SMT3000RMT2U - APC SMART-UPS 3000VA RM 2U LCD 208V

Intuitive LCD interface Provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys. Predictive replace battery date Dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning. Green mode Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection. Energy meter Provides actual kilowatt hours of usage for energy conscious users. Outlet group control Turn on/off, reboot or shut down select outlet groups to save dispatching technicians to remote locations (for UPSs with switched outlet groups). Sequenced shutdown and restart Configure select outlet groups to shut down and turn on in a pre-determined order (for UPSs with switched outlet groups). Pure sine wave output on battery Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics. Single switched outlet group Single outlet group that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off and non-critical load shedding. Wide input voltage range Designed for harsh electrical environments to save battery life. StruxureWare Central compatible Enables centralized management via StruxureWare Central. Battery failure notification Provides early-warning fault analysis on batteries enabling timely preventive maintenance High online efficiency Reduces utlility costs, generates less heat. LED Indicators Provide easy-to-read status of the unit and utility power conditions. Cold-start capable Provides temporary battery power when the utility power is out. Hot-swappable batteries Ensures clean, uninterrupted power to protected equipment while batteries are being replaced Disconnected battery notification Warns when a battery is not available to provide backup power. Automatic self-test Periodic battery self-test ensures early detection of a battery that needs to be replaced. Automatic restart of loads after UPS shutdown Automatically starts up the connected equipment upon the return of utility power. Adjustable voltage-transfer points Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation. Adjustable voltage sensitivity Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications. Audible alarms Provides notification of changing utility power and UPS conditions User-replaceable batteries Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR) USB connectivity Provides management of the UPS via a USB port (not available on all models). Serial Connectivity Provides management of the UPS via a serial port. Temperature-compensated battery charging Prolongs battery life by regulating the charge voltage according to battery temperature. Boost and Trim Automatic Voltage Regulation (AVR) Gives higher application availability by correcting low and high voltage conditions without using the battery. Intelligent battery management Maximizes battery performance, life, and reliability through intelligent, precision charging. Safety-agency approved Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment. Network manageable Provides remote management of the UPS over the network. Frequency and voltage regulation Gives higher application availability by correcting poor frequency and voltage conditions without using the battery. Predicitive failure notification Provides early-warning fault analysis ensuring proactive component replacement. Boost and Trim Automatic Voltage Regulation (AVR) Gives higher application availability by correcting low and high voltage conditions without using the battery. Intelligent battery management Maximizes battery performance, life, and reliability through intelligent, precision charging. Power conditioning Protects connected loads from surges, spikes, lightning, and other power disturbances. Temperature-compensated battery charging Prolongs battery life by regulating the charge voltage according to battery temperature. Automatic restart of loads after UPS shutdown Automatically starts up the connected equipment upon the return of utility power. Automatic self-test Periodic battery self-test ensures early detection of a battery that needs to be replaced. Disconnected battery notification Warns when a battery is not available to provide backup power. Network manageable Provides remote management of the UPS over the network. Audible alarms Actively let you know if the unit is on battery, if the battery is low or if there is an overload condition. LED status indicators Quickly understand unit and power status with visual indicators. Serial Connectivity Provides management of the UPS via a serial port. USB connectivity Provides management of the UPS via a USB port (not available on all models). Disconnected battery notification Warns when a battery is not available to provide backup power. User-replaceable batteries Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair Hot-swappable batteries Ensures clean, uninterrupted power to protected equipment while batteries are being replaced Predictive failure notification Provides early-warning fault analysis ensuring proactive component replacement. Resettable circuit breakers Enables a quick recovery from overload events. Battery failure notification Provides early-warning fault analysis on batteries enabling timely preventive maintenance Adjustable voltage-transfer points Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation. Adjustable voltage sensitivity Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications. Safety-agency approved Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.



Specification:



Power
Output power	2700 W
Input operation voltage (min)	75 V
Input operation voltage (max)	154 V
Surge energy rating	459 J
Efficiency	98%
Output voltage Total Harmonic Distortion (THD)	5%
Output power capacity	2.88 kVA
Input frequency	50/60 Hz
Ports & interfaces
Cable length	96.1" (2.44 m)
AC outlets quantity	8 AC outlet(s)
AC outlet types	NEMA 5€“15R, NEMA 5€“20R
Power plug	NEMA L5-30P
USB 2.0 ports quantity	1
Performance
Audible alarm modes	Battery replacement
Waveform	Sine
Noise level	55 dB
Audible alarm(s)	Yes
Features
Audible alarm modes	Battery replacement
Waveform	Sine
Output power	2700 W
Input operation voltage (min)	75 V
Input operation voltage (max)	154 V
Surge energy rating	459 J
Efficiency	98%
Output voltage Total Harmonic Distortion (THD)	5%
Noise level	55 dB
Audible alarm(s)	Yes
Output power capacity	2.88 kVA
Input frequency	50/60 Hz
Battery
Battery technology	Sealed Lead Acid (VRLA)
Battery recharge time	3 h
Typical backup time at half load	7.2 min
Typical backup time at full load	3.4 min
Replacement battery cartridge	RBC43
Design
Rack capacity	2U
Form factor	Rackmount
Product colour	Gray
Cable length	96.1" (2.44 m)
Display type	LCD
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 45 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	0 - 118110.2" (0 - 3000 m)
Non-operating altitude	0 - 590551.2" (0 - 15000 m)
Technical details
Sustainability certificates	RoHS, ENERGY STAR
Packaging data
Package dimensions (WxDxH)	23.6 x 38.6 x 10" (600 x 980 x 254 mm)
Package weight	114 lbs (51.7 kg)
Weight & dimensions
Weight	97.7 lbs (44.3 kg)
Width	18.9" (480 mm)
Package weight	114 lbs (51.7 kg)
Height	3.39" (86 mm)
Depth	26.9" (683 mm)
Other features
Package dimensions (WxDxH)	23.6 x 38.6 x 10" (600 x 980 x 254 mm)
Output connection type	6 x NEMA 5-15R & 2 x NEMA 5-20R
Nominal output voltage	120 V
Nominal input voltage	120 V
