)
Package height	9.88" (251 mm)
Package weight	70.3 lbs (31.9 kg)
Logistics data
Products per pallet	16 pc(s)
Certificates
Certification	CSA, FCC Part 15 Class A, UL 1778, REACH, PEP, EOLI
Packaging content
Resource CD	Yes
Rack mount kit	Yes
Quick installation guide	Yes
Cables included	RS-232, USB cable
Software CD	Yes
