SMX3000RMLV2UNC - APC SMART-UPS X, LINE INTERACTIVE, 3KVA, RACK/TOWER CONVERTIBLE 2U, 120V, 3X 5-15R+3

Intuitive LCD interface Provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys. High frequency design Reduces or eliminates bulky transformers resulting in lighter units for ease of handling. Auto recognition of external batteries UPS recognizes when external battery packs are attached and automatically adjusts runtime. Predictive replace battery date Dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning. Green mode Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection. Energy meter Provides actual kilowatt hours of usage for energy conscious users. Outlet group control Turn on/off, reboot or shut down select outlet groups to save dispatching technicians to remote locations (for UPSs with switched outlet groups). Sequenced shutdown and restart Configure select outlet groups to shut down and turn on in a pre-determined order (for UPSs with switched outlet groups). Load shedding Turn off select outlet groups in a pre-determined sequence to shed less critical equipment and conserve runtime (UPSs with switched outlet groups). InfraStruXure Central compatible Enables centralized management via APC InfraStruXure Central. Pure sine wave output on battery Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics. Multiple switched outlet groups Multiple outlet groups that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off and non-critical load shedding. Wide input voltage range Designed for harsh electrical environments to save battery life. Battery failure notification Provides early-warning fault analysis on batteries enabling timely preventive maintenance.



Specification:



Power
Output frequency	50/60 Hz
Output power	2700 W
Input operation voltage (min)	70 V
Input operation voltage (max)	153 V
Output operation voltage (max)	120 V
Surge energy rating	540 J
Emergency Power Off (EPO)	Yes
Output voltage Total Harmonic Distortion (THD)	5%
Output power capacity	2.88 kVA
Input frequency	50/60 Hz
Ports & interfaces
Cable length	96.1" (2.44 m)
USB port	Yes
Serial interface	Yes
SmartSlot	Yes
AC outlets quantity	7 AC outlet(s)
AC outlet types	NEMA 5€“15R,NEMA 5€“20R,NEMA L5-30R
Power plug	NEMA L5-30P
Performance
Audible alarm modes	Alarm when on battery, Low battery alarm, Overload alarm
UPS topology	Line-Interactive
Waveform	Sine
Auto-restart	Yes
Automatic Voltage Regulation (AVR)	Yes
LED indicators	Yes
Noise level	55 dB
Audible alarm(s)	Yes
Temperature voltage compensation	Yes
Features
Output frequency	50/60 Hz
Web-based management	No
Audible alarm modes	Alarm when on battery, Low battery alarm, Overload alarm
UPS topology	Line-Interactive
Waveform	Sine
Auto-restart	Yes
Automatic Voltage Regulation (AVR)	Yes
Output power	2700 W
Input operation voltage (min)	70 V
Input operation voltage (max)	153 V
Output operation voltage (max)	120 V
Surge energy rating	540 J
Emergency Power Off (EPO)	Yes
Output voltage Total Harmonic Distortion (THD)	5%
Noise level	55 dB
Audible alarm(s)	Yes
Output power capacity	2.88 kVA
Temperature voltage compensation	Yes
Input frequency	50/60 Hz
Battery
Battery life (max)	5 year(s)
Number of batteries supported	1
Battery technology	Sealed Lead Acid (VRLA)
Battery recharge time	3 h
Hot-swap battery	Yes
Cold start	Yes
Automatic battery test	Yes
Design
Rack capacity	2U
Form factor	Rackmount/Tower
LED indicators	Yes
Product colour	Black
Certification	BSMI, CSA, EN 50091-2, EN 55022 Class A, FCC Part 15 Class A, NOM, TAA, TUV, UL 1778, VCCI Class A
Cable length	96.1" (2.44 m)
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 45 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	0 - 118110.2" (0 - 3000 m)
Non-operating altitude	0 - 590551.2" (0 - 15000 m)
Technical details
Output frequency	50/60 Hz
Sustainability certificates	RoHS, ENERGY STAR
Management features
Web-based management	No
Weight & dimensions
Weight	84.9 lbs (38.5 kg)
Width	17" (432 mm)
Height	3.35" (85 mm)
Depth	26.3" (667 mm)
Package width	23.5" (596 mm)
Package depth	34.2" (869 mm)
Package height	9.57" (243 mm)
Package weight	100.1 lbs (45.4 kg)
Packaging data
Screws included	Yes
Resource CD	Yes
Quick installation guide	Yes
Cables included	RS-232, USB cable
Bracket	Yes
Software CD	Yes
Package width	23.5" (596 mm)
Package depth	34.2" (869 mm)
Package height	9.57" (243 mm)
Package weight	100.1 lbs (45.4 kg)
Logistics data
Products per pallet	8 pc(s)
Certificates
Certification	BSMI, CSA, EN 50091-2, EN 55022 Class A, FCC Part 15 Class A, NOM, TAA, TUV, UL 1778, VCCI Class A
Packaging content
Screws included	Yes
Resource CD	Yes
Quick installation guide	Yes
Cables included	RS-232, USB cable
Bracket	Yes
Software CD	Yes
